Circle Guide For Router Table
Model: CPRT-104
Web Site: www.circleperfecttools.com
Facebook: www.facebook.com/circleperfecttools
Tutorials: www.circleperfecttools.com/#!VIDEOS/c20ku
FAQ: www.circleperfecttools.com/#!faq/cavw
Contact Us: info@circleperfecttools.com
©2014 Circle Perfect Tools, LLC. All rights reserved
Advertisement
Table of Contents
Summary of Contents for CPT CPRT-104
- Page 1 Circle Guide For Router Table Model: CPRT-104 Web Site: www.circleperfecttools.com Facebook: www.facebook.com/circleperfecttools Tutorials: www.circleperfecttools.com/#!VIDEOS/c20ku FAQ: www.circleperfecttools.com/#!faq/cavw Contact Us: info@circleperfecttools.com ©2014 Circle Perfect Tools, LLC. All rights reserved...
- Page 2 GENERAL SAFETY RULES Safety is a combination of common sense, staying alert and knowing how to use a tool. WARNING: To avoid mistakes that could cause serious injury, do not attach Circle Guide for Router Table until you have read and understood the following: READ and become familiar with the entire installation instructions on how to attach Circle Guide for Router Table to your Router table.
-
Page 3: Table Of Contents
ASSEMBLY UNPACKING This product requires assembly WARNING: Carefully remove the product and any accessories from Do not attempt to modify this product or create the box. Makes sure that all items listed in the packing accessories not recommended for use with this list are included. -
Page 4: Center Pins (Pvc/Steel)
ASSEMBLY Step 1 - Inserting Slide Brackets Snap the two (2) PVC Slide Plate back Brackets into the of Slide Plate making sure they are flush with the plate. Step 2 - Inserting Center Pins Insert the two (2) PVC Center back Pins in from the side of... -
Page 5: Alignment Plate (Pvc)
Step 4 - Aligning Slide Plate to Alignment Plate Starting from one side of the Slide Plate, slide the Alignment Plate so that the Slide Plate Brackets are fully positioned into the groove of the Alignment Plate. Step 5 - Inserting Alignment Pin Now line up both Alignment Plate and Slide Plate matching center line on each piece. - Page 6 Step 7 Option A - Attaching Alignment Plate - USING BOLTS Using a 5/16 inch drill bit, drill two holes into the router table (one from each side) matching the pre-drilled holes in Alignment Plate. Insert mounting bolts through both the Alignment Plate and router table and use Hex Key to secure with washers and hex...
- Page 7 Step 8 Option A - Attaching Slide Plate - USING BOLTS Using a 5/16 drill bit, drill a hole through the center of the lock down channel of Slide Plate closet to the front edge of the router table and in alignment with the center line on the Slide Plate.
-
Page 8: Safety Stops (Pvc)
Basic Operations Safety Stops Use Safety Stops to prevent damage to the Circle Guide tool when using bits larger than 1/4" (English) or 6mm (Metric). The Safety Stops ensure the router bit will not cut into the Circle Guide tool when routing very small circles. - Page 9 Using Set Measurements The Circle Guide for Router Table provides the ability to lock in at set measurements every 1/16" (English) or 2mm (Metric). This operation provides precise repeatability by allowing operator to recall to a prior position. Step 1: Loosen the Lock-Down Bolt and release Alignment Pin.
