Features of CPE-S110 Projector
ICC (Independent Color Control)
In order to help users to resolve problems in adjusting whole colors, CPE-S100 Projector enables
users to adjust the intended colors to be controlled independently, such as red, green, blue and
yellow.
i-Brightness
i-Brightness complements both brightness and contrast of the dark screen simultaneously.
This function is designed to resolve fundamental problem that projecting screen gets darker when
DVD is inserted in the computer.
You may adjust the brightness and contrast conveniently using the shortcut key on the remote
controller or the control panel on the projector without having to control the brightness and contrast
in a separate way.
PIP / POP
In case you need to show two screens simultaneously, PIP overlaps two screens, whereas POP
shows two screens evenly (1:1).
You may freely adjust the size of each screen when the PIP/POP function is implemented.
Color Mode
Since 5 pre-defined user modes are provide, you may need to make complex color control, which is
optimized for the operational environment.
You can select a mode that best matches with the projecting image out of five pre-defined modes.
- Standard mode
- Cinema mode
- P.T mode (Presentation Mode)
- Sport mode
- Game mode
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CPE-S110 and is the answer not in the manual?

Questions and answers

Summary of Contents for EXTRAMA CPE-S110

  • Page 1 Features of CPE-S110 Projector ICC (Independent Color Control) In order to help users to resolve problems in adjusting whole colors, CPE-S100 Projector enables users to adjust the intended colors to be controlled independently, such as red, green, blue and yellow.

  • Page 2: Table Of Contents

    Table of Contents Safety Precautions ........................3 Symbols ..............................3 Precautions on Installation ........................4 Precautions on Power Supply......................... 4 Precautions on Usage and Miscellaneous....................5 Product Description ........................7 ........................... What's Inside Names and Functions of Projector Unit ....................8 Remote Controller ..........................

  • Page 3: Safety Precautions

    Safety Precautions Symbols Symbols and descriptions in this manual are designed to prevent possible injuries and product damages through safe projector using guide. Please comply with the instruction. Warning Ignoring warning messages may result in serious injuries or fatal product damages. Caution Ignoring caution messages may result in slight injuries or product damages.

  • Page 4: Precautions On Installation

    Safety Precautions Precautions on Installation Warning 1. Be careful not to drop foreign objects into the holes of the projector. Moreover, do not spill liquid into the projector. 2. Do not place any breakable objects, liquid cans, medical supplies or any other similar objects near by the product.

  • Page 5: Precautions On Usage And Miscellaneous

    Safety Precautions Precautions on Power Supply Warning 1. Use the voltage indicated on the projector only. If you use the voltage other than specified, fire may break out or you may be struck by electricity. 2. Do not place heavy objects on the power cord. 3.
  • Page 6 Safety Precautions Precautions on Usage and Miscellaneous Caution 1. If you plan not to use the projector for a long time, plug out the power cord for your safety. Fire may break out. 2. Do not remove a lamp after using the projector. Turn off the power and wait until it cools down sufficiently.

  • Page 7: Product Description

    Product Description What's Inside See if the following components are included in the product package. If you find anything is missing, consult the authorized dealer or the service center. Projector carry-on case Projector Remote controller (including a shoulder strap) (including CR2025 lithium battery) Power cord S-Video cable Video cable...

  • Page 8: Names And Functions Of Projector Unit

    Product Description Names and Functions of Projector Unit < Front side > Remote sensor Lens Adjustable foot Adjustable foot Lens cap < Rear side > Remote sensor Power switch AC power input terminal Safety locking device Exhaust vents Product Description...
  • Page 9 Product Description Names and Functions of Projector Unit < Left side > S-Video terminal RS-232C Air inlet Video terminal Computer connection terminal <Top surface and control panel> Yellow lamp : When the lamp is not in the projector or fan is disconnected, the yellow lamp blinks. (Indicates a fan malfunction) Lamp indicator: Yellow : On standby mode.

  • Page 10: Remote Controller

    Product Description Remote Controller Power button Input Select button (Switches between S-Video PIP : Two screen button. VIDEO Computer) Use this button to project two screens at a time. POP : Displays the video and com- ESC button puter screen with the same size. Moves to the upper menu when the menu screen is available.

  • Page 11: Installing The Projector

    Installing the Projector Installing the Projector The projector should be placed so that the center line of the lens is at a right angle to the screen as in the following figures. Use the adjustable foot to control the angle of the projector. (See page 17.) Seen from the side Seen from the top Projection Distance and Screen Size...

  • Page 12: Connecting To The S-Video Signal

    Installing the Projector Connecting to the S-Video Signal Always turn off the projector before connecting to the video device in order to protect the device connected to the projector. DVD/VCR S-VIDEO Cable Camcorder Turn off the projector and device connected to the projector. Connect the S-video output terminal for DVD, TV, camcorder or set-top box to the projector S-video output terminal, using the provided S-video cable.

