CPT CPDP-104 Assembly Instructions Manual

Circle guide for drill press
Hide thumbs

Advertisement

Quick Links

Download this manual
Circle Guide For Drill Press
Model CPDP-104
Web Site: www.circleperfecttools.com
Facebook: www.facebook.com/circleperfecttools
Tutorials: www.circleperfecttools.com/#!VIDEOS/c20ku
FAQ: www.circleperfecttools.com/#!faq/cavw
Contact Us: info@circleperfecttools.com
©2014 Circle Perfect Tools, LLC. All rights reserved

Advertisement

loading
Need help?

Need help?

Do you have a question about the CPDP-104 and is the answer not in the manual?

Questions and answers

Summary of Contents for CPT CPDP-104

  • Page 1 Circle Guide For Drill Press Model CPDP-104 Web Site: www.circleperfecttools.com Facebook: www.facebook.com/circleperfecttools Tutorials: www.circleperfecttools.com/#!VIDEOS/c20ku FAQ: www.circleperfecttools.com/#!faq/cavw Contact Us: info@circleperfecttools.com ©2014 Circle Perfect Tools, LLC. All rights reserved...

  • Page 2: General Safety Rules

    GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how to use a tool. WARNING: To avoid mistakes that could cause serious injury, do not attach Circle Guide For Drill Press until you have read and understood the following: READ and become familiar with the entire installation instructions on how to attach Circle Guide For Drill Press.
  • Page 3 ASSEMBLY UNPACKING This product requires assembly WARNING: Carefully remove the product and any accessories from Do not attempt to modify this product or create the box. Makes sure that all items listed in the packing accessories not recommended for use with this list are included.
  • Page 4 ASSEMBLY INSTRUCTIONS Step 1 - Aligning Drill Press Chuck and Drill Press table Set Drill Press Table approximately 6 inches from the Drill Press chuck. Align Drill Press Table with Drill Press chuck. Once aligned, lock table with table lock. Step 2 - Attaching Table Mount Attach Table Mount to Drill Press table using 1/4 inch connector...
  • Page 5 Step 4 - Inserting Center Pin Insert Center Pin thru the bottom of Slide Plate in the pocket closest to the drill channel. Make sure Center Pin is flush with the bottom of Slide plate. Step 5 - Attaching Slide Plate Slide the Slide Plate between the two alignment plates that are mounted on Table Mount.
  • Page 6 Step 7 - Inserting Alignment Pin and securing Slide Plate Insert short Alignment Pin into the Left Alignment Plate at the "For Black Scale" position. Slide the Slide Plate to the 5 inch mark of the Left Alignment Plate. Seat the Alignment Pin into the Slide Plate.

  • Page 7: Basic Operations

    Basic Operations Preparing Material The Circle Guide tool requires the rotation of material around a Center Pin. Please perform these basic steps before drilling to prepare your material. Step 1: Drill a 1/8" (English) or 3mm (Metric) hole in material which will be the center point of your circle. Drill the hole as perpendicular as possible to ensure precise rotation around the Center Pins.
  • Page 8 Drilling Holes in Material (with Degree Gears) After preparing the material you can proceed to setting up the Circle Guide and Drill Press. Step 1: Start by releasing the Alignment Pin and loosening the Lock-Down Bolt. Step 2: Move the Slide Plate away from the drill bit until it is stopped by the Lock-Down Bolt. Step 3: Insert the desired drill bit into the Drill Press.
  • Page 9 Using Set Measurements The Circle Guide for Drill Press provides the ability to lock in the radial distance at set measurements every 1/16" (English) or 2mm (Metric). This operation provides precise repeatability by allowing operator to recall to a prior position. Step 1: Loosen the Lock-Down Bolt and release Alignment Pin.
