Page 2
About this Manual P/N: 01.54.456498 MPN: 01.54.456498011 Release Date: April, 2017 Statement This manual will help you understand the operation and maintenance of the product better. It is reminded that the product shall be used strictly complying with this manual. User’s operation failing to comply with this manual may result in malfunction or accident for which the manufacturer can not be held liable.
Page 3
Terms Used in this Manual This guide is designed to give key concepts on safety precautions. WARNING A WARNING label advises against certain actions or situations that could result in personal/animals injury or death. CAUTION A CAUTION label advises against actions or situations that could damage equipment, produce inaccurate data, or invalidate a procedure.
Table of Contents Chapter 1 Introduction ........................1 1.1. Features ..........................1 1.2. Intended Use/Indications for Use ..................1 1.3. Model ..........................1 1.4. Contraindications ......................2 1.5. General Safety Precaution Information ................2 1.5.1. General Information ....................2 1.5.2. Biohazard Considerations ..................4 1.5.3.
Page 5
5.4.3. Alphabetic Keys ....................32 5.4.4. Function Controls ....................32 5.4.5. Comment Function ....................37 5.4.6. Body Mark Function ..................... 39 5.4.7. Imaging Functions ....................41 5.4.8. Additional Control Functions ................44 5.5. Menu ..........................45 5.6. Dialog Box Operation ....................47 5.7.
Page 6
7.1.4. Bladder ........................90 7.2. Abdominal Report ......................90 7.3. Others ..........................91 Chapter 8 Obstetric Measurement and Calculation ..............92 8.1. Obstetric Measurement and Calculation in B Mode ............92 8.2. Canine Obstetrics Measurement ..................93 8.2.1. CRL ........................93 8.2.2.
Page 7
Chapter 11 Inspection and Maintenance ..................122 11.1. Daily Checklist ......................122 11.2. Cleaning and Disinfection .................... 123 11.2.1. System Surface Cleaning ................. 124 11.2.2. Probe and Probe Holder Cleaning and Disinfection ........124 11.2.3. Needle Guide Cleaning and Disinfecting ............126 11.2.4.
Page 8
A2.8.3: Test of Probe L761-2: ..................149 A2.8.4: Test of Probe L743-2: ..................153 A2.8.5: Test of Probe V563-2: ..................157 A2.8.6: Test of Probe C321-2: ..................161 Appendix III: Measurement Accuracy ..................166 Appendix IV: EMC Information-Guidance and Manufacture’s Declaration ......167 Appendix V: Order List .......................
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Chapter 1 Introduction 1.1. Features The P3V is a portable Veterinary Diagnostic Ultrasound System, which applies advanced technologies such Phased Inversion Harmonic Compound Imaging (eHCI), Double-Beam-Forming (D Beam), Speckle Resistance Imaging (eSRI), Synthetic Receiving Aperture (SRA)...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 1.4. Contraindications The equipment is not applicable to the diagnosis of the pneumatic organs that contain gas such as lung, stomach, intestines, etc. It is recommended not to examine the parts with wounds or acute inflammation to avoid cross infection.
Page 11
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Only accessories supplied or recommended by the manufacturer can be used, the battery and probes of the manufacturer can be only used on the manufacturer’s systems. Otherwise, the performance and electric shock protection can not be guaranteed.
Long time exposure should be avoided. For the parameters of sound output, please refer to appendix II. The P3V complies with the requirements of applicable International Electrotechnical Commission (IEC) standards in terms of safety and acoustic output levels.
The recommended inspection interval is once per week or less. If damage is evident, replacement is recommended before use. 9. Equipment connected to the P3V and located in the patient vicinity must be powered from a medically-isolated power source or must be a medically-isolated device.
Page 14
To ensure proper grounding and leakage current levels, it is the policy of the manufacturer to have an authorized representative or an approved third party to perform all on-board connections of documentation and storage devices to the P3V. The device and accessories are to be disposed of according to local regulations...
Page 15
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual manufacturer for recycling or proper disposal. Batteries are hazardous waste. Do not dispose them together with house-hold garbage. At the end of their life hand the batteries over to the applicable collection points for the recycling of waste batteries.
Page 16
Ultrasound machines also generate EMI. The P3V complies with limits as stated on the EMC label. However, there is no guarantee that interference will not occur in a particular installation.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 1.5.4. Battery Safety To prevent the battery from igniting, emitting fumes, bursting, injuring personal, damaging equipment, pay attention to the following precautions. WARNING Do not expose the battery to temperatures above 60 °C, or leave the battery in strong and direct sunlight.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual time. Do not pierce the battery with sharp objects, or hit it. Charge the battery between 0 °C and 40 °C and store it between -20 °C and 60 °C, which affects battery life.
Page 19
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Disposal method. It indicates that the equipment should be sent to special agencies according to local regulations for separate collection after its useful life. General Symbol for Recovery / Recyclable Type B Applied Part Alternating Current (a.c.)