  • Page 13: Connecting To The Pc

    Installing the Projector Connecting to the PC Always turn off the projector before connecting to the PC in order to protect the PC connected to the projector. Projector IBM VGA or compatible (laptop or desktop PC) 15-pin D sub signal cable Check to see if the computer power is off and the power switch located at the rear side of the projector is also turned off.

  • Page 14: Connecting To The Power Cord

    Installing the Projector Connecting to the Power Cord Never look into the lens after turning on the projector. Your vision can be impaired due to strong light. Do not project with lens cap on. The lens cap may be deformed by heat. See if the projector and connected device are turned off.

  • Page 15: Basic Operations

    Basic Operations Power On Press the power switch on located at the rear side of the projector. (The power indicator will light up with red color and the projector will be standby mode.) < Projector > Press the Power button( ) on the remote controller or the top surface of the projector.

  • Page 16: Adjusting Projected Image Size (Optical Zoom)

    Basic Operations Adjusting Projected Image Size (Optical Zoom) The projected image size varies depending on the distance between the screen and the projector. To adjust screen size in the optimal state, check the projected distance range by screen size and adjust the distance using the optical zoom function.

  • Page 17: Adjusting The Image Angle

    Basic Operations Adjusting the Image Angle Lift up the front side of the projector until the intended angle is obtained. Then, press down the adjustable foot button with both hands. The front foot will be ejected. Release the adjustable foot button when the front foot is ejected as much as you want. If you want to take the foot back, put down the projector while pressing down the adjustable foot button.

  • Page 18: Removing The Trapezoidal Position Of The Image (Keystone)

    Basic Operations Removing the Trapezoidal Position of the Image (keystone) If you install the projector with a specific angle suing the adjustable foot lever of the projector, the projected image may get distorted in trapezoid form. You can adjust the projected image if it can be adjusted within approximately 15"...

  • Page 19: Adjusting The Computer Image

    Basic Operations Adjusting the Computer Image Press the Auto button on the remote controller. When the computer signal is entered, phase, frequency and position will be automatically adjusted to the optimal state. You can use this function only when the input signal of the projecting device is a computer.
  • Page 20 Basic Operations Power Off (continue) Press the Power button( ) again. The lamp will be turned off and the power indicator will blink with yellow color. The projector will enter into the cool down mode. (Duration of the cool down mode varies depending on the surrounding temperature.) When the power indicator is on with yellow color continuou- <...

  • Page 21: Adjustments

    Adjustments Setting and Adjusting the Menus You can adjust or set the video or computer images using the remote controller of the menu function of the control panel located on the top surface of the projector. This chapter describes how to adjust or set the projector using a remote controller. Use the projector adjustment function after running the projector more than 3 minutes.

  • Page 22: How To Use The Menu On The Remote Controller

    Adjustments How to Use the Menu on the Remote Controller Press the MENU button on the remote controller. The main menu will appear on the projector screen. Press the button to select the icon you want (main screen menu) The selected icon menu will be displayed brighter. Press the Enter ( ) button.

  • Page 23: How To Use The Menu On The Control Panel

    Adjustments How to Use the Menu on the Control Panel Press the MENU button( ) on the control panel located on the top surface of the projector. The main menu will appear on the projector screen. Press the ) or ) button to select the icon you want (main screen menu) The selected icon menu will be displayed brighter.

  • Page 24: Shortcut Key Functions

    Adjustments Shortcut Key Functions You can use several functions for adjustments by selecting the following shortcut key once on the remote controller or the control panel of the projector. Icon Control Remote Function Description Panel Menu controller You can select a projected input signal among several projector input signals.
  • Page 25 Adjustments Shortcut Key Functions (continue) Icon Remote Control Function Description Menu controller Panel Use this button to automatically adjust phase, frequency and position of the computer input. 1) Press the Auto button. Auto Phase, frequency and position will be automatically adjusted. Use this button to set the active window for the currently projected screen, in order to adjust screen size or position.

  • Page 26: Image Adjustments

    Adjustments Image Adjustments Icon Menu Function Description Adjusts screen brightness. button: Screen becomes darker. Brightness + button: Screen becomes brighter. Compensates for the dark screen when displaying the movie file in the PC. Screen becomes brighter and contrast sharpens. , + button: Enable / Disable toggle button. Enable: i-Brightness function is activated.
  • Page 27 Adjustments Image Adjustments (continue) Icon Menu Function Description Adjusts depth of color (saturation). button: Screen color becomes light. Saturation + button: Screen color becomes dark. Adjusts balance between green and red color while not changing the blue color. button: Red color is added to the image. + button: Green color is added to the image.

