BLiNQ Networks Inc. X-100 User Manual

Intelligent wireless backhaul system
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
BLiNQ Networks Inc.
X-100 Intelligent Wireless Backhaul System
User Guide
Release 1.0
Issue 01
February 2013

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X-100 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for BLiNQ Networks Inc. X-100

  • Page 1 BLiNQ Networks Inc. X-100 Intelligent Wireless Backhaul System User Guide Release 1.0 Issue 01 February 2013...
  • Page 2 BLiNQ Networks Inc. X-100 User Guide Release 1.0 Disclaimer The statements, configurations, technical data, and recommendations in this document are believed to be accurate and reliable, but are presented without express or implied warranty. Additionally, BLiNQ Networks makes no representations or warranties, either expressed or implied, regarding the contents of this product.

  • Page 3: Table Of Contents

    Ethernet Bridge Support ........................26 Installation Planning..........................27 Using the X-100 WebUI ........................28 10.1 Requirements ..........................28 10.2 Common X-100 WebUI Page Items ..................... 29 10.3 Configuring Hub Modules ......................30 10.3.1 Logging In ..........................31 10.3.2 System Overview Page ......................32 10.3.3...
  • Page 4 Performance Page ....................... 52 10.4.6 Events Page ......................... 52 10.4.7 Admin Page ......................... 52 Alarms and Events (Fault Management)..................53 Using the X-100 Command Line Interface ..................56 12.1 Overview ............................. 56 12.2 Identify Command Context ......................56 12.3 Logging On to the X-100 CLI ......................57 12.4...
  • Page 5 Keywords ..........................64 12.8.2 Parameters .......................... 64 12.8.3 Keywords and Parameters Together .................. 65 12.9 Saving Configuration Changes Made Through the X-100 CLI ............ 65 12.10 Writing and Running X-100 CLI Scripts ..................67 12.11 Using Help ..........................67 12.11.1 ? (Question Mark Key) ....................
  • Page 6 BLiNQ Networks Inc. X-100 User Guide Release 1.0 List of Figures 1 BL NQ X-100 S ..................6 IGURE YSTEM IN A IRELESS ACKHAUL PPLICATION 2 BL NQ X-100 H (HM) (RBM) ............... 8 IGURE ODULE EMOTE ACKHAUL ODULE 3.5 GH ...................

  • Page 7: 100 System Overview

    The BLiNQ X-100 system operates in the sub 6 GHz licensed frequency bands and are designed for Non- Line-of-Sight (NLOS) operation by incorporating advanced physical layer and medium access control layer algorithms and techniques.
  • Page 8 3-5 µsec in urban areas where small cells are deployed. For short symbol times on the order of a few µsec the added cyclic prefix would substantially cut into the useful bandwidth. For the longer symbol times used by the X-100 system the cyclic prefix is only a small fraction of the total bandwidth.
  • Page 9 Network Management Protocol (SNMPv2C/v3) interface to existing third-party managing applications such as element/network management systems (EMSs/NMSs). The X-100 system has a small, all-outdoor, zero-footprint form factor that can be easily deployed on towers, poles, building sidewalls, or rooftops unobtrusively. Page 8 of 91...

  • Page 10: 100 System Description

    Release 1.0 2 X-100 System Description The BLiNQ X-100 system is designed to meet the requirements of network operators for high capacity and reliability in small cell base station backhaul applications, as well as in a number of other applications. The system can function either as Point-to-Point (PTP) or Point-to-Multipoint (PMP) wireless Ethernet bridge equipment.
  • Page 11 The X-100 system is small in size (31x21x8 cm) and low in weight (3.5 kg) so it can be easily mounted on the network operator’s existing tower assets. The small size and weight allows quick deployment of the RBMs at customer premises in different enterprise/corporate data backhaul applications or other types of industrial and commercial applications.
  • Page 12 Configuration Management: BLiNQ products are designed to minimize the configuration effort • by the network operator. For example, when deployed in the field, the X-100 system can obtain its IP address through DHCP rather than have it statically assigned by the user. Further, the X- 100 system provides a web-based configuration tool called the X-100 WebUI and a standard Command Line Interface (CLI) that run directly on the X-100 equipment.

