SJA SJ-5286 Quick Installation Manual

N e x t G e n e r a t i o n G P S
Bluetooth GPS Receiver Quick Installation Guide
Thank you for purchasing Bluetooth GPS Receiver and we wish you have the best consumer product
experience ever.

Main features:


Adopt Skytraq Venus 6 with 65-Channel for fast acquisition and reacquisition

High sensitivity (to -160dBm)

Excellent performance - Cold/Hot start time: 29/1 sec. (average)

Smart power saving / Up to 14~16 hours usage

Support standard NMEA-0183

Compatible with Bluetooth Serial Port Profile (SPP) in 10m wirelessly

WAAS / EGNOS supported

A. Standard Package

Bluetooth GPS Receiver (1) + Lithium-Ion Rechargeable Battery (2) + Cigarette Adapter (3) + Optional Travel Charger (4) + Quick
Installation Guide. (* Travel Charger plug type might be adjusted according to corresponding countries.)
1.

B. Appearance

Power Jack
Bluetooth Status LED
Power LED

C. Charging your battery

For the first time using the Bluetooth GPS Receiver, please charge battery until it is fully
charged. Take the power cable and connect it to the power jack and recharge through
travel charger or car cigarette adaptor. This will begin to charge the battery. Charging
time is 3 hours typically.
- When the Power LED is blinking, battery power is low status. Please recharge.
- When the Power LED is steady on, the battery is under charging mode.
- When the Power LED is Off, the battery is fully charged.
S k y T r a q 6 5 C H B l u e t o o t h G P S
2. 3.
Carrying Strap Hole
B l u e t o o t h G P S R e c e i v e r
4.
(Option)
Power Switch
GPS Status LED
Page 1