Page 20
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Degree of protection provided by enclosures (IP Code): temporary IPX7 immersion. For the probe but not including the probe connector. Power off/on the system Brightness Contrast Sound muting Loudspeaker To adjust volume in PW mode NOTE: The user manual is printed in black and white.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 2.1.2. Rear View Figure 2-2 Rear View Probe sockets Air Fan AC power switch Appliance inlet Equipotential terminal Handle Probe holder Coupling gel trough Rechargeable lithium battery CAUTION 1. To have good aeration performance and be able to operate normally, please don’t cover or plug the air fan or heat dissipation orifice partly or wholly by using any object.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 2.2. Configuration 2.2.1. Standard Configuration 1 P3V main unit 1 micro-convex array probe: C611-2 1 power cord 1 potential equalization conductor 1 cable holder 2 pieces of fuse, φ5×20, T3.15AH250V ...
Page 24
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Printer Type Interface Recommended Models Video SONY UP-897MD, MITSUBISHI P93W_Z Black /white Video Printer SONY UP-D897, SONY Up-D898MD Video SONY UP X898MD S-Video SONY UP-20 Color Video Printer SONY UP-D25MD Color Inkjet printer:...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Chapter 3 Transportation and Storage 3.1. Moving the System The system is designed to be portable and easily transported. Power off the system and secure all accessories before moving it to another location.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Chapter 4 Installation Instructions 4.1. Environmental Requirements Keep the device away from equipment with strong electric field, strong magnetic and high voltage field, and protect the display screen from direct exposure to strong sunlight. Keep good ventilation.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 4.3.1. Installing and Uninstalling a Cable Holder To install the cable holder: 1. Take out the cable holder, three screws (M3×12) and packing foam from the package. 2. To avoid scraping the main unit, put one piece of packing foam on a flat ground.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 4.3.2. Installing and Uninstalling a Battery To install a battery (if necessary): 1. Take out the battery from the package. 2. Press the button on the battery cover and pull the cover out.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual ③ Pull the flicker counterclockwise to hide it ① Press the button ④Pull out the battery ②Pull the battery cover out Figure 4-4 Uninstalling Battery from Main Unit 4.3.3. Connecting and Disconnecting Probes NOTE: Ensure that the system is shut down before connecting and disconnecting probes.
Once the probe is connected to the main unit, please do not reinstall it frequently. This is to avoid poor contact between the probe and the main unit. 4.3.4. Peripheral Connections Video connections are located on the left panel of the P3V. WARNING Accessory equipment connected to the analog and digital interfaces must be certified according to the respective IEC/EN standards (e.g.
Page 31
To ensure proper grounding and leakage current levels, it is the policy of the manufacturer to have an authorized representative or approved third party perform all on-board connections of documentation and storage devices to the P3V. Figure 4-7 Ports on the Left Panel...
Non-medical peripheral equipment approved according to any other EN or IEC standard must use the following setup for connection: ➢ Connect the equipotential connector of P3V to an independent protective earth terminal with a potential equalization conductor. ➢ The peripheral equipment is located at least 1.5 meters (1.8 meters in Canada and the U.S.A) outside the patient environment.
IEC/EN 60601-1-1. If in doubt, consult our technical service department or your local distributor. 2. If you want to use a multiple portable socket-outlet to supply power to the whole P3V system, you are suggested to calculate the system power consumption when building a P3V system so as to match the system power consumption with the power sustained by a multiple portable socket-outlet.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 4.3.7. Installing a Needle Guide To install the needle guide of convex probes: Align the locating pin of the needle guide with the locating groove of the probe, align the clamp of the needle guide with the locating groove of the probe to click.
Page 35
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Figure 4-10 Parts of Needle Guide of Linear Probe - 27...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Chapter 5 System Control 5.1. Powering On/Off Device To power on the device Before powering on this device, check as below: 1. Check the potential equalization conductor and make sure it is connected properly.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual To restart the device If there is any trouble described as below, please press the power on/off key to switch off the device and then press it again to restart the device.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 5.3. Screen Layout ① ② ③ ④ ⑤ ⑥ Figure 5-1 Typical Image Screen ① . Top status bar: logo image, hospital name, animal information, system date and time, major parameter such as, probe name, probe frequency, etc.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 5.4. Control Panel ① ② ③ ④ ⑤ Figure 5-2 Control Panel ③ Acoustic power adjusting ① ② Power on/off key knob(reserved) Power/running indicator lights sliders ④ PC keyboard ⑤ Function controls 5.4.1.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual NOTE: 1. Please be gentle when running the trackball. 2. Please keep the surface of trackball clean. 5.4.2. “0~9” Numeric Keys Numbers are used for time calibrating, data setting, age notating, and comment adding etc.
Page 41
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual compound imaging. eSRI Speckle Resistance Imaging Press this key to reduce noise and enhance image quality. Colorization key Colorize Press this key to colorize the image. Cobalt, Sage, Sepia, magenta, flame, tan, or gray.
Page 42
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Entering key Enter In annotation mode and comment mode, press this key to move the cursor to insert a blank line. Delete key Del/Bksp In annotation mode and comment mode, press one of these two keys to delete text word by word.