  • Page 13: Technical Specifications

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 3 Technical Specifications 3.1 System Parameters Table 2 shows general X-100 system parameters. Table 2 General X-100 System Parameters Access Technology Orthogonal Frequency-Division Multiplexing (OFDM) Non-Line-of- Sight (NLOS) RF Bands 3.65 – 3.7 GHz...

  • Page 14: Ofdma And Frame Parameters

    Orthogonal Frequency-Division Multiple Access (OFDMA) and Frame Parameters for 10 MHz channel bandwidth option are shown in Table 3. The frame duration or size is a user settable feature in the X-100 WebUI (through the Setup Page for the Radio Interface) and is part of system configuration.
  • Page 15 BLiNQ Networks Inc. X-100 User Guide Release 1.0 Mask for off the shelf antennas BLiNQ’s RBM Antenna Performance Figure 3 Horizontal antenna pattern (Port 1) for 3.5 GHz band Table 4 Integrated Antenna Specifications in the 3.65 GHz Band Gain 17.0 ±...

  • Page 16: System Enclosure

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 3.4 System Enclosure The enclosure for both the Hub and RBM is a rugged IP67 casing supplied with an optional mounting bracket with both horizontal and vertical tilt capabilities to mount the unit on towers, poles, and building side walls while allowing full flexibility in the range of orientation to establish best connectivity between the Hub and RBMs.

  • Page 17: Link Budget And System Gain

    Release 1.0 4 Link Budget and System Gain Table 6 lists the link budget for the BLiNQ X-100 system at 3.65 GHz in a 2x2 Multiple Input Multiple Output-Spatial Multiplexing (MIMO-SM) operation. The X-100 system provides very high system gain (134 dB for 256 Quadrature Amplitude Modulation [QAM] 5/8 Modulation and Coding Scheme [MCS]).

  • Page 18: System Trade-Offs

    Range, capacity and reliability are three factors that can be traded off against each other. The higher the fade margin, the lower the reach of the X-100 is to achieve a certain capacity target. For example, Figure shows a system gain of 136 dB for 256-QAM 5/8 MCS which results in a throughput of 61 Mbps.
  • Page 19 Figure 4 Performance Versus Distance for 256 QAM 5/6 MCS The BLiNQ proprietary Managed Adaptive Resource Allocation (MARA) interference management technology built into the X-100 system contributes to increasing the link availability while also providing higher capacity. Confidential - Restricted Use and Duplication...

  • Page 20: System Synchronization

    When configured to synchronize on GPS, the X-100 system uses its internal GPS antenna and receiver module to synchronize to the GPS network. This allows all X-100 HMs deployed in the network to accurately synchronize their transmit and receive operations on the air interface. The GPS system also allows the X-100 system to determine accurate time of day and date information.
  • Page 21 HM to RBM protocol, the clock reference is accurately transported at the RBM and therefore the entire cluster implements the behavioral requirements of an IEEE 1588v2 master clock. The X-100 system allows the configuration of the main IEEE 1588v2 master clock parameters such as transport protocol and messaging intervals.

  • Page 22: System Throughput

    MIMO operation which doubles the channel throughput by transmitting two independent codewords on each antenna. Note: System throughput is set using the X-100 WebUI Setup Page for the Radio Interface. See 10.3.4 for details. Table 8 Throughput Performance for Cyclic Prefix of 1/8...
  • Page 23 BLiNQ Networks Inc. X-100 User Guide Release 1.0 Table 9 Throughput Performance for Cyclic Prefix of 1/16 TDD Frame 5 ms, 22/22 3.125 ms, 12/12 Length, DL/UL 1 RBM 2 RBMs 3 RBMs 4 RBMs 1 RBM 2 RBMs 3 RBMs...