  • Page 28: Screen Adjustments

    Adjustments Screen Adjustments Icon Menu Function Description Adjusts screen size when the upper side and the lower size mismatch in size depending on the projection angle. Keystone button: The lower screen part becomes narrower. + button: The upper screen part becomes narrower. Selects the screen aspect ratio.
  • Page 29 Adjustments Screen Adjustments (continue) Icon Menu Function Description Displays the small computer screen on the video screen or small video screen on the computer screen. +: Changes from Video Computer V on C C on V Video: Video screen will be displayed on the entire screen. Computer: Computer screen will be displayed on the entire screen.

  • Page 30: Menu Adjustments

    Adjustments Menu Adjustments Icon Menu Function Description Size Selects the menu screen size - normal or double. Normal: Sets the normal menu screen. Double: Sets the menu screen two times bigger than the normal Display menu screen. Grid Normal: The menu screen will be displayed normally. Grid: The menu screen will be displayed with a grid format.

  • Page 31: Tuning Adjustments

    Adjustments Tuning Adjustments Icon Menu Function Description Corrects noise to the horizontal direction when displaying the computer input. Phase Press the " " or "+" button for adjustment until noise is removed. This function is enabled only when the input signal comes from the computer.

  • Page 32: Automatic Adjustments

    Adjustments Automatic Adjustments Icon Menu Function Description Automatically detects the projector input signal. (Default: Off) +: Enables the automatic adjustment function. Auto Press the INPUT button on the remote controller or the INPUT/ESC button on the control panel to change the projector input signal.

  • Page 33: Troubleshooting

    Troubleshooting The following table describes the problems that can occur while using the projector or installing the projector as well as its resolution. Before consulting your authorized dealer, please check the following points. Symptom Probable Cause and Corrective Action Page The warning lamp blinks every Lamp is not available.
  • Page 34 Troubleshooting Symptom Probable Cause and Corrective Action Page Video image does not appear. 12,13 See if the signal is being received. See if the cable for projection is properly connected. See if the power saving function is enabled in case of the computer input.
  • Page 35 Troubleshooting Symptom Probable Cause and Corrective Action Page Color is poor or unstable. Adjust ICC or hue. Adjust saturation. Adjust brightness and contrast. Video seems reversed in left/right Adjust screen flip. or up/down position. The upper part of the video image 9,10 Use the Keystone button on the remote controller or bows or distorts.

  • Page 36: Miscellaneous

    Miscellaneous Specifications Model Name CPE-S110 Type of Input Input Resolution: VGA ~ XVGA PC Input Signal Vertical frequency: 56 ~ 85Hz Color System NTSC, PAL, SECAM (Automatic switching) Display Method 3 panel transmitted light type Panel Size Emission Method TFT active matrix...

  • Page 37: Standard Signal Table

    Miscellaneous Standard Signal Table Horizontal Vertical Clock Sync. Mode Resolution Frequency Frequency Frequency Polarity (kHz) (Hz) (MHz) (H / V ) 37.861 85.080 31.500 640 350 37.927 85.039 35.500 720 400 31.469 59.940 25.175 640 480 37.861 72.809 31.500 640 480 37.500 75.000 31.500...

  • Page 38: Maintenance And Repair

    Miscellaneous Maintenance and Repair Cleaning Clean the projector if it is dirty or the projected image quality is degraded. Read the safety precautions carefully and comply with instructions before cleaning the projector. Make sure to turn off the projector and remove the power cord before cleaning the projector.

  • Page 39: Cleaning The Air Filter

    Miscellaneous Cleaning the Air Filter If dirt has gotten in or blocked by the foreign objects, ventilation performance will be degraded and can cause a malfunction due to overheat inside the project. Clean dirt and foreign objects using a vacuum cleaner or replace with new one. Air Filter Replacing the Air Filter If you cannot remove dirt and foreign objects using a vacuum cleaner, replace the air filter.

  • Page 40: Time To Replace The Lamp

    Miscellaneous Time to Replace the Lamp Please purchase the new lamp unit under the following circumstances. The projector lamp is not turned on or the screen disappears while it is in use. Brightness and the quality of the projected image is deteriorated compared wit the initial usage. The life of the lamp currently used for this projector is about 3000 hours.
  • Page 41 Miscellaneous Time to Replace the Lamp (continue) Push the lamp cover to the arrow direction to remove it from the projector. Loosen the two screws with a (+) screwdriver. Remove the lamp unit. Hold the handles at both sides of the lamp and pull it up to remove from the projector.

  • Page 42: Customer Service Information

    Customer Service Information If the EXTRAMA you use is not working properly or cannot solve the problem using the troubleshooting points in this instruction, contact the customer service center as described below. Customer Support Center +82+080-263-0914 Free call number EXTRAMA www.extrama.co.kr...

  • Page 43: Warranty Card

    FCC RF INTERFERENCE STATEMENT NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
