RICOH Americas Corporation
Introduction
Model Type
Launch Date
Serial Number
Prefix
Product Code
Brand/Model Name
Product Code
M132
Product Concept
Hardware
Productivity:
50ppm (A4,LT/LEF)
New features/functions:
Color of machine's outer frame changed to dark gray, in
4.3 inch LCD touch panel for easier machine operation
Note: From a hardware perspective,
This model is a fusion of the G179 and D129/D130.
Compared to these predecessor models, only minor changes
have been applied to the hardware and internal layout.
Connectivity/Software support
This is a Spring 2012 model, which has the same connectivity specification as Autumn 2011
models.
Security
There are no new security features.
Ver.2.0
Product Support Guide
Model M132
B/W Printer
11-12-2012
T42
M132
Lanier
SP 8300DN
Aficio SP 8300DN
accordance with New PDI design concepts.
Page 1 of 23
Subject to change without notice
Content ID# 054904
Ricoh
Savin
SP 8300DN
11/9/2012
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ricon M132
Summary of Contents for Ricon M132
-
Page 1: Model Type
RICOH Americas Corporation Content ID# 054904 Product Support Guide Model M132 Introduction Model Type B/W Printer Launch Date 11-12-2012 Serial Number Prefix Product Code M132 Brand/Model Name Product Code Lanier Ricoh Savin M132 SP 8300DN Aficio SP 8300DN SP 8300DN... -
Page 2: Main Frame
Product Support Guide Model M132 Main Frame Item Model Name EDP Code Notes Lanier SP 8300DN Comes Standard with M132 Ricoh Aficio SP 8300DN Savin SP 8300DN NOTE: Order Numbers are provided for reference purposes only. Please use your Pricing Guide for proper order numbers to insure you receive the correct branding emblem. - Page 3 Product Support Guide Model M132 Product Item Description EDP Code Common / Unique Notes Code 1000 Sheet Finisher SR3090 415804 D588-17 C (D129) Finisher 3000 Sheet Finisher SR3120 416008 D636-17 C (D129) Finisher Punch Unit Punch Unit PU3030 416325 D570-00...
- Page 4 The yield figures for the maintenance kits are based on the following conditions: A4 (LT/SEF) 5% image coverage ratio 5 prints/job Note: The only change made to the Maintenance Kit A for the M132 was the color of the outer frame (changed to dark gray). Ver.1.0 Page 4 of 23...
-
Page 5: Main Frame Configuration
Product Support Guide Model M132 Option Compatibility 1. 2 Tray Bank 2. LCIT PB3140 3. LCIT RT3020 4.Bridge Unit 5. Finisher SR3090 6.500 sheet Finisher 7. Finisher SR3120 8. FAC56 Cabinet X: Cannot be installed together M: Must be installed together in RAC Market Branding Information Branding is required as the machines are shipped as a generic version. -
Page 6: Mfp Options
Product Support Guide Model M132 MFP Options : Symbol: : Unique option, : Option also used with other products Item Callout Machine Code Main M132 M132 Frame Two-Tray Paper Feed Unit [ 2 ] D5 8 0 2000-sheet LCT [ 3 ]... - Page 7 Product Support Guide Model M132 Item Callout Machine Code IPDS Unit M4 1 6 VM Ca r d D6 4 0 M394 (NA) Gigabit Ethernet IEEE 802.11a/g, g M3 4 4 IEEE 1284 B6 7 9 NOTE: 1. The finisher requires the bridge unit and two-tray paper feed unit or 2000-sheet LCT. The 1000- sheet finisher and 3000-sheet finisher cannot be installed together.
-
Page 8: Installation Requirements
Product Support Guide Model M132 M132 G179 Standard 550 Sheets x 2 trays 550 Sheets x 2 trays Bypass 100 Sheets 100 Sheets Max Capacity 4,400 Sheets 4,400 Sheets Paper Input 550 Sheets x 2 trays 550 Sheets x 2 trays... -
Page 9: Power Requirements
Product Support Guide Model M132 Power Requirements Input voltage level: 110 - 127 V, 60Hz:more than 12A. Do not place anything on power cord. The required wall outlet is a NEMA 5-15R (receptacle). Space A(Front) Over 750 cm (29.6”) B(Left) 10 cm (4") -
Page 10: Installation Times
Product Support Guide Model M132 Power Consumption / Noise Emission Power Consumption Power consumption BTU/hr 1550W or less 5288.82 Energy Saving 3.5W or less 11.94 Noise Emission Main Unit Compete System Stand by Less than 48db (Guaranteed Value) Less than 48db (Guaranteed Value) - Page 11 Product Support Guide Model M132 Storage/Transportation Storage Transportation -30℃ to 40℃ (22 F to 104 F) 15%～85%RH -30℃ to 50℃ (22 F to 122 F ) 15%～95% Mainframe Toner* Under 50℃ (122 F) 15%～80%RH Under 50℃ (122 F )15%～80%RH Remarks for Toner: NOTE: * Store in a dry, dark place where temperature does not exceed 45℃...