  • Page 24: Element And Network Management

    X-100 Web Interface (WebUI). Accessible via HTTP(S), the X-100 WebUI provides an interactive • visual toolset that allows an operator to modify the full configuration of the X-100 system as well as view state, fault, and performance indicators. The performance data is displayed using visual charts, and applications are provided to visualize up to 24 hours of historical performance data stored on the system.
  • Page 25 The security configuration parameters allow the operator to secure access or disable specific management interfaces and perform various unit administrative operations. Fault Management. The X-100 system provides fault management service via a comprehensive • list of alarms and events. Some of the potential faults that the system is able to detect and...
  • Page 26 (that is, the system modules retrieve the software package files from external FTP servers), or a push scheme using the X-100 WebUI (that is, the operator uploads a software package file to the system modules using the X-100 WebUI). The X-100 system also supports remote configuration backups and backup restoration.

  • Page 27: Ethernet Bridge Support

    VLAN processing scheme. The system also allows network management traffic to be encapsulated in a dedicated management VLAN. The X-100 system can transport standard Ethernet frames (up to 1518 bytes) as well as mini Jumbo frames of up to 2048 bytes.

  • Page 28: Installation Planning

    Determine if lightning protection is needed and install if required • Be sure to do the following upon unpacking the X-100 system modules. For each Hub and RBM module in your system: Locate the label on the module casing that lists the Serial Number (SN) and Media Access •...

  • Page 29: Using The X-100 Webui

    Linux • Note: With the exception of IE9, both web browser and OS support for the X-100 WebUI always refer to the most recent versions (for example: Fx17 running on Windows 7). All required X-100 system configuration tasks can be performed using the X-100 WebUI.

  • Page 30: Common X-100 Webui

    Release 1.0 10.2 Common X-100 WebUI Page Items Most X-100 WebUI pages have either an Apply button or a Refresh button or both at the bottom right hand corner. If you change the settings on a page, ensure to click on Apply before navigating to another page. Read- only data on a page can be updated to their current values at any time by clicking on the Refresh button.

  • Page 31: Configuring Hub Modules

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 10.3 Configuring Hub Modules Page 30 of 91 Issue 01 Confidential - Restricted Use and Duplication...

  • Page 32: Logging In

    To log in and access the X-100 WebUI interface for configuring Hub Modules (HMs), do the following: 1. Launch your web browser and set it to allow pop ups (as some screen functions in the X-100 WebUI require pop ups).

  • Page 33: System Overview Page

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 10.3.2 System Overview Page This read-only page gives general system information on the particular Hub you are logged in to. The RBMs associated with this Hub are also listed along with their information.

  • Page 34: Setup Page (System)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 10.3.3 Setup Page (System) This sub-page handles configuration of system parameters that govern basic Hub Module operation. System Identification: Enter information here as desired to aid system identification. System Name: Name of the module, composed of alphanumeric characters, underscores, and dashes.

  • Page 35: Setup Page (Radio Interface)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 Note: The “FreeRun” mode is intended for isolated trial or laboratory testing of the X-100 system only. Networks of X-100 systems depend on proper synchronization through either GPS or IEEE 1588v2 clock references to operate optimally, and may experience significant performance degradation or even outage if not deployed accordingly.

  • Page 36: Bridge Page

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 Chapter 14 for more information on use of preamble indices Rate Adaptation: Minimum and Maximum Uplink and Downlink Modulation and Coding Scheme (MCS) For each, set to one of the following (as applicable): QPSK3/4 •...

  • Page 37: Rbms Page (Rbm General)

    The QoS is supported by allocating each service flow a specific QoS class, of which there are two in the X-100 system: Guaranteed Bit Rate (GBR), and Best Effort (BE). The GBR class is for data streams for which the most stringent service scheduling is required, with guarantees on throughput, latency, and jitter.

