- Page 1 AeroScout Exciter EX2000BW User Guide EX2BW-UG-251108-01...
- Page 2 The information and know-how included in this document are the exclusive property of AeroScout Inc. and are intended for the use of the addressee or the user alone. The addressees shall not forward to another their right of using the information, know-how or...
-
Page 3: Table Of Contents
Table of Contents | 3 Table of Contents Introduction......................5 Application and Industry Examples..............5 LED Indications ......................7 Mounting the Exciter ..................8 Mounting the Exciter Using a Fixed Mount..............8 Mounting the Exciter Using a Flexible Mount ..............9 Mounting the Exciter Using a Ceiling Mount .............10 Exciter Specifications .................. -
Page 5: Introduction
AeroScout tags that can also be accurately located in real time by the AeroScout system. The Exciter triggers AeroScout’s tags as they pass through a choke point, and those transmit a message to AeroScout Location Receivers or compatible Access Points in range. - Page 6 Network connectivity Enables remote programming, monitoring and software updates by the AeroScout Engine. In addition, the Exciter can work in offline mode disconnected from the network, thus eliminating the need for a physical network feed. In this mode, remote configuration and monitoring is not enabled.
-
Page 7: Led Indications
Application and Industry Examples | 7 Figure 2. AeroScout Exciter EX-2000-BW LED Indications The front panel of the Exciter consists of three LEDs. Figure 3 describes these LEDs. Figure 3. LED Indicators Power – Green LED indicates that the unit is ON and connected to a power source. -
Page 8: Mounting The Exciter
8 | Mounting the Exciter Mounting the Exciter Mounting the Exciter Using a Fixed Mount The Exciter can be mounted on a wall using the fixed mounting bracket (provided with the Exciter). The mounting bracket includes five optional screw holes that can be mounted to a wall, a ceiling or any other placement as shown in Figure 4. -
Page 9: Mounting The Exciter Using A Flexible Mount
Mounting the Exciter | 9 Mounting the Exciter Using a Flexible Mount Wherever mounting Exciters with the fixed mount is not sufficient, you can use the flexible mount that provides both swiveling and tilting. Figure 6. Flexible Mount To mount the Exciter using the flexible mount: Remove the flexible mount’s cover. -
Page 10: Mounting The Exciter Using A Ceiling Mount
10 | Mounting the Exciter Figure 8. Attach fixed mount to the flexible mount Attach the Exciter to the fixed mount. Figure 9. Exciter attached to the flexible mount. Mounting the Exciter Using a Ceiling Mount A ceiling mount can also be attached to the Exciter’s fixed mount for mounting on false/acoustic ceilings (Ceiling mount is acquired separately). -
Page 11: Exciter Specifications
Exciter Specifications | 11 Exciter Specifications Range Adjustable range up to 6.5 m (20 feet) • Supports AeroScout Tags • Physical and Mechanical Dimensions: 220mm (8.6 inches) diameter, 115mm (4.5 inches) depth • Weight: 800g (28 oz.) • Network Interface Ethernet (RJ-45) •... -
Page 12: Safety And Warnings
12 | Safety and Warnings Safety and Warnings SAFETY AeroScout Exciters should always be professionally installed. A minimum distance of 50cm (20 inches) should be maintained between Exciters and critical medical care equipment in order to mitigate possible electromagnetic interference (EMI) issues. The electromagnetic... - Page 13 The date of shipment of a Product by AeroScout is set forth on the packaging material in which the Product is shipped. This limited warranty extends only to the original user of the Product. Customer's sole and exclusive remedy and the entire liability of AeroScout and its suppliers under this limited warranty will be, at AeroScout’s or its service center's option, shipment of a...