Page 43
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Image left/right Flip key Press this key to flip the image horizontally. Press this key to clear all the measurements, calculations, comments, Clear and body marks displayed in the current image.
Page 44
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Rotate it to adjust total gain in the B mode, 0 ~ 130, in increments of Press it and then rotate it to adjust total gain in the PW mode.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual levels are available: 100%,144%,196%, 256%, 400%, 576%, 900%, 1600%(in area). Press Set display the zoomed image, and then roll the trackball to move the zoomed image. NOTE: In real-time mode, magnification function is only available in B-mode and 2B-mode.
Page 46
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual ➢ To add an arrow: 1. Press Comment, and there is a cursor “І” displayed in the image area for annotating; 2. Press Set to display an arrow; 3. Move the trackball to move the position of the arrow; and the rotation function is automatically activated and the rotation light is on.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Cardiac Lesion 1 Lesion 2 Figure 5-3 System-defined Comment Library 5.4.6. Body Mark Function To add a body mark: 1. Press Body Mark, to display the body mark dialog box. 2. Highlight a body mark in the body mark dialog box, and press Set to confirm the choice to add the body mark.
Page 48
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual To move a body mark: 1. Move the cursor to a body mark, Press Set button, and there is a pane around the body mark; 2. Press Set and move the cursor to a new position;...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Limb Figure 5-4 Body Marks 5.4.7. Imaging Functions B mode Imaging Control Press this key to enter the B mode. The system displays a single real-time B mode image. B indicates brightness, or two-dimensional (2D) gray scale imaging.
Page 50
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 4B mode Imaging Control Press this key to enter the 4B mode. The system divides the image area into four quadrants: the first quadrant is on the top left, the second on the top right, the third on the bottom left, and the fourth on the bottom right.
Page 51
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Operation: In the B scan, the long line lets you adjust the sample line position, the two parallel lines (that look like =) let you adjust the sample volume (SV) size and depth, and the line that crosses them lets you adjust the correction angle (PW angle).
4. Press PW again to enter B+PW mode. The system locks the sample volume indicator and adds the Time Series window. 5.4.8. Additional Control Functions The P3V also provides the following additional control functions, which are available through status menus. Control function...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual PW Invert Invert the PW wave. (Up or Down) D gain Adjust D gain in the PW mode D Frequency Set the probe frequency in PW mode Sample Volume Set the default sample volume...
Page 54
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Figure 5-6 System Status Menu Measurement and calculation menu Perform an operation. For instance, begin a distance measurement, and then the corresponding measurement cursor is displayed. After entering B mode, press Measure to display the menu below.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual the selected option. Example: The secondary menu of Cir/Area contains Ellipse and Trace, shown as below. After entering B mode, press Measure to display the menu below, and highlight the option Cir/Area, the system will display the secondary menu Ellipse and Trace.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Figure 5-11 Labd Examination Presetting Dialog Box 5.7. Presetting 5.7.1. Entering and Exiting To activate presetting function: 1. Press Preset, and the system displays the preset menu, as shown below. Figure 5-12 Preset Menu (the left—with no DICOM installed, and the right—with DICOM installed)
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 2. Roll the trackball to highlight one of the options and then press Set to display the menu of the corresponding option. To exit presetting: Highlight Return and press Set. Then the system restarts automatically. The system runs with the new modified parameters after being restarted.
Page 58
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Item Setting Allows you to Set hospital name displayed on the Hospital Input freely key top left of the screen and Name diagnosis report. Chinese, English, etc.(The language options Language Set the overlay language vary with language software installed.)...
Page 59
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Figure 5-14 Application Presetting Dialog Box Item Setting Allows you to Scan Line Green, Yellow, White, Red, Orange Set the default color of the scan line Guide Line Green, Yellow, White, Red, Orange...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual You must restart the system to validate the change, including Language, Keyboard Sound, Cursor Time. After you perform those presetting, and press Return, the system displays a confirm dialog box to prompt you whether to restart the system.
Page 61
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Freq F1/F2/F3/THI 1/THI 2 Set the frequency of probe. Gray map 0~14 Select the default post-processing gray curve map Set the image parameter of the basal wave Set the image parameter of the harmonious wave...
Page 62
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Pseudo color Set the colorization colors. D Dyn Range 30~150 Set the dynamic range of the PW wave D Freq F1/F2 Set the probe frequency in the PW mode Table 5-7 Obstetric Presetting Information – Parameter 2...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Gray Auto Control, Adjust the image penetrability. The purpose of GAC is to eliminate the high echo saturation in order to show clear clinical information. Table 5-8 Obstetric Presetting Information – IP 1 NOTE: The presetting information of IP-H is all the same as IP.
Page 64
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Figure 5-19 Comment Library Presetting To create text for text list: Take Generic for instance: 1. Press Generic to open the Generic comment library. 2. Roll the trackball to highlight one of the custom comments, and press Set.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 3. Press Del to delete the created comment. 4. Press OK to save the modification, or press Cancel to give up and close the dialog box. 5.7.6. Factory Default In preset menu, move the cursor to highlight Factory Default and press Set, a dialog of “Restore the Data”...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Alias Set the alias of the server Package Set the PDU receiving package size, from 4K to 64K, and the Size default value is 16K. Verify After presetting the server information, press Verify to verify the server’s connection.