  • Page 38: Rbms Page (Default Service)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 10.3.7 RBMs Page (Default Service) On this sub-page you can edit the RBM configuration data for the default service flow definition. Click Apply for the changes to take effect. Page 37 of 91...
  • Page 39 BLiNQ Networks Inc. X-100 User Guide Release 1.0 Service Flow Select a Service Flow from the list at the left. Details appear on the right where they can be edited. To delete a Service Flow, click on a check box on the list at the left and click on the Remove Selected button.

  • Page 40: Rbms Page (Rbm List)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 appropriate. Up to eight Classifiers can be configured per service flow, with Boolean OR logic in effect on multiple Classifiers in a service flow. Change the order and priority of Boolean OR operations for multiple Classifiers by drag and drop. The higher up the order the Classifier is, the higher its priority within Boolean OR operations.

  • Page 41: Performance Page (Ethernet)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 10.3.9 Performance Page (Ethernet) This read-only sub-page for Hub Ethernet performance visualizes the incoming and outgoing traffic for the Ethernet interface connections using two graph lines. This allows the user to see traffic and bandwidth usage for the Ethernet interfaces in a real-time, graphical format, and monitor the current download/upload throughput speeds.
  • Page 42 BLiNQ Networks Inc. X-100 User Guide Release 1.0 Click on an RBM on the list at the bottom to view the statistics on signal quality and throughput (per service flow) performance for that RBM. Confidential - Restricted Use and Duplication...

  • Page 43: Events Page (Alarms)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 10.3.11 Events Page (Alarms) This read-only sub-page lists current alarms and events along with their details. For a list of alarms and events see Chapter 10. Reorder the alarms and events as desired by clicking on any of the column headers.

  • Page 44: Events Page (History)

    Note: If you disable the Web option, the X-100 WebUI becomes unusable. You will have to enable it again using either the X-100 CLI or SNMP. It is not possible, however, to lock yourself out of all three options; at least one option is always be available.

  • Page 45: Admin Page (User Manager)

    • characters, and must contain at least one letter and one digit. At least one user with read/write privileges needs to exist in the X-100 system. • If you cannot login due to a forgotten user name or password, contact another user with •...

  • Page 46: Admin Page (Snmp Settings)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 10.3.15 Admin Page (SNMP Settings) On this sub-page the administrator can add, delete, or edit SNMPv2C or SNMPv3 users and hosts if desired. Confidential - Restricted Use and Duplication Page 45 of 91...

  • Page 47: Admin Page (Software Upgrade)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 10.3.16 Admin Page (Software Upgrade) On this sub-page the administrator can perform system software upgrade activities. As shown, active and standby software image versions can coexist simultaneously on the HM (and RBM).

  • Page 48: Admin Page (Configuration Management)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 5. If the software upgrade fails (due normally to a corrupt load), the system restarts again using the old software image. The banner at the top of the page indicates that this has happened.

  • Page 49: Admin Page (Syslog Server)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 10.3.18 Admin Page (Syslog Server) On this sub-page the administrator can add and delete Syslog Servers, and set or change their operational status. Click on Add to add a new Syslog server to the list displayed. In the dialog box that appears use the radio buttons to toggle its status: ‘Enable’...

  • Page 50: Configuring Rbms

    Release 1.0 10.4 Configuring RBMs The X-100 WebUI interface for configuring RBMs is similar to that for Hubs. This section focusses on differences only. Moreover, sections that are read-only are not discussed; some of these omit data not appropriate to RBMs and add other data not shown on the X-100 WebUI pages for Hubs.

  • Page 51: Logging In

    10.4.1 Logging In To log in and access the X-100 WebUI interface for configuring RBMs, do the following: 1. Launch your web browser and set it to allow pop ups (as some screen functions in the X-100 WebUI require pop ups).

  • Page 52: Setup Page (System)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 10.4.3 Setup Page (System) This sub-page handles configuration of system parameters that govern basic RBM operation and is the same sub-page as for Hub, except: System Clock Source: Cannot be set from the RBM...

