  • Page 1 EMC Professional NET(19“) Time Server with integrated DCF77 Time Receiver for Industrial Applications Manual...
  • Page 2 Manual EMC Professional NET(19“) © 2019 GUDE Systems GmbH Rev. 2.3...

  • Page 3: Table Of Contents

    4.2 Operation under Linux (NTP) 4.2.1 NTP installation 4.2.2 NTP configuration 4.2.3 Starting NTP 4.2.4 Setup of a NTP daemon 4.3. V.24 protocols 4.3.1 Gude standard time protocol 4.3.2 Gude UTC time protocol 4.3.3 XNTP time protocol EMC Professional NET...
  • Page 4 5 Configuration 5.1 Automatic configuration by DHCP 5.2 Network configuration by GBL_Conf.exe 5.3 Configuration by Webinterface 5.4 IP Access Control List 5.5 SNMP 5.6 Syslog 5.7 Presentation of the recent configuration 6 Features 6.1 Bootloader mode 6.2 Firmware update 6.3 Technical information 7 Support Declarations Contact...

  • Page 5: Security Declaration

    Security declaration The device must be installed only by qualified personnel accord- ing to the following installation and operating instructions. The manufacturer does not accept responsibility in case of im- proper use of the device and particularly any use of equipment that may cause personal injury or material damage.

  • Page 6: Description

    1 Description EMC Professional NET (EMC Prof NET (19“)) provides ac- cess to one of the most exact working atomic clocks in the world. It is run by the Physikalisch-Technische Bundesanstalt (PTB) in Braunschweig/Germany. Time and date are broad- casted by the DCF77 long-wave sender in Frankfurt/Mainflingen in Germany on a frequency of 77,5 kHz.

  • Page 7: Hardware

    2 Hardware 2.1 Content of delivery The delivery includes:  EMC Prof NET (19“)  Power adaptor (EMC Prof NET) / Power cable IEC (EMC Prof NET 19“)  Serial Interface Cable (Sub-D)  Network cable  CD-ROM incl. software and manual ...

  • Page 8: Installation

    After power on the LC display shows the configuration and the version of the firmware. EMC ProNET V1.6 Config: Gude After a few seconds EMC Prof NET (19“) shows its IP address followed by the up-to-date time and date. EMC ProNET V1.6 D192.168.0.2...
  • Page 9 It looks for a proper radio signal. Approximatly after two minutes EMC Prof NET (19“) has received enough information to switch into the radio mode. Then it shows “F=...” in the display, which means the number of faulty received bytes within in the last ten minutes.

  • Page 10: Alignment Of The Active Antenna

    2.4 Alignment of the active antenna Local issues may have influ- ences on the received quality of the signal. Barriers like re- inforced concrete buildings or mountains may weaken the sig- nal, the electromagnetic fields of screens or motors may disturb the signal, too.
  • Page 11  Interferences may be exactly at 77,5 kHz or broadband interferences, which meet 77,5 kHz. Devices like moni- tors or devices using a power adaptor are known jam- ming sources. Do not place the antenna near by those objects.  Athmospheric interferences occur like shortwave radio in batches, up to a few seconds.

  • Page 12: Network Operation

    3 Network operation 3.1 EMC Prof NET (19“) as SNTP-Server Due to its integrated ethernet interface EMC Prof NET (19“) can be connected to a network and is able to act as a stand alone time server. The SNTP protocol allows client in the network to synchronize the time with EMC Prof NET (19“).

  • Page 13: Windows 9X/Nt/2000

    3.2.2 Windows 9x/NT/2000 While using Windows 9x/NT/2000 the easiest way to synchro- nize the internal PC clock with the EMC Prof NET (19“) is the tool Dimension 4 (D4). To synchronize the PC with EMC Prof NET (19“), click on the button Add.

  • Page 14: Linux

    3.2.3 Linux Under Linux, there are several ways to synchronize the PC clock with a network time server. This chapter shows how you can synchronize your PC clock with ntpdate and cron. Please check, if ntpdate is installed already. Therefor, please use the command „which ntpdate“.
  • Page 15 For a regularly synchronization, you have to create a cronjob. A cronjob is command, done by cron. We recommend to start ntp- date with the parameter „-s“. With „-s“ the command line output of ntpdate will be written into the systemlog. To create a cronjob, you have to start crontab -e.

  • Page 16: Operation Via Serial Interface

    4 Operation via serial interface EMC Prof NET (19“) offers a serial interface, additionally to the network ethernet interface. On the CD-ROM, you can find the tool w32EMC for Windows OS. For Linux you need the free toolset NTP. 4.1 Operation under Windows 4.1.1 Installation of the Software Put the CD-ROM „Drivers &...
  • Page 17 the PC. This feature is recommended in locations of bad receive, since the DCF signal may have errors and will look totally correct, although it is wrong.  Language Here you can change the language of w32EMC. Pos- sible languages are English and German Sync frequency ...

  • Page 18: Interface

    4.1.3 Interface At the w32EMC window (figure 11) you can see the following values: DCF77-State System time The time and date of your PC. Last received The last correct received DCF time and date. Operation mode It is indicated here if EMC Prof NET (19“) is in radio or in quarz mode: „Radio mode“...

  • Page 19: Logmode

    V.24 V.24 State The state of the data transfer of the serial interface is shown here: „active“/„active in ... seconds“: DCF time signals are re- ceived at serial interface of the PC. The system time is compared with DCF time. „No receive!“: There is no receive of signals at the choos- en serial interface.