Page 67
3. Before printing, make sure the printer power cord and the USB cable are connected well. 4. Do not cut off the printer power supply or the USB cable during printing. 5. If the printer can not work normally, please restart the printer and the P3V. - 59...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Chapter 6 Operation 6.1. Entering New Patient Press New Patient to clear all the information displayed on the screen, and then begin a new patient examination. NOTE: When you press New Patient, the system clears all the recent patient data, comments, measurements, calculations and worksheets, except saved images.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Figure 6-2 Examination Type Menu 6.4. Activating and a Probe Deactivating While multiple probes are connected to the ultrasound system, only one can be activated at a time. Press Probe repeatedly to cycle through the probes currently connected to the system. The model of the activated probe is displayed in the top right corner of the screen.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 3. In simulative operation, the final radiating surface temperature of probe L743-2 is 41.41℃. 4. In simulative operation, the final radiating surface temperature of probe C361-2 is 41.7℃. 6.5. Selecting an Imaging Mode...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Examination Application measurement & calculation items Result Abdomen Gallbladder:CBD, Gallbladder, Abdominal worksheet Kidney: Left Kidney, Right Kidney, Bladder Obstetric CRL, GSD, HD, BD, HD&BD, GSD-H, GSD-V, TD, Obstetric worksheet and BPD NOTE: Different measurement labels depend on different examination species.
Page 72
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 5. Roll the trackball and press Set to begin a new distance measurement. You can measure a maximum of four groups of data. The outcome will be displayed in the measurement result window, as shown below.
Page 73
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Trace Method To measure Circumference / Area: 1. Press Measure to activate measurement function. 2. Roll the trackball to highlight Cir/Area. Then select Trace, and press Set to activate a measurement cursor on the screen.
Page 74
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual (A: the length of major axis. B: the length of minor axis. M: the length of the third axis.) Three-axis method can be used to perform volume measurement by calculating two sets of measured data, EA and the length of the third axis.
Page 75
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual LAxis SAxis 3rdAxis Volume Figure 6-7 3-Axis Volume Method and the Results 3-Axis (LWH) method V= (π/6) × L × W × H, (L: the length. W: the width. H: the height.) Three-axis (LWH) method can be used to perform volume measurement by calculating 3 sets of distance data, L, W, and H.
Page 76
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Ratio To determine the ratio, take two measurements: A and B. The system calculates the ratio: A/B or B/A. To measure ratio: 1. Press Measure to activate measurement function. 2. Roll the trackball to highlight Ratio, press Set to activate a measurement cursor on the screen.
Page 77
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual To measure distance stenosis: 1. Press Measure to activate measurement function. 2. Roll the trackball to highlight % Stenosis, and select Distance, and then press Set to activate a measurement cursor on the screen.
Page 78
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 1. Press Measure to activate measurement function. 2. Roll the trackball to highlight % Stenosis, and select Area, and then press Set to activate a measurement cursor on the screen. 3. Measure the first area with the ellipse method.
Page 79
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 5. During measurement, you can press Change to change the start point and the end point; if you press Change again, the system interchanges line A and line B. 6. Roll the trackball and press Set to complete this measurement.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 6.6.2. Generic Measurements in M Mode M mode measurements and calculations include distance, time, slope and heart rate (2 cycles). These are for B/M and M display modes only. The default measurement of B/M and M mode is heart rate measurement.
Page 81
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual interval and then press Set. 5. Roll the trackball and press Set to begin a new time measurement. You can measure a maximum of four groups of data. The outcome will be displayed in the measurement result window, as shown below.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual and then press Set to anchor start position, and the measurement mark turns to a vertical line. 4. Roll the trackball to move the second measurement maker on the peak systole following two complete cycles and then press Set to anchor end position.
Page 83
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Reference Section 6.6.2 Generic Measurements in M Mode. Velocity To measure velocity of a point on the Doppler wave: 1. Press Measure to activate a measurement cursor “+”. 2. Roll the trackball to highlight Velocity and press Set and a “+” is displayed.
Page 84
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Vel2, calculating RI. 5. Roll the trackball and press Set to begin a new RI measurement. You can measure a maximum of four groups of data. The outcome will be displayed in the measurement result window.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual To perform D Trace function (automatic tracing) 1. Press Measure to activate a measurement cursor “+”. 2. Roll the trackball to highlight D Trace and press Set. 3. Select Auto and a big “+” is displayed.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual To print the general ultrasound report: Press Print in the General worksheet dialog box. Printing reference Section 5.8, Printing. Save PDF Press Save PDF to save the report to the removable U disk in PDF format. Images of white/black or color can be inserted in the report.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual The default setting is to load images by serial numbers forward. When the number reaches the last, it will return to 1. During playing back, press Save As to save the file in BMP, JPG, FRM, DCM, CIN or AVI format.
