- Page 1 ULTRAVIOLET WATER DISINFECTION SYSTEM OPERATION & MAINTENANCE MANUAL GUV SERIES UV System GUV-7, GUV-10, GUV-15, GUV-20 Use the attached chart to record lamp changes to the system: Lamp Change Date Lamp Change Date INSTALL DATE: March 2009...
-
Page 2: Replacement Parts List
You should have received the following: REPLACEMENT PARTS LIST MODEL Lamp # Quartz # Ballast # Orings Compression Fittings GUV-7 #1 L-501414 #1 Q-532017 #1 P-78PIBP #1 M-75214O #1 M-001RCN GUV-10 #1 L-524414 #1 Q-532017 #1 E-40HOIB #1 M-75214O #1 M-001RCN... - Page 3 1.1. Warning UV light is harmful to your eyes and skin. Do not look directly into the light. Always unplug (disconnect power) your unit before installing or removing a lamp. Your unit may have a green LED light that indicates that the lamp is operating and the unit has an audible alarm that will sound in the event of lamp failure.
- Page 4 Step Action Diagram Use # 10 screws (not included) to mount clips ( M-2500MC) to wall. Note: On GUV-15/20 four mounting clips are included. Two clips are to be mounted two inches apart, and the remaining clips are to be mounted directly below them 2”...
- Page 5 UV unit may be mounted vertically or horizontally. UV units inlet port may be rotated 180 degrees. If your system has been modified with a port do not install with the port facing down. 2. Your Disinfection Unit – Installation If you are attempting to install the unit by yourself and you have questions, please call your water quality or plumbing professional.
- Page 6 3. Maintenance As noted in this manual, your lamp needs to be replaced on a yearly basis the quartz cleaned on a more frequent basis. The quartz may have “build up” on it. If it does, clean it with soap and water. If the quartz is stained, use a product like CLR or LimeAway (both available at the grocery store).
- Page 7 Recommendations Use a licensed plumber or qualified water professional to do the installation. • • Check the unit on a regular basis to see if the lamp is on (the green LED indicator will tell you if the lamp is working). •...
- Page 8 August 2009...
-
Page 9: Warranty Registration
EMAIL:__________________________ Please fill out the above information and forward it to your dealer or to Glasco UV LLC. This will provide you with a 7-year warranty on the stainless steel chamber and a 1-year warranty on the electrical components. UV lamps are warranted for 30 days.
