STERIVALVE
Installation and operation manual
(Including welding guideline)
valves & instrumentation
16, rue Fresnel, F‐78310 COIGNIERES
Tél. +33 1 34 82 10 00
Fax +33 1 34 82 10 20
contact@eriks.fr ‐ www.eriks.fr
Sealing and rubber technology | Flow Technology | Industrial Plastics | Power Transmission and bearings | Tools, maintenance and safety products

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STERIVALVE 12 and is the answer not in the manual?

Questions and answers

Summary of Contents for Steridose STERIVALVE 12

  • Page 1 ® STERIVALVE Installation and operation manual (Including welding guideline) valves & instrumentation 16, rue Fresnel, F‐78310 COIGNIERES  Tél. +33 1 34 82 10 00  Fax +33 1 34 82 10 20  contact@eriks.fr ‐ www.eriks.fr  Sealing and rubber technology | Flow Technology | Industrial Plastics | Power Transmission and bearings | Tools, maintenance and safety products...

  • Page 2: Table Of Contents

    ---Table of Contents--- 1. Introduction 1.1 Safety information 1.2 Scope and Purpose 1.3 Main Components 1.3.1 Valve housing 1.3.2 Actuators 1.3.3 Diaphragms 2. Assembly 2.1 General 2.1.1 Valve housing to actuator connection 2.1.2 Diaphragm connection 2.2 Assembly Procedure 2.2.1 Pneumatically operated valves 2.2.2 Manually operated valves 2.2.3 Additional procedures for installation of PTFE diaphragms 2.2.4 Position Indicators...

  • Page 3: Introduction

    INTRODUCTION Safety information DANGER! The equipment may be operated and maintained only when this maintenance manual is thoroughly understood. Negligence to do so can result in personal injury and/or material damage. ® If the Sterivalve is part of a piping system, please note: DANGER! The system may be subject to overpressure, steam, hot water, vapors and chemicals.

  • Page 4: Valve Housing

    Figure 1: Main Components Sterivalve 12 (1/2”) to 38 (1.5”) Sterivalve 51(2”) and 76 (3”) 1.3.1 Valve housing The valve housing is made as standard of stainless steel AISI 316L. Each valve housing is marked with a respective lot number that links it with a specific material mill certificate.
  • Page 5 Figure 2: Standard Valve Housing Configurations Figure 3: Standard Sample Valve Housing Configurations Page 5 / 45 REV. STV20110519...

  • Page 6: Actuators

    1.3.2 Actuators The valve is provided with the following actuator types: Plastic Pneumatic Actuator 12 (1/2”) to 76 (3”) The plastic pneumatic actuator is made of PPE (polyphenylene ether) polymer. The actuators are sealed for life and are not serviceable. The actuator is provided as spring to close/air to open (normally closed).
  • Page 7 Stainless Steel Pneumatic Actuator 51 (2”) & 76 (3”) The stainless steel pneumatic actuator for valves 51 (2”) and 76 (3”) is sealed and not serviceable. The actuator is bolted to the housing. The pneumatic actuator is provided already pre-assembled with the adapter and adapter plate (see figure 6).

  • Page 8: Diaphragms

    1.3.3 Diaphragms The valve has three different diaphragm material options. Consult Steridose for availability of each material for any particular valve size. Diaphragm material selection is a function of chemical compatibility with the process fluid (s), including CIP solutions/steam, operational temperature and number of cycles.

  • Page 9: Assembly

    Assembly General When installing the valve sufficient clearance to remove/assemble the actuator must be considered. The amount of space required depends on valve size and actuator configuration. In order to ensure self draining, the valve must be installed in the correct position. See figures 10 and 11: Figure 10: Self draining positions for process valves The housing is self draining in these positions,...