  • Page 20: Operation Under Linux (Ntp)

    4.2 Operation under Linux (NTP) EMC Prof NET (19“) can be used with NTP under Linux. „NTP“ means Network Time Protocol. It is designed for the synchroni- zation of clients over TCP/IP. For the usage under Linux the V.24 output protocol has to be changed to XNTP (see chapter 5.3). 4.2.1 NTP installation For easy installation of NTP you can find the shell script make_ all.sh on the CD-ROM at „tools\linux\get_ntp“.

  • Page 21: Starting Ntp

    You have to enter the following lines into the file ntp.conf in order to receive the time and date information of EMC Prof NET (19“) regularly: server 127.127.8.0 prefer mode 12 logfile /var/log/ntp logconfig =all driftfile /var/log/ntp.drift This means, the time and date information of the device re- fclock-0 will be picked up by driver 12 of group 8.

  • Page 22: Setup Of A Ntp Daemon

    With „peers“ a table of the active referencee clocks can be dis- played. An asterisk at the beginning of a line (*) shows the up- to-date time referencee. remote refid st t when poll reach delay offset jitter ========================================================= *GENERIC(0).DCF. 0 l 0.000 2.846 0.008...

  • Page 23: Protocols

    +2 hours. 4.3.2 Gude UTC time protocol While using this v24. format, the time will be exported as UTC time. This protocol is coded like the Gude standard time protocol. More information can be found at http://www.gude.info/wiki. 4.3.3 XNTP time protocol The XNTP time protocol was developed for XNTP applications.

  • Page 24: Configuration

    For changing the network properties manually, the program GBL_Conf.exe is required. This tool is available for free on our website www.gude.info. Furthermore GBL_Conf.exe enables you to install firmware up- dates and to reset EMC Prof NET (19”) to its factory settings (see 5.2).

  • Page 25: Configuration By Webinterface

    5.3 Configuration by Webinterface Go to the website of EMC Prof NET (19”). Enter the IP address of EMC Prof NET (19”) into the address line of your internet browser: http://”IP address of EMC Prof NET (19”)”/ and press LOGIN. Figure 17 Login Now, an overview about the status of EMC Prof NET (19“) is displayed.
  • Page 26 Configuration - Clock LCD Display Here you can choose, which time format shell be displayed at the LC-Display of EMC Prof NET (19“). You can switch between CET/CEST and UTC. V.24 output protocol Here you can choose the format which shell be used by the RS232 interface.
  • Page 27 Configuration - IP Address Hostname Enter the host name of EMC Prof NET (19”). EMC Prof NET (19”) uses this name to connect with DHCP server. Special signs may destabilize your network. IP Address Here you can change the IP ad- dress of EMC Prof NET (19”).
  • Page 28 Configuration - IP ACL Reply ICMP-Ping requests Here you can set, if EMC Prof NET (19”) shell react on pings. Enable IP Filter Here you can activate the IP Ac- cess Control List (IP ACL) of EMC Prof NET (19”). If IP ACL is active, DHCP and SNMP only work, if all neces- Figure 21 Configuration - IP...
  • Page 29 Here you can download the MIBs of EMC Prof NET (19”). Use SNMP only if your network is fitted for. More information about the SNMP functions of EMC Prof NET (19”), you can find in chapter 5.5, on http://www.gude.info/wiki or ask our support team. EMC Professional NET...

  • Page 30: Ip Access Control List

    If you locked yourself out by mistake, please activate the boot- loader mode of EMC Prof NET (19“), start Gbl_Conf.exe and deactivate IP ACL. You can find more information about configuration of IP ACL in chapter 5.3 or have a look at http://www.gude.info/wiki. EMC Professional NET...

  • Page 31: Snmp

    At least, there are so called Object Identifiers (OID) subordi- nated to those three structures. An OID describes the location of an information inside a MIB. You can find more information about configuration of SNMP in Chapter 5.3 or have a look at http://www.gude.info/wiki. EMC Professional NET...

  • Page 32: Syslog

    - Switching of the relais You can find more information about configuration of Syslog in chapter 5.3 or have a look at http://www.gude.info/wiki. 5.7 Presentation of the recent configuration After power-up of EMC Prof NET (19“) you can see the IP address of the device in the display, when you press the Boot- loader button.

  • Page 33: Features

    EMC Prof NET (19”) that are in the network are listed. Select the one, that should be updated, click on Program De- vice→Firmware Update and determine the location of the new firmware. Please note: The up-to-date firmware and GBL_Conf.exe can be found at www.gude.info, free to download. EMC Professional NET...

  • Page 34: Technical Information

    6.3 Technical information EMC Professional NET Interfaces: Ethernet, potential free relais outlet, 9 Pin D-SUB (RS232), BNC Connector for active antenna Network: 10 MBit/s 10BaseT Ethernet Protocols: TCP/IP, NTP, HTTP, SNMP v1/v2c, Syslog Power supply: Power Adaptor (9V) Operating temperature: 5°C - 55°C Dimensions: 17 x 10,5 x 6,5 cm (L x B x H) Weight:...

  • Page 35: Support

    The up-to-date software and firmware you can download at www.gude.info. In case of further questions about installation and operation of EMC Prof NET (19“) please take a look at www.gude.info/ wiki and do not hesitate to contact our support team at mail@gude.info.

  • Page 36: Declarations

    Declarations Hereby, we confirm EMC Professional NET (19“) follows the restrictions of RoHS. EMC Professional NET...

  • Page 37: Contact

    Contact GUDE Systems GmbH Von-der-Wettern-Str. 23 51149 Koeln Tel.: +49-221-912 90 97 Fax: +49-221-912 90 98 E-Mail: mail@gude.info Web: www.gude.info...
