- Page 1 HOT SWAP SYSTEM FOR V-LOCK LITHIUM ION BATTERIES Model MVQUICK OPERATING INSTRUCTIONS Revision 1.2 www.blueshape.net Printed in Malta 2009...
- Page 2 Introduction MVQUICK is a hot swap system to be installed as a battery interface between the camera (or any other V-lock compatible device) and the battery pack. The main purpose is to allow camera battery replacement without any power interruption through an automatic detection of the battery removal.
- Page 3 UPS is providing continuity power. When operating as the main power source, the runtime provided by MVQUICK depends by the state of charge of its internal battery and the actual power consumption. The LED array displays the state of charge based on the internal...
- Page 4 How to check the state of charge Out from the box, the internal battery of MVQUICK has a state of charge of about 50% or higher. To verify the state of charge: When the external battery is installed: Press the “Check” button to verify the state. The LED will stay on for about 3 sec showing the state (see table above).
- Page 5 60 minutes. To avoid this, just press the LED button once to restart the countdown and prolong the operating period. It is preferable to switch off MVQUICK after a working session or before storage to minimise the power consumption and the self- discharge.
-
Page 6: Technical Specifications
Battery communication bypass When MVQUICK is used with BLUESHAPE V-lock batteries or with batteries having the same communication protocol, it is possible to obtain data communication between the device and the battery. The data switch selector can be moved by a pointed object towards ON to enable or towards OFF to disable data communication. - Page 7 Warranty BLUESHAPE MVQUICK is warranted to be free from defects in materials, workmanship and functionality for a period of 18 months commencing from the date of purchase. This warranty shall not apply to any products or parts of, that have been subjected to misuse, negligence, accidental or abnormal conditions of operation.
- Page 8 NEW CELL TOP Srl VIA LIGURIA 4-6, 42124 REGGIO EMILIA, ITALY TEL. +39 0522 518556 FAX. +39 0522 277084 WEB: www.blueshape.net EMAIL: info@blueshape.net...