  • Page 53: Performance Page

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 10.4.5 Performance Page This read-only sub-page for RBM performance contains graphs and statistics for the downlink/uplink Carrier to Interference-plus-Noise (CINR), downlink/uplink MCS, and downlink/uplink throughput. It visualizes the incoming and outgoing traffic for the RBM using graph lines. This allows the user to see traffic and bandwidth usage for the RBM in a real-time, graphical format, and monitor the current download/upload throughput speeds.

  • Page 54: Alarms And Events (Fault Management)

    The X-100 system issues an event notification when something of importance happens that does not trigger an alarm, but is considered significant enough to be presented to users through the X-100 WebUI Events page.
  • Page 55 BLiNQ Networks Inc. X-100 User Guide Release 1.0 Name Description/Comments Type Severity b) The Radio Driver is expecting the Radio Module to boot (for example, following a soft reset or after unit restart) and the DAN Driver fails to establish connection with the Radio Module after a certain time.
  • Page 56 BLiNQ Networks Inc. X-100 User Guide Release 1.0 Table 11 List of Events Name Description/Comments Type Severity 6001 Cold Start Unplanned restart Equip. Information 6002 Warm Start Planned restart Equip. Information Radio Module Radio driver established communication 5001 Equip. Information...

  • Page 57: Using The X-100 Command Line Interface

    Note: Command comments can be entered directly in the X-100 CLI by identifying them with an exclamation mark (!) at the start of a line. This tells the X-100 system that the information is a comment and is to be ignored.

  • Page 58: Logging On To The X-100 Cli

    Once an IP address is assigned to a module, you can log on to the X-100 CLI using a Secure Shell (SSH) connection (SSH is an application for opening a secure socket connection to an IP device). However, SSH version 2.0 client software must be installed on your host computer (SSH version 1.0 can be used, but is...

  • Page 59: Global Config Commands

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 event-history exit Exit the management session file Perform file operations help Provide help information history Configure history size Show user id information idle-timeout Configure idle timeout ignore-leading-space Ignore leading whitespace (true/false) Job operations...

  • Page 60: Radio Config Mode

    Show a parameter Exit to top level and optionally run command validate Validate current configuration Within the Global CONFIG level you can: Apply features globally to an X-100 system • Enable/disable a feature or function • Configure a feature or function •...

  • Page 61: Rbm Config Mode (Hub Modules Only)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 localhost(config-user-admin)# <Tab> Possible completions: group Group the user belongs to password User password commit Commit current set of changes exit Exit from current mode help Provide help information Negate a command or set its defaults...
  • Page 62 BLiNQ Networks Inc. X-100 User Guide Release 1.0 Terminate configuration session exit Exit from current mode help Provide help information insert Insert a parameter load Load configuration from an ASCII file move Move a parameter Negate a command or set its defaults...

  • Page 63: X-100 Cli Command Structure

    Display current mode path Exit to top level and optionally run command 12.6 X-100 CLI Command Structure To get a quick display of available options at a CLI level or for the next option in a command string, enter a single question mark ? at the prompt, press Tab, or press <space>.

  • Page 64: X-100 Cli Command Line Prompts

    12.7 X-100 CLI Command Line Prompts Within the X-100 CLI, the command line prompt identifies both the hostname and the command mode. The hostname is the name of your X-100 system; the command mode indicates your location within the CLI command structure.

  • Page 65: X-100 Cli Keywords And Parameters

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 For some actions, the X-100 CLI prompts you for a response. The acceptable default responses are the following: You can press <Enter> to agree with the prompt and continue. • You can press any other key to disagree with the prompt and cancel the action.