Page 88
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Preset>General Preset. NOTE: 1. After connecting a removable disk, the interface displays a USB symbol on the bottom left corner. 2. Please do not use the two USB ports at a time, otherwise, the system may fail to read / write data.
Page 89
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual ➢ Save AVI 1. Press Freeze to freeze the system; 2. Press File to open the file menu; 3. Highlight Save AVI in the file menu, and press Set. NOTE: The AVI files can not be viewed on this system, please use a U disk to copy the AVI files to a PC, and view them by using the WINDOWS RealPlayer.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual When saving a file, the saving information is automatically displayed in the middle of image area. 6.8.2. File Manager You can use the file manager to perform the file management or browse the images.
Page 91
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 2. USB disk or portable hard disk must be in FAT32 format. 3. Do not use the USB disk or portable hard disk for other uses, but only for this device.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual prompt Loading file… is displayed in the middle of the screen. 3. If the file format is FRM/CINE, cine images will be loaded. You can perform Cine review, measurements, or add comments/body marks and print them out in reports; if the file format is BMP/JPG/DCM, the system will enter image browsing status: check the multi-choice checkbox to browse the selected files in file list, uncheck the checkbox to browse all files.
Page 93
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual To send a DCM Image 1. Highlight the secondary menu DCM Image, and then press Set. 2. If the server is running normally, the current image will be sent to the server.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 6.9. Needle Guide Function NOTE: Use proper disinfection techniques at all times to perform a biopsy. Always follow these basic precautions: WARNING 1. Disinfect the needle guide and the probe before the first use and after each subsequent use to avoid cross infection.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual WARNING 1. Prior to each puncture, calibrate the needle guide line. 2. If the needle position is not the same as the needle guide line position, do not perform the puncture.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Highlight Load Factory and press Set load the factory data. To select the bracket: If the probe has different brackets, you can use the Bracket sel option to select the bracket.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Chapter 7 Abdominal Measurements & Calculations 7.1. Measurements and Calculations The abdominal examination is usually in the B mode. 1. Press Exam, select the exam mode Abd-Small/Abd-Large, and then press Set.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 7.1.2. Gallbladder 1. In the abdominal measurement menu, roll the trackball to highlight Gallbladder, select GB-L, GB-W or GB-H from the secondary menu,and then press Set. 2. Measure GB-L, GB-W or GB-H by the method of distance measurement.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Worksheet, as shown below: Figure 7-2 Abdominal Worksheet The diagnosis editing column displays the cursor “І”, and you can enter diagnosis information. To print the report: Press Print in the Abdominal Worksheet.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Chapter 8 Obstetric Measurement and Calculation The obstetric examination is usually in the B mode. To enter B mode obstetric examination: Press Exam, select a desired exam mode: OB Canine, OB Feline, OB Equine, OB Bovine, OB Ovine, or OB Others, and then press OK, or double click on the exam type.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Biparietal Diameter According species, Menstrual Age described in Appendix III Table 8-1 Obstetrics Measurement & Calculation 8.2. Canine Obstetrics Measurement When the exam mode OB Canine is selected, the OB MEAS CAN menu will display after entering the obstetrics measurement.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual For more information on B-mode generic distance measurements, please refer to section 6.6.1 Generic Measurement in B mode. 3. The result is displayed in the measured result window. 4. To begin a new GSD measurement, repeat steps 1 through 3. You can measure a maximum of one group of data.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Generic Measurement in B mode. 3. The result is displayed in the measured result window. 4. To begin a new HD&BD measurement, repeat steps 1 through 3. You can measure a maximum of one group of data.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual For more information on B-mode generic distance measurements, please refer to section 6.6.1 Generic Measurement in B mode. 3. The result is displayed in the measured result window. 4. To begin a new GSD-H measurement, repeat steps 1 through 3. You can measure a maximum of one group of data.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual For more information on B-mode generic distance measurements, please refer to section 6.6.1 Generic Measurement in B mode. 3. The result is displayed in the measured result window. 4. To begin a new TD measurement, repeat steps 1 through 3. You can measure a maximum of one group of data.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Figure 8-7 Other Obstetrics Measurements and Calculation Menu The measurements items of OB MEAS OTH are the same as those of OB MEAS CAN. Please refer to section for the measurements and calculations.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual NOTE: The system will display the completed measurements and calculations, the uncompleted measurements and calculations will not be displayed. You can check the measured items by opening the OB worksheet dialog box whenever you want, during measurement or after that.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Chapter 9 Cardiology Measurement and Calculation The cardiology examination is usually in the B mode, the B/M mode or the M mode. 9.1. Cardiac Measurement and Calculation in M Mode To enter M mode obstetric examination: 1.
Page 109
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 1. CUBE formula: NOTE: d: end diastolic; s: end systolic Label Description Method LVIDd Left Ventricle Internal Diameter Distance (mm) LVIDs Left Ventricle Internal Diameter Ejection Time Time (ms or s)
Page 110
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 2. TEICHHOLZ formula: NOTE: d: end diastolic; s: end systolic Label Description Method LVIDd Left Ventricle Internal Diameter Distance (mm) LVIDs Left Ventricle Internal Diameter Ejection Time Time (ms or s)
Page 112
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Body Surface Area (m Calculate by to the selected formula LVMW (g)=1.04*[{IVSTDd (cm)+LVIDd (cm) LVMW Left Ventricular Muscle Weight LVPWd (cm)} -LVIDd (cm) ]-13.6 Left Ventricular Muscle Weight LVMWI LVMWI (No unit)=LVMW/BSA...
