NodOn
Z-Wave Plus Micro Smart Plug Switch E/F
SKU: NODEMSP3101
Quickstart
This is a On/Off Power Switch for Europe. To run this device please connect it to your mains power supply. To add this device to your network
execute the following action:
To include/add to the Z-Wave network, long press during 2 seconds to send several NIF during 30 seconds or a triple press to send a single NIF
What is Z-Wave?
Z-Wave is the international wireless protocol for communication in the Smart Home. This device is suited for use in the region mentioned in the Quickstart
section.
Z-Wave ensures a reliable communication by reconfirming every message ( two-way communication)
and every mains powered node can act as a repeater for other nodes (meshed network) in case the
receiver is not in direct wireless range of the transmitter.
This device and every other certified Z-Wave device can be used together with any other certified Z-
Wave device regardless of brand and origin as long as both are suited for the same frequency
range.
If a device supports secure communication it will communicate with other devices secure as long as
this device provides the same or a higher level of security. Otherwise it will automatically turn into a
lower level of security to maintain backward compatibility.
For more information about Z-Wave technology, devices, white papers etc. please refer to www.z-wave.info.
Product Description
The NodOn Micro Smart Plug can be controlled by any kind of Z-Wave (or Z-Wave Plus) gateway or other Z-Wave controller (standalone mode) such as
the NodOn Soft Remote or Octan Remote.
It existed in both standard, Type E (French) or Type F (German). Its very small design and volume allow easy integration, without obstructing nearby power
holes on a power strip. Furthermore, it can perform Power and Energy Metering.
The NodOn Smart Plug is based on brand new 500 series Z-Wave module from Sigma Designs, and support all the new features of Z-Wave Plus standard:
Longer range (up to 40m), lower power consumption, higher data rate transmission, and many more new features.
Prepare for Installation / Reset
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for nodon NODEMSP3101
Summary of Contents for nodon NODEMSP3101
- Page 1 Furthermore, it can perform Power and Energy Metering. The NodOn Smart Plug is based on brand new 500 series Z-Wave module from Sigma Designs, and support all the new features of Z-Wave Plus standard: Longer range (up to 40m), lower power consumption, higher data rate transmission, and many more new features.
- Page 2 3) The Micro Smart Plug allows to switch ON (Power ON) or switch OFF (Power OFF) the electrical appliance you want to control. Switching ON or OFF can be done through the Micro Smart Plug local button, or any kind of Z-Wave® compatible devices, such as the NodOn® Octan Remote, the NodOn®...
- Page 3 Exclusion To exclude/remove from the Z-Wave network, long press during 2 seconds to send several NIF during 30 seconds or a triple press to send a single NIF Product Usage The Micro Smart Plug can be switched ON or OFF locally, through a short press on the local button. By default, the Micro Smart Plug is switched ON when the LED is green, OFF when the LED is OFF.
- Page 4 This parameter is to set the Alarm 1 Type. Use the Home Automation Gateway interface or our Alarm set-up form to define the value corresponding to your need. Size: 2 Byte, Default Value: 0 Setting Description 0 - 65535 To set-up your values please follow this link : www.nodon.fr/support/msp3/alarm...
- Page 5 Description 0 - 2097151999 To set-up your values please follow this link : www.nodon.fr/support/msp3/alarm Parameter 7: Alarm 2 Type Configuration This parameter is to set the Alarm 2 Type. Use the Home Automation Gateway interface or our Alarm set-up form to define the value corresponding to your need.
- Page 6 0 - 65535 To set-up your values please follow this link : www.nodon.fr/support/msp3/alarm Parameter 16: Alarm 6 Specifications This parameter is to set the Alarm 6 Specifications. Use the Home Automation Gateway interface or our Alarm set-up form to define the value corresponding to your need.
- Page 7 Parameter 24: Metering Pulse Whatever other metering reports, this parameter will send one power and one energy report to the lifeline every x s (Seconds). Size: 2 Byte, Default Value: 3600 Setting Description Metering Pulse disable 1 - 65535 Metering Pulse enable and send report every 1 s (to 65535 s) Parameter 25: Power High Threshold This parameter defines the High Threshold power value.
- Page 8 Association Group Information V2 Association V2 Basic Configuration Device Reset Locally Firmware Update Md V2 Indicator Manufacturer Specific V2 Meter V4 Notification V4 Powerlevel Protection V2 Switch Binary Version V2 Zwaveplus Info V2 Controlled Command Classes Application Status Basic Explanation of Z-Wave specific terms Controller —...
