PACKAGE CONTENTS:
1xUniversal Fan Controller:
1x 400mm 4-pin Motherboard cable:
1x 400mm SATA cable:
1x Manual Remote:
1x Velcro Tape:
TECHNICAL SPECIFICATIONS:
Dimension controller (WxHxD)
Dimension remote (WxHxD)
Power input
SATA Cable
Input signal
PWM signal / DC signal / Manual remote / No signal
Output signal
1x White Universal 4 / 3-pin
4x Black 4-pin
3x Black 3-pin
Remote speeds
Max. connector power output
Max. total power output
Max. power usage
Warranty
102 x 38 x 17 mm
48 x 20 x 8 mm
12V
0-100% PWM / 3.8-12V DC
0-100% PWM
3.8-12V DC
40% / 70% / 100%
1A
4A
48W
2 years
UNIVER SA L FA N C ONTROLLER
M A N U A L
PLEASE CHECK W W W. P H A N T E K S . C O M / FA Q
FOR UP-TO-DATE INSTRUCTIONS AND COMPATIBILITY.
V 1.0
Advertisement
Related Manuals for Phanteks PH-PWHUB
Summary of Contents for Phanteks PH-PWHUB
- Page 1 V 1.0 PACKAGE CONTENTS: 1xUniversal Fan Controller: 1x 400mm 4-pin Motherboard cable: 1x 400mm SATA cable: UNIVER SA L FA N C ONTROLLER 1x Manual Remote: 1x Velcro Tape: M A N U A L TECHNICAL SPECIFICATIONS: Dimension controller (WxHxD) 102 x 38 x 17 mm 48 x 20 x 8 mm Dimension remote (WxHxD)
- Page 2 UNIVERSAL FAN INSTALLATION: C ONTROLLER Conveniently control both 4-pin PWM and 3-pin DC fans with a single controller STEP 1. with the manual remote (software-free) or synced to your motherboard. Choose for (A) MANUAL CONTROL (B) MOTHERBOARD CONTROL. A. Connect Manual Remote to the INPUT port. Speed control with a 3-button remote for silent/balanced/high performance mode.