  • Page 10: Valve Housing To Actuator Connection

    2.1.1 Valve housing to actuator connection The valve housing and actuator are connected with either a hygienic clamp union or bolts, as indicated below: Size 12 (1/2”): TC CLAMP 1"/ 1.5" Size 25 (1”): TC CLAMP 2.5" Size 38 (1 ½”): TC CLAMP 2.5"...
  • Page 11 Figure 13: Replacement of pressure plate type 1 for type 2 For valves 12 (1/2”) to 76 (3”), with PTFE diaphragm, no pressure plate is required in the valve stem. The PTFE diaphragm is provided with a threaded stud that will screw direct to the valve stem.

  • Page 12: Assembly Procedure

    Assembly Procedure 2.2.1 Pneumatically operated valves In order to install the pneumatic actuator to the valve, follow these steps: 1-Attach diaphragm to actuator stem, or screw the valve diaphragm to the actuator stem. Refer to section 2.1. 2-Actuate the actuator to the open position. If the actuator is set-up as normally closed, actuate the actuator to the open position.

  • Page 13: Additional Procedures For Installation Of Ptfe Diaphragms

    2.2.4 Position Indicators An assortment of models and styles of instrumentation are available to sense the actuator position. Listed below are some of the most common. Please consult Steridose to determine the best solution to your particular application. 2.2.4.1 Stainless Steel Pneumatic Actuators For valves 12 (1/2”), 25 (1”), and 38 (1-1/2”)
  • Page 14 In order to assemble open micro-switches follow these steps: Add/remove any required adapters or sensors from top of actuator. 2. Screw the electrical position indicator in and adjust so that when the actuator is open the sensor switch is activated. 3.
  • Page 15 For valves 51 (2”) and 76 (3”) The stainless steel pneumatic actuator for 51(2”) and 76 (3”) valves can be provided with inductive switches for sensing open and closed position. The same actuator is used with or without switches. A plastic sensor holder is added to the actuator and the sensors are screwed to each mounting bracket as shown on figure 16.

  • Page 16: Plastic Pneumatic Actuators

    2.2.4.2 Plastic Pneumatic Actuators For valves 12 (1/2”), 25 (1”), 38 (1-1/2”), 51 (2”), and 76 (3”) The sensors available are: Open, micro-switch Open/Close, micro-switch Open, inductive proximity switch Open/close, inductive proximity switch In order to assemble switches follow these steps: 1.

  • Page 17: Operation

    OPERATION 3.1 Pneumatically operated Valve The pneumatically operated actuator type S-A is opened when pressurized and closed otherwise. The pneumatically operated actuator type A-A is opened when the lower connection is pressurized and closed when the upper connection is pressurized. DANGER! Always make sure that the surrounding system is de-pressurized before opening a valve to atmosphere or non-pressure vessels.

  • Page 18: Maintenance/Service

    It is recommended that the pneumatic actuators 12 (1/2”), 25 (1”) and 38 (1 ½”) are returned to Steridose for repair. Pneumatic actuators 51 (2”) and 76 (3”) are sealed and not serviceable. All plastic Pneumatic actuators and manual stainless steel actuators are also sealed and not serviceable.

  • Page 19: Actuators

    4.3 Actuators 4.3.1 Manual Actuator The manual actuator does not need any maintenance or service. Visual inspection every 12 months is recommended. 4.3.2 Pneumatic Actuator General The pneumatic actuator requires inspection every 12 months. The following components shall be inspected: 1- Inspect pneumatic tubing and replace if damaged.
  • Page 20  STERIVALVE Table 2: Sterivalve 12 (1/2") S-A  STERIVALVE 12 (1/2”) S-A Part # 104156 Pos: Qty: Description: Material: Dimension: Note: O-ring Viton 16.1x1.6 X-ring Viton 9.25x1.78 Compact seal Nitril O-ring Viton 34.65x1.78 O-ring Viton 3.1x1.6 Pressure plate 316 L ...