- Page 12 Product Support Guide Model M132 Q’ty/ Unique or Part Number Description PM Interval Unit Common AE045099 Cleaning Web 160K C (G147) AE040099 WEB Holder Roller 320K C (G147) B0654247 Brake Pad 320K C (G147) Special Tools & Lubricants Item Part Number Description Q’ty...
- Page 13 Product Support Guide Model M132 M132 First Print 3.5 sec or less (A4/LT LEF) Warm-up 25 sec or less Controller Processor RM7035C-533L 533MHz Spec Memory STD/MAX STD: 512MB MAX: 1024MB 120GB (Option) Resolution 600/300/200 dpi Interface USB2.0(TypeA 2port & B) , Ethernet(100BASE-...
- Page 14 Product Support Guide Model M132 M132 Legal SEF, Foolscap SEF, Government LG SEF, Folio SEF, F/GL SEF, G LT SEF/LEF, Eng Quatro SEF/LEF, Executive SEF/LEF, Com10 SEF/LEF, Monarch SEF/LEF, C5 SEF/LEF, C6 SEF/LEF, DL env SEF/LEF, 12"x18", 11"x15", 11"x14", 10"x15", 10"x14"...
- Page 15 Product Support Guide Model M132 MFP Supported Environments Windows Environments Type PCL5e PCL6 PostScript3 Professional Windows XP Home Edition Standard Edition Enterprise Edition Windows Server 2003 Datacenter Edition Web Edition Standard Edition Enterprise Edition Windows Server 2003 Datacenter Edition Web Edition...
- Page 16 Product Support Guide Model M132 Windows Environments Vista Professional Server & Advanced Server W2K Pro Windows XP Vista Professional W2K Pro Windows Vista Vista W2K Pro Terminal Service & Citrix MetaFrame Server Driver PCL5e/6 Windows Server 2008 Windows Server 2008 R2...
-
Page 17: Utility Software
Product Support Guide Model M132 Mac OS PostScript3 Printer Utility for MAC Mac OS 8.6 or later, Mac OS X classic Mac OS X Native : v. 10.4 ~ 10.7 or later UNIX Filter Unix Platforms Version Sun Solaris 2.6 / 7 / 8 / 9 /10 HP-UX 10.x / 11.x / 11iv2/11iv3... - Page 18 Product Support Guide Model M132 Software Description use the information in the PPD to control the print device and enable full functionality. It supports the Mac OS X 10.1 or later. Please see the Readme file for information about compatibility with versions of Mac OS X.
- Page 19 Product Support Guide Model M132 Model PCL 6 PostScript3 Mac OS Windows XP/Vista/7 (Native), 10.4-10.7 or later Slip Sheet Chaptering (Page Layout) Chaptering (Single Page Insert) Chaptering(Page Block Insert) User Defined Pages Tab Stock Printing Mirror Image Print Negative Image Print...
-
Page 20: Special Paper
Product Support Guide Model M132 Other MFP Support Information Not Applicable Counters User Tools / Printer Features / List/Test Print / Configuration page / unit prints the configuration page and the total counter in on the top right ... -
Page 21: Firmware Information
Product Support Guide Model M132 Firmware Information Firmware Firmware SD Card Firmware Type Engine Engine Finisher SR3110/SR3120 Finisher Font EXP Font Network Support NetworkDocBox NetworkDocBox OpePanel LCDC PCL Font PCL Font Printer Printer PostScript3 PS3 Font PostScript3 Font RPCS RPCS... -
Page 22: Contact Information
Product Support Guide Model M132 Contact Information Name Contact Technical Services Call Center (Hotline) Ricoh: (800) 537-4264 Savin: (800) 291-6044 Lanier: (800) 333-3147 Application Help Desk (Software Ricoh Phone Card: 2 Call - 000781MIU, 5 Call - 000900MIU Issues) Savin Phone Card: 2 Call - 12992, 5 Call - 12993 Hytec Parts and Logistics Control (800) 557-4264 http://www.nrc-usa.com... - Page 23 Product Support Guide Model M132 Revisions 1.0 Original Ver.1.0 Page 23 of 23 11/9/2012 Subject to change without notice...