Page 113
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual will be displayed. Select TEICHHOLZ or CUBE and press Set. Then move the cursor to the image area and a “+” is displayed. Move the cursor to the end systolic of left ventricle, and measure LVIDs. The method is similar to generic M mode distance measurement.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual To enter Height and Weight 1. In the M-cardiac measurement menu, roll the trackball to highlight Input. Then select the secondary menu Height & Weight and press Set to display a Height and Weight entering dialog box, as shown below.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual To measure EF slope, ACV, and A/E Roll the trackball to highlight EF Slope, ACV, or A/E, and press Set. The method of measuring EF Slope and ACV is similar to the generic M mode slope measurement method.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual The measurement operation procedure: 1. Roll the trackball to highlight Valve Volume and press Set. 2. Measure MAVO1. The method is similar to the generic M mode distance measurement method. 3. Measure MAVO2. The method is similar to the generic M mode distance measurement method.
Page 117
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Figure 9-5 B Mode Cardiac Measurement and Calculation Menu 1. Items of Measurement and Calculation B-CARDIAC MEAS: RV, LV, and PA. 2. Items of input Heart Rate, LVET, and Height & Weight.
Page 118
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Table 9-6 Measurement and Calculation Items with Single Plane Ellipse Formula 2. Dual plane ellipse formula: NOTE: d: end diastolic; s: end systolic Label Description Method LVALd Left Ventricle Area of Long-axle...
Page 119
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Mitral Valve LVLs Left Ventricular Length Distance (mm) Heart Rate Key in (bpm) EDV (mL)= (5/6)×LVLd (mm)×LVAMd (mm End Diastolic Volume /1000 ESV (mL)= (5/6)×LVLs (mm)× LVAMs (mm End Systolic Volume...
Page 120
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Ejection fraction (B mode) EF (No unit)= SV (mL)/ EDV (mL) x 100% Stroke Index SI (No unit)= SV (mL)/ BSA (m Cardiac Index CI (No unit)= CO (L/min)/ BSA (m...
Page 121
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual The operations in these methods are similar to those in the single plane ellipse method. Please refer to the corresponding B mode generic measure method for details, and you can use the prompt instruction to help you.
Page 122
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Figure 9-7 ET Input Dialog Box 2. Input a suitable value in the LVET (ms) box. 3. Roll the trackball to highlight OK and press Set. After measuring LV, MVCF will be displayed in the measured result window.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual measured result window. 9.2.2. RV (Right Ventricle Internal Diameter) 1. In the B-cardiac measurement menu, roll the trackball to highlight RV. 2. Measure RV with distance method. 3. The result will be displayed in the measured result window.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual To measure PS/ED: 1. In the D-Car MEAS menu, roll the trackball to highlight PS/ED and press Set and a “+” is displayed. 2. Roll the trackball and press Set to anchor the first point, measuring Vel1.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual To print the report: Press Print in the Cardiac Worksheet. Printing reference Section 5.8 Printing.. 9.5. Others Select Others to enter another application measurement. - 117...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Chapter 10 Vascular Measurements & Calculations Usually the vascular examination is in the PW mode. 10.1. Measurements and Calculations in PW Mode Press Exam, select the exam mode Vascular, and then press Set.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Reference Section 6.6.3 Generic Measurement in PW mode. 3. The results are displayed in measurement result window. 4. To begin a new Forelimb measurement, repeat steps 1 through 3. You can measure a maximum of one group of data.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Reference Section 6.6.3 Generic Measurement in PW mode. 3. The results are displayed in measurement result window. 4. To begin a new ICA measurement, repeat steps 1 through 3. You can measure a maximum of one group of data.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Figure 10-2 Vascular Worksheet The diagnosis editing column displays the cursor “І”, and you can enter diagnosis information. To print the report: Press Print in the vascular worksheet. Printing reference Section 5.8 Printing.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Chapter 11 Inspection and Maintenance CAUTION The device and accessories are to be disposed of according to local regulations after their useful lives. Alternatively, they can be returned to the dealer or the manufacturer for recycling or proper disposal.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 11.2. Cleaning and Disinfection All exterior parts of the device, including the control panel and probes, should be cleaned and/or disinfected as necessary or between uses with a recommended cleanser or disinfectant. Clean each part to remove any surface particles.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual 11.2.1. System Surface Cleaning To clean the system surface: 1. Power off the system and disconnect it from power supply. 2. Use a clean gauze pad or lint-free cloth, moistened lightly with a mild detergent (Javel water), to wipe the surface and the control panel.
Page 133
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual CAUTION We recommend that the single-use sheath should be complies with the local regulations To disinfect the probe: Disinfection should be performed each time after use. 1. Prepare the disinfectant(2.4% glutaraldehyde or 0.55% ortho-Phthalaldehyde).