  • Page 21: Diaphragms

    Diaphragms 4.4.1 Interval of diaphragm inspection The service life to the valve diaphragm depends on its working conditions. Important factors with regard to the service life are temperature and the type of process and CIP fluid (s). In general, inspection should be made at every 50 hours of sterilization (e.g. exposure to steam or superheated water) or 1000 hours of operation, whichever occurs first.
  • Page 22 ® ® Sterivalve 12 (1/2”), 25 (1”) and 38 (1 ½”) Sterivalve 51 (2”) and 76 (3”) 1. Open the valve, manually or pneumatically. 1. Open the valve, manually or pneumatically. 2. Unscrew the clamp with the wing-nut and separate 2.

  • Page 23: Troubleshooting

    TROUBLESHOOTING Trouble Description Possible cause Remedial action Manual valve does not 1. Diaphragm is stuck on valve seat. 1. Inspect diaphragm and replace if open when actuator is 2. Diaphragm is not mounted properly required. turned counterclockwise on the actuator. 2.

  • Page 24: Technical Specifications

    TECHNICAL SPECIFICATIONS Design data for complete valve Design temperature Sterivalve 12, 25 & 38 Sterivalve 51 & 76 ® ® (1/2”), (1”) & (1 ½”) (2”) & (3”) Sterilization In Place (SIP) Max 135° C (at 1 hour) Max 135° C (at 1 hour) Autoclave Max 135°...
  • Page 25 Surface treatment Sterivalve 12, 25 & 38 Sterivalve 51 & 76 ® ® (1/2”), (1”) & (1 ½”) (2”) & (3”) __________________________________________________________________________________________ Internally High grade polished High grade polished Ra 0.5 μm or better Ra 0.5 μm or better Externally Ra 0.8 μm Ra 0.8 μm Operating data for pneumatic actuator...
  • Page 26 STERIVALVE PARTS LIST 7.1 Sterivalve 12 (½”) Diaphragms Part # Designation Description Picture 103477 NP3006837 EPDM diaphragm - FDA 111164 EPDM diaphragm – USP Class VI 103476 NP3002694 Silicone diaphragm – USP Class VI 110646 PTFE diaphragm – USP Class VI...
  • Page 27 Valve Housings Part # Designation Description Picture 108928 ASTM shut off body w/TC connect – new style 110555 ASTM shut off body w/TC connect – old style 108960 ASTM flow-thru body w/TC connect – new style 110024 ASTM flow-thru body w/TC connect – old style 107205 ASTM TC connectable, double outlet 107322...
  • Page 28 7.2 Sterivalve 25 (1”) Diaphragms Part # Designation Description Picture 103479 NP3001941 EPDM diaphragm – FDA 111165 EPDM diaphragm – USP Class VI 103478 NP3000743 Silicone diaphragm – USP Class VI 105016 PTFE diaphragm – USP Class VI Actuators Part # Designation Description Picture...
  • Page 29 Valve Housings Part # Designation Description Picture 108936 ASTM shut off body w/TC connect – new style ASTM flow-thru body w/TC connect – new 108968 style 107225 ASTM bottom outlet, 45° TC, single outlet 107211 ASTM bottom outlet, 45° TC, double outlet 108411 ASTM bottom outlet w/1/2”...
  • Page 30 7.3 Sterivalve 38 (1-1/2”) Diaphragms Part # Designation Description Picture 103481 NP2006668 EPDM diaphragm – FDA 111166 EPDM diaphragm – USP Class VI 103480 NP2010310 Silicone diaphragm – USP Class VI 105651 PTFE1.5 PTFE diaphragm – USP Class VI Actuators Part # Designation Description...
  • Page 31 Valve Housings Part # Designation Description Picture 108893 ASTM shut off body w/TC connect ASTM flow-thru body w/TC connect – new 108976 style 107251 ASTM bottom outlet, 45° TC, single outlet 107237 ASTM bottom outlet, 45° TC, double outlet Page 31 / 45 REV.
  • Page 32 7.4 Sterivalve 51 (2”) Diaphragms Part # Designation Description Picture 127742 NP1010647 Teflon diaphragm, including support gasket Actuators Part # Designation Description Picture 110232 NP3010534 Manual handle, SS 110155 Pneumatic actuator, spring/air – SS 110537 Pneumatic actuator, spring/air - plastic 109829 NP1010323 Pneumatic actuator spring/air (cylinder only) - SS...
  • Page 33 7.5 Sterivalve 76 (3”) Diaphragms Part # Designation Description Picture 127743 NP1010675 Teflon diaphragm, including support gasket Actuators Part # Designation Description Picture 110243 NP1010659 Manual handle, SS 110214 NP1010743 Pneumatic actuator, spring/air – SS 110539 Pneumatic actuator, spring/air - plastic 109830 NP1010743 Pneumatic actuator spring/air (cylinder only) - SS...