  • Page 66: Keywords And Parameters Together

    X-100 system. For example, you could specify the Global CONFIG command user service to add a description of the user service to the X-100 system by entering a keyword and a parameter. You need to type only the portion of the keyword that makes it unambiguous, such as des.
  • Page 67 Through the X-100 CLI, by way of this example you have now successfully made a change to the X-100 system configuration, committed this change to the running configuration, and copied the running configuration to the startup configuration, thereby saving the configuration change across system restarts.

  • Page 68: Writing And Running X-100 Cli Scripts

    To run a basic CLI script file on the X-100 system, save the script as text, then copy and paste it directly into the X-100 CLI at the Global CONFIG level. The script then runs on the X-100 system. Ordinarily, when a CLI script is run, it is run to completion, even if errors are encountered.

  • Page 69: (Question Mark Key)

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 12.11.1 ? (Question Mark Key) You can enter the question mark (?) key whenever you need additional information. When you enter ?, all available choices for the CLI level are displayed. When you enter ? on a line by itself or when it is preceded by one or more spaces, a list of all next available choices is displayed.

  • Page 70: Help Command

    This feature is most powerful when the command keyword is known, but the list and format of parameters is not. Refer to Example 2. Example 2 You can terminate an X-100 CLI command with a ? to display the complete help on that command: localhost(config)# mgmt ? Possible completions:...

  • Page 71: Partial-Keyword

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 Possible completions: autowizard Automatically query for mandatory elements clear Clear parameter compare Compare running configuration to another configuration or a file complete-on-space Enable/disable completion on space config Manipulate software configuration information copy...

  • Page 72: Upgrading System Software Through The X-100 Cli

    1.0.7_1 localhost# To ugrade the software through the X-100 CLI, do the following: 1. Run the systems software download Privileged EXEC command to download a new software image onto the HM or RBM from an FTP server. If the software download is successful, the command output indicates “Upgrade was successful”.
  • Page 73 On completion, the HM or RBM resets and the user is forced out of the X-100 CLI. Log in again once the X-100 system is back up and running. 4. If the software upgrade fails (due normally to a corrupt load), the system restarts again using the old software image.

  • Page 74: System Provisioning

    Open a web browser and navigate to the IP address that you pinged to bring up the X- 100 WebUI. b. Use a Secure Shell (SSH) client to log on to the X-100 CLI using an SSH connection to the IP address that you pinged. However, SSH version 2.0 client software must be installed on your host computer (SSH version 1.0 can be used, but is not recommended).
  • Page 75 4. Click “Apply” in the bottom right corner for the changes to take effect. Alternately, if you wish to use the X-100 CLI to change this management IP to a static user-assigned IP address (for example, 192.168.1.1/24), enter these commands:...
  • Page 76 To allow for a radio link to be created between an HM and RBM, you must at a minimum initially configure the following for the X-100 system, as follows: 1. Navigate to the “Setup Page (Radio Interface)” sub-page of the X-100 WebUI. 2. Set the Radio Administrative State to “Enabled”.

  • Page 77: Adding Users

    Release 1.0 13.2 Adding Users Adding users to the X-100 system can be done through either the X-100 WebUI or the X-100 CLI. To add users to the X-100 system using the X-100 WebUI: 1. Navigate to the “Admin Page (User Manager)” sub-page of the X-100 WebUI.