Each time after use, clean and disinfect the probe. The acoustical window and the shell of the probe should be examined frequently. WARNING The P3V cannot be used together with high-frequency surgical equipment. CAUTION 1. Do not disinfect or clean probes under high temperature, and the temperature should be below 45°C.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Disinfecting Always disinfect the Needle Guide after use. 11.2.4. Trackball Cleaning To clean the trackball: 1. Remove the front panel bezel. 2. Remove the trackball as shown in figure 11-2. 3. Clean trackball with a tissue and 70% isopropyl alcohol.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Step 1 Step 2 Step 3 WARNING Only use the fuses with the same model as the manufacturer specified. 11.2.6. Disinfectants Disinfectants’ chemical name Disinfectants’ trade name Glutaraldehyde(2.4%) Cidex Activated Dialdehyde Solution (2.4%) Probe Ortho-Phthalaldehyde (0.55%)
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual WARNING 1. Be sage to choose the cleansers and disinfectants. The concentration in the air must not exceed an applicable specified limit. Comply with the manufacturer’s instructions when using the cleansers and disinfectants 2.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Chapter 12 Troubleshooting 12.1. Checkup Check whether the power supply works properly and the power cord is well connected and plugged into the power socket. Check whether the probe is properly connected to the main unit.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Chapter 13 Warranty and Service 13.1. Warranty The manufacturer warrants that products meet the labeled specifications of the products and will be free from defects in materials and workmanship that occur within warranty period.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Appendix I: Specifications A1.1: Electrical Safety Classifications Internally powered equipment, According to the type of protection against electric shock Class I equipment According to the degree of protection against Type B...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual A1.3: Machine Specifications Main unit dimensions 330 mm (L) × 220 mm (W) × 320 mm (H) Net weight 7.1 kg A1.4: Display Specifications Display TFT-LCD Diagonal Size 12.1-inch Horizontal: Өx View Angle .: 80°;...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Type Linear array probe Micro-convex probe: Micro-convex probe: Model L761-2 C321-2 C611-2 B/M Frequency (MHz) 6.5/7.5/8.5 2.5/3.5/4.5 5.5/6.5/7.5 Harmonious H9.0/H9.4 H5.0/H5.4 H9.0/H9.4 Frequency (MHz) Doppler Frequency 5.5/6.5 2.5/3.0 5.0/6.0 (MHz) Needle Guide Bracket...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Appendix II: Ultrasound Intensity and Safety A2.1: Ultrasound in Medicine The use of diagnostic ultrasound has proved to be a valuable tool in medical practice. Given its known benefits for non-invasive investigations and medical diagnosis, including investigation of the human fetus, the question of clinical safety with regards to ultrasound intensity arises.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual changed. Generally, the acoustic output will be higher with it gets nearer to the probe. Freeze When freezing the system, it will stop transmitting ultrasonic wave. The output of probe will be changed with the change of the transmission Transmission power power, and acoustic output will be changed.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual The temperature rise is determined by the acoustic intensity, exposed area and thermophysical properties of the tissue. In order to indicate the potential for temperature rise caused by thermal effects, the AIUM and NEMA formulate thermal index (TI).
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual relatively conservative. Over-estimation of actual in situ intensity exposure, for the majority of tissue paths, is made to the measurement and calculation process. For example, attenuation coefficient of 0.3 dB/cm∙MHz, which is much lower than the actual value for most tissues of the body, is adopted.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual frequency (PRF). The imaging mode determines whether the ultrasound beam is scanning or non-scanning. Thermal bioeffect is closely associated with M, PW and Color mode. Acoustic attenuation of tissue is directly connected to probe frequency.
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual A2.8: Probe Acoustic Output Parameters List A2.8.1 :Test of Probe C361-2: Acoustic Output Reporting Table for Track3 System : Operating Mode: B mode Transducer: C361-2 Working Frequency: 3.5MHz Index Label non-scan...
Page 150
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 System : Operating Mode: M mode Transducer: C361-2 Working Frequency: 3.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.63 0.0057...
Page 151
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 System : Operating Mode: B+M mode Transducer: C361-2 Working Frequency: 3.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.67 0.10...
Page 152
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 System : Operating Mode: PW mode Transducer: C361-2 Working Frequency: 2.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.56 0.44...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual A2.8.2 : Test of Probe C611-2: Acoustic Output Reporting Table for Track3 System : Operating Mode: B mode Transducer: C611-2 Working Frequency: 6.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt...
Page 154
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 System : Operating Mode: M mode Transducer: C611-2 Working Frequency: 6.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.76 0.0086...
Page 155
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 System : Operating Mode: B+M mode Transducer: C611-2 Working Frequency: 6.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.78 0.11...
Page 156
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 System : Operating Mode: PW mode Transducer: C611-2 Working Frequency: 5.0MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.74 0.33...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual A2.8.3: Test of Probe L761-2: Acoustic Output Reporting Table for Track3 System : Operating Mode: B mode Transducer: L761-2 Working Frequency: 6.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.50...