  • Page 34: Traceability And Conformity Information

    8. Traceability & Conformity information All wetted components in the Sterivalve are traceable and marked with a batch number. All wetted components are provided with certificates of compliance with regards of the materials of constructions. Valve housing All valve housings are provided with the part number and batch number etched to the outside of the valve housing.
  • Page 35 Declaration of EC Conformity We herewith declare, the Pneumatic actuators used on different Bürkert types meet the requirements given in the European Directives for ATEX Directive (94/9/EG) Pressure Directive (97/23/EG) For the assessment of the products according to the ATEX the European Standard EN 13463-1:2002 Non electrical equipment for the use in Hazardous Locations was used.
  • Page 36 Declaration of EC Conformity Herewith we declare, that the supplied products meet all requirements laid down in the following European Directives: · Low voltage installations with rated voltage 50 - 1000 V/AC respective 75 - 1000 V/DC (Directive 73/23 EEC) ·...

  • Page 37: Contact Information

    Our mission is to enable our customers to achieve a market leading position by being the most competent Mag Drive Mixing solution partner. Steridose is known for its client’s integrity and proactive approach with involvement stretching beyond our customer’s expectations.

  • Page 38: Appendix A: Welding Guide

    APPENDIX A: Welding Guide 1. Placement of the valve housing The valve housing is usually placed according to the figure below, but other locations may exist. Therefore the relevant vessel drawings should be checked in order to determine the desired location.
  • Page 39  Tack weld the valve housing with a TIG-welder from the outside. The correct filler depends on the material in the dished end and valve housing. For a dished end and valve housing of 316L filler Avesta 316L (SKR), 316L-Si/SKR-Si or similar type may be used. ...
  • Page 40 APPENDIX B: Indicator systems 1. Position Indicators for Stainless Steel actuator size 12 (1/2”) to 38 (1½”) 1.1 Single induction switch The electrical position indicator indicates open position of the valve. It is threaded to the top of the pneumatic actuator. Technical specifications Model IFB3002-BPKG/V4A/US...
  • Page 41 1.2 Single micro switch The electrical position indicator indicates open position of the valve. It is threaded to the top of the pneumatic actuator. This indicator contains a micro switch with snap action contact mechanism designed for up to switching operations. The silver contacts are gold plated. The housing can be rotated through 360°.
  • Page 42 1.3 Double micro switch The electrical position has two micro switches that indicate both open and close position. It is threaded to the top of the pneumatic actuator. Both micro switches can be continuously and precisely adjusted, independent of each other, via thread spindles.
  • Page 43 2. Position indicators for Plastic Pneumatic actuators (all sizes) The electrical position feedback is installed on the valve actuator. Valve positions are remotely reported electrically according to switch type: - open, closed (version with a limit switch) or - open and closed (version with two switches or a double limit switch) LEDs provide optical position indication (except with the inductive 2-wires version).
  • Page 44 Dimensions – [mm] Page 44 / 45 REV. STV20110519...
  • Page 45 3. Inductive switches for Stainless Steel actuator size 51 (2”) and 76 (3”) The inductive switches are mounted on a plastic holder mounted on the actuator. Technical Specifications Diameter [mm] Length [mm] Operating voltage 10-30 VDC Connection type [mA] pnp-L Sensing range [mm] Thread...