  • Page 78: Provisioning Default Versus Individual Service Flows

    With the HM service flow definition set to Use Individual Service Definition, you must configure each RBM service flow and add the RBMs to the X-100 system on an RBM-by-RBM basis. This can be done through either the X-100 WebUI or the X-100 CLI.
  • Page 79 For example, to configure a default, pass-all, bidirectional service flow on the HM for one RBM on the X-100 system using the X-100 WebUI: 1. Navigate to the RBMs page of the X-100 WebUI. 2. Click Add to add an RBM.
  • Page 80 BLiNQ Networks Inc. X-100 User Guide Release 1.0 6. Select the “Destin MAC Address” box and set both values to 00:00:00:00:00:00 to allow for any destination MAC Address. 7. Click Add to add another service flow for the other direction.
  • Page 81 BLiNQ Networks Inc. X-100 User Guide Release 1.0 10. Select the Dest MAC Address checkbox and set both values to 00:00:00:00:00:00 to allow for any destination MAC Address. 11. Click Apply for the changes to take effect. You should now see a message that the RBM was successfully created and is now in the RBM table.
  • Page 82 14. The system should notify you that the running configuration has been successfully copied to the startup configuration. Alternately, for example, to configure a default pass-all, bidirectional service flow on the HM for one RBM on the X-100 system using the X-100 CLI, enter these commands: localhost# //Enter configuration mode...
  • Page 83 BLiNQ Networks Inc. X-100 User Guide Release 1.0 //Create the first service flow for one direction localhost(config-rbm-0c:a1:38:00:00:4f)# service-flows service-flow 1 Value for 'direction' [downlink,uplink]: downlink Value for 'priority' (<unsignedByte>): 0 Value for 'qos service-type' [best- effort,guaranteed-bit-rate]: best-effort //Add the classification rule that allows for any...

  • Page 84: Preambles, Flows, And Network Provisioning

    This chapter describes the role and use of preamble series indices and service flows in provisioning multiple X-100 clusters—a cluster being one Hub Module (HM) configured with its group of up to four Remote Backhaul Modules (RBMs) (referred to as 1:2, 1:3, or 1:4 clusters), as well as the provisioning...

  • Page 85: Preamble Operational Description

    Hubs default to a preamble series value of ‘0’, while RBMs default to a preamble series of ‘all’. Thus, by factory default, RBMs accept X-100 system service from and register with the best serving Hub pointed in their direction using any preamble series index value.
  • Page 86 0 to 31: RBMs can also be set to two different preamble operating modes through the ‘Setup (Radio Interface)’ X-100 WebUI sub-page for RBMs: Automatic Scan Mode—When the RBM preamble series index is set to “All” (the system •...
  • Page 87 BLiNQ Networks Inc. X-100 User Guide Release 1.0 The Defined Preamble Mode is typically used when the operator seeks to connect to a specific hub module. For normal network operation, BLiNQ recommends that the preamble on RBMs be set to a specific index value using the Defined Preamble Mode rather than use Automatic Scan Mode.

  • Page 88: Provisioning Hm Service Flow Definitions

    14.4 Provisioning HM Service Flow Definitions As explained in Chapter 13 “System Provisioning”, the HM has two service flow definitions for allowing communication to be established with a RBM, set through the ‘RBMs (RBM General)’ X-100 WebUI sub- page for HMs: Use Default Service Definition •...
  • Page 89 Using the X-100 CLI for the HM: localhost(config)# radio localhost(config-radio)# preamble series-index 0 Using the X-100 CLI for RBM 1, RBM 2, RBM 3, and RBM 4, respectively: localhost(config-radio)# preamble scanning-mode scan-series-list localhost(config-radio)# preamble series 0 value 0 Second 1:4 Neighbor Cluster: Repeat the steps done for the first 1x4 cluster, replacing the ‘preamble series’...

  • Page 90: Appendices

    Remote Backhaul Modules (RBMs) and their internal antennas. RF energy fields may be present when the transmitter is on. Do not install the X-100 system in a location where it is possible for people to stand or walk •...

  • Page 91: List Of Acronyms

    BLiNQ Networks Inc. X-100 User Guide Release 1.0 15.2 List of Acronyms Table 13 List of Acronyms Best Effort Best Signal Indication B-SON Backhaul – Self-Organizing Network CINR Carrier to Interference plus Noise Ratio Command Line Interface Class of Service...
  • Page 92 BLiNQ Networks Inc. X-100 User Guide Release 1.0 Quality of Service Remote Backhaul Module Radio Frequency RFEC Radio Frequency Environment Characterization SFTP Secure File Transfer Protocol SISO Single Input Single Output Small form-factor pluggable Service Level Agreement SNMP Simple Network Management Protocol...