Page 158
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 System : Operating Mode: M mode Transducer: L761-2 Working Frequency: 6.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.53 0.0017...
Page 159
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 System : Operating Mode: B+M mode Transducer: L761-2 Working Frequency: 6.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.53 0.02...
Page 160
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 System : Operating Mode: PW mode Transducer: L761-2 Working Frequency: 5.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.41 0.07...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual A2.8.4: Test of Probe L743-2: Acoustic Output Reporting Table for Track3 System : Operating Mode: B mode Transducer: L743-2 Working Frequency: 6.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.67...
Page 162
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 System : P3V Operating Mode: M mode Transducer: L743-2 Working Frequency: 6.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.67...
Page 163
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 System : Operating Mode: B+M mode Transducer: L743-2 Working Frequency: 6.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.67 0.04...
Page 164
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 System : Operating Mode: PW mode Transducer: L743-2 Working Frequency: 5.5MHz Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.56 0.25...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual A2.8.5: Test of Probe V563-2: Acoustic Output Reporting Table for Track3 Transducer Model: V563-2 Operating Model: B Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.66 0.04...
Page 166
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 Transducer Model: V563-2 Operating Model: M Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.60 0.0026 0.0066 (MPa) 1.18 (mW) 0.28...
Page 167
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 Transducer Model: V563-2 Operating Model: B+M Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.60 0.04 0.0026 0.04 (MPa) 1.18 (mW) 10.79...
Page 168
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 Transducer Model: V563-2 Operating Model: PW Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.52 0.20 0.99 (MPa) 1.04 (mW) 21.59...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual A2.8.6: Test of Probe C321-2: Acoustic Output Reporting Table for Track3 Transducer Model: C321-2 Operating Model: B Index Label non-scan scan non-scan ≤1 >1 aprt aprt 0.69 0.21 Global Maximum Index Value (MPa) 1.18...
Page 170
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 Transducer Model: C321-2 Operating Model: M Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.64 0.21 0.53 (MPa) 1.08 (mW) 13.10...
Page 171
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 Transducer Model: C321-2 Operating Model: B+M Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.64 0.21 0.21 0.53 (MPa) 1.08 (mW) 26.20...
Page 172
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Acoustic Output Reporting Table for Track3 Transducer Model: C321-2 Operating Model: PW Index Label non-scan scan non-scan ≤1 >1 aprt aprt Global Maximum Index Value 0.81 0.98 3.22 (MPa) 1.40 (mW) 119.5...
Page 173
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual TRACK3(FDA Guidance) and IEC60601-2-37 standard parameter equal contrast list NOTE TRACK3 parameter IEC60601-2-37 parameter Attenuated Peak-rare-factional Acoustic Pressure r.α Peak-rare-factional Acoustic Pressure Output Power Depth for Soft Tissue Thermal Index Attenuated Output Power α...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Appendix III: Measurement Accuracy Parameter Range Accuracy C361-2: 19mm-324mm L743-2: 19mm-117mm L761-2: 29 mm-120mm Image depth range <±4% of full scale C611-2: 29mm-157mm V563-2: 19mm-176mm C321-2: 29mm-245mm M mode Time Range 1s, 2s, 4s, 8s <±3% of full scale...
EQUIPMENT and SYSTEMS Guidance and manufacture’s declaration – electromagnetic immunity The P3V is intended for use in the electromagnetic environment specified below. The customer or the user of P3V should assure that it is used in such an environment.
Page 176
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Electrical fast ±2 kV for power supply ±2KV for power supply Mains power quality transient/burst IEC lines lines should be that of a typical 61000-4-4 commercial hospital environment. Surge ±1 kV line to line ±1 kV line to line...
Page 177
To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the P3V is used exceeds the applicable RF compliance level above, the P3V should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as reorienting or relocating the P3V Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
Page 178
Recommended separation distances between portable and mobile RF communications equipment and the P3V The P3V is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the P3V can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the P3V as recommended below, according to the maximum output power of the communications equipment.
Appendix V: Order List The following accessories are recommended to be used on the P3V. WARNING Probes and other accessories used on the P3V must be provided or recommended by the manufacturer. Otherwise, the device may be damaged. Part Name...
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual Appendix VI: Glossary Abbreviated Description Obstetrics Estimated Date of Confinement Menstrual Age Last Menstrual Period Basal Body Temperature Estimated Fetal Weight Gestational Sac Diameter Crown Rump Length Biparietal Diameter Head Circumference...
Page 181
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual MVCF Mean Velocity Circumferential Fiber Shortening Body Surface Area Aortic root Diameter Left Atrium Diameter LAD/AOD Left Atrium Diameter / Aortic root Diameter Cardiac cycle apex A Cardiac cycle apex E...
Page 182
P3V Veterinary Digital Ultrasonic Diagnostic Imaging System User Manual L UT A Left Uterus Aorta R UT A Right Uterus Aorta L OV A Left Ovary Aorta R OV A Right Ovary Aorta Small Parts Thyroid Gland L. THY-V Left Thyroid Gland Volume L.
