Carson CSF343W Use And Care Manual

Hide thumbs
1
2
3
4
5
6
Table of Contents

Advertisement

Quick Links

Download this manual
Enlarged version

Troubleshooting

Review the following before contacting customer service.
Problem
Possible Cause
Timer knob does not • Is the power connected?
turn
Drum does not turn
• Is the door closed?
• Is the power connected?
Air is not hot
• Is the timer incorrectly set to air dry?
The laundry is not
• Are the filters clear?
thoroughly dried
• Is there too much laundry in the dryer? • Reduce the amount in the dryer.
• Have items been added whilst the dryer • Re-dry the items again.
is in operation?
• Has the laundry become twisted whilst • Untwist the items and re-dry.
drying?
• Has the dryer been placed in a
poorly ventilated area?
•
Is the drying time sufficient?
Dryer does not start • Is the power connected?
• Is the door closed?
• Is the timer in the OFF position?

Specifications

Model:
CSF343W
Voltage/Freque ncy:
220-240V- /50Hz
Net Weight:
20Kg
NOTE: Consistent with our continuing
product development policy,
improvements may have been made
which render the contents of this
package slightly different to that shown.
What to do
• Connect the power cord and
switch electrical supply ON.
• Close the door.
• Connect the power cord and
switch electrical supply ON.
• Set the timer to hot air.
• Clean the filters.
• Place the dryer in a well-vented
area.
• Increase drying time, use full
heat
• Connect the power cord and
switch electrical supply ON.
• Close the door.
• Set the timer.
Drying C apacity:
4.0Kg
Rated Input:
1200W/700W
Dimensions(mm):
595x438x671
12
USE AND CARE GUIDE
MODEL NO. : CSF343W

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CSF343W and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Carson CSF343W

Summary of Contents for Carson CSF343W

  • Page 1: Troubleshooting

    220-240V- /50Hz 1200W/700W Net Weight: 20Kg Dimensions(mm): 595x438x671 USE AND CARE GUIDE MODEL NO. : CSF343W NOTE: Consistent with our continuing product development policy, improvements may have been made which render the contents of this package slightly different to that shown.
  • Page 2 Safety Oil-affected items can ignite spontaneously, especially when exposed to heat sources such as in a clothes dryer. The items become warm, causing an oxidation reaction in the oil. When using electrical appliances, in order to reduce the risk of fire, electric shock, and/ Oxidation creates heat.

  • Page 3: Operation

    Components Operation • Check the items to be dried do not have combustible materials or foreign objects within them; for example, paper and Electrical Requirements coins etc. The unit is required to be plugged into a three pin 240VAC mains electrical socket that is reliably grounded.

  • Page 4: Control Panel

    Control Panel Drying Tips Heat Selector button Delicate items should be placed into a nylon To minimize the risk of fire in a tumble dryer, .& half heat net bag prior to drying. Drying under-wire the following should be observed: Select Full heat for items that are particularly bulky or large .a.

  • Page 5: Installation

    Installation Wall Mounting 3. Install the exhaust flue to the exhaust vent on the rear panel and adjust the direction of the flue as required. Fix the 2 mounting brackets to the wall using suitable 4. Carefully raise the dryer and position it so the bracket hooks enter fasteners (not supplied).

  • Page 6: Maintenance

    Maintenance Cleaning the Air Intake Filter Fig. 3 Cleaning the Lint Filter The filter should be cleaned once a month. Disconnect the electrical cord prior to any and lower ends of the air intake shroud. drying. It must be cleaned before each use. Remove the filter inside the shroud and clean 1.
