www.mkdiamond.com
MK-VTS/50
OWNER'S MANUAL,
OPERATING INSTRUCTIONS
& PARTS LIST
Revision 113
03.2019
Manual Part No. 167790
Caution: Read all safety and operating instructions
before using this equipment. This owners manual
MUST accompany the equipment at all times.

Advertisement

Table of Contents
loading

Related Manuals for MK Diamond Products MK-VTS/50

Summary of Contents for MK Diamond Products MK-VTS/50

  • Page 1 MK-VTS/50 OWNER'S MANUAL, OPERATING INSTRUCTIONS & PARTS LIST Revision 113 03.2019 Manual Part No. 167790 Caution: Read all safety and operating instructions before using this equipment. This owners manual MUST accompany the equipment at all times.
  • Page 2 INTRODUCTION We at MK Diamond want to congratulate you on selecting the MK-VTS/50 Floor Scraper. We are certain that you will be pleased with your purchase. MK Diamond takes pride in producing the finest products in the industry. Operated correctly, your MK-VTS/50 Floor Scraper should provide you with years of quality service.

  • Page 3: Table Of Contents

    TABLE OF CONTENT SAFETY Page Safety Message/Alert Symbols, Warnings Hazard Symbols General, Maintenance, Saw Safety California proposition 65 Message Electrical Requirements and Grounding Instructions 9-12 Safety Label Locations Blade Changing / Installation OPERATION Wheel Adjustment Handle Adjustment Transportation Blade Usage TYPE OF TEAROUTS Removal Materials Subfloor Surfaces...

  • Page 4: Safety Message/Alert Symbols, Warnings

    MK-VTS/50 FLOOR SCRAPER SAFETY Read and follow all safety, operating and maintenance instructions. Failure to read and follow these instructions could result in injury or death to you or others. Failure to read and follow these instructions could also result in damage and/or reduced equipment life. Safety warnings and guidelines do not by themselves eliminate danger.
  • Page 5 MK-VTS/50 FLOOR SCRAPER SAFETY PERSONAL PROTECTIVE EQUIPMENT ALWAYS wear approved respiratory, head, ear and eye protection when operating this machine. ACCIDENTAL STARTS! Before starting the engine/motor, be sure the ON/OFF switch is in the OFF position to pre- vent accidental starting. Place the ON/OFF switch in the OFF position before performing any service operation.

  • Page 6: General, Maintenance, Saw Safety

    MK-VTS/50 FLOOR SCRAPER SAFETY USE PROPER APPAREL DO NOT wear loose clothing, gloves, neckties, rings, bracelets, or other jewelry that may be caught in moving parts. Non-slip footwear is recommended. Wear protective hair cover- SECURE WORK Clamps or a vise should be used to hold work whenever practical. Keeping your hands free DO NOT OVERREACH Keep proper footing and balance at all times by not overreaching.
  • Page 7 MK-VTS/50 FLOOR SCRAPER SAFETY CHECK FOR DAMAGED PARTS Before using a power tool, check for damaged parts. A guard or any other part that is damaged should be carefully checked to determine if it would operate properly and perform its intended function. Always check moving parts for proper alignment or binding.

  • Page 8: California Proposition 65 Message

    MK-VTS/50 FLOOR SCRAPER SAFETY SILICA DUST WARNING Grinding/cutting/drilling of masonry, concrete, metal and other materials with silica in their composition may give off dust or mists containing crystalline silica. Silica is a basic compo- nent of sand, quartz, brick clay, granite and numerous other minerals and rocks. Repeated and/or substantial inhalation of airborne crystalline silica can cause serious or fatal respira- tory diseases, including silicosis.
  • Page 9 MK-VTS/50 FLOOR SCRAPER SAFETY ELECTRIC MOTOR SAFETY For maintenance care and operation of the electric motor, refer to your electric motor instruction book- let furnished with the electric motor. Protect the electric motor from dust as much as possible and keep ventilating openings clean.

  • Page 10: Electrical Requirements And Grounding Instructions

    MK-VTS/50 FLOOR SCRAPER SAFETY ELECTRICAL REQUIREMENTS AND GROUNDING INSTRUCTIONS In order to prevent potential electrical shock and injury, the following electrical safety precautions and symbols should be followed at all times! WARNING In case of a malfunction or breakdown, grounding provides a path of least resistance for electric cur- rent to reduce the risk of electric shock.
  • Page 11 MK-VTS/50 FLOOR SCRAPER SAFETY WARNING Use only extension cords that are intended for outdoor use. These extension cords are identified by a marking "Acceptable for use with outdoor appliances; store indoors while not in use." Use only extension cords having an electrical rating not less than the rating of the product.
  • Page 12 MK-VTS/50 FLOOR SCRAPER SAFETY WARNING Use of undersized extension cords result in low voltage to the motor that can result in motor burnout and premature failure. MK Diamond warns that equipment returned to us showing signs of being run in a low voltage condition, through the use of undersized extension cords,will be repaired or replaced totally at the customer’s expense.

  • Page 13: Safety Label Locations

    MK-VTS/50 FLOOR SCRAPER SAFETY SAFETY LABEL LOCATIONS Safety labels contain important safety information. Please read the information contained on each safety label. These labels are considered a permanent part of your saw. If a label comes off or becomes hard to read, contact MK Diamond or your dealer for a replacement.

  • Page 14: Blade Changing / Installation

    MK-VTS/50 FLOOR SCRAPER BLADE INSTALLATION BLADE CHANGING / INSTALLATION CAUTION Blades are sharp. Handle with care. Failure to do so could cause bodily injury. • Dull blades greatly reduce cutting ability. Re-sharpen or replace as needed. • Proper blade size and placement per job type greatly affects performance.

  • Page 15: Wheel Adjustment

    MK-VTS/50 FLOOR SCRAPER GENERAL OPERATION WARNING Do not operate machine around excessive moisture areas, such as abatement work and flooded pool areas without GFCI wall plug. Failure to do so could cause damage in machine or injury to operator. Before using the machine, check for any broken, worn or damage parts and replace them immediately.

  • Page 16: Handle Adjustment

    MK-VTS/50 FLOOR SCRAPER GENERAL OPERATION HANDLE ADJUSTMENT After the proper wheel adjustment is achieved, adjust the handle length. Simply loosen the thumbscrews located on the frame and the handle will slide up and down. Locate the most comfortable height and tighten the thumbscrews to lock the handle in place.

  • Page 17: Blade Usage

    MK-VTS/50 FLOOR SCRAPER BLADES BLADE USAGE Start with a narrow blade, then increase blade size to optimize cutting pass. Narrower blades work easier than wider blades and usually clean the floor better. Wider is not always better or faster. Proper blade size and placement, depending on material and sub-floor type, greatly affects performance.

  • Page 18: Removal Materials

    MK-VTS/50 FLOOR SCRAPER TYPES OF TEAROUTS REMOVAL MATERIALS Never remove flooring containing asbestos without fully understanding proper WARNING state and federal procedures and guidelines. • Sheet vinyl, solid vinyl, rubber tile, urethane or PVC sheet roofing, will need to be scored for best removal results.

  • Page 19: Subfloor Surfaces

    MK-VTS/50 FLOOR SCRAPER TYPES OF TEAROUTS SUBFLOOR SURFACES • WOOD: When working over plywood sub-flooring, try to run machine in the same direction as the grain in the wood. Blade in most cases should be bevel down. On solid wood floors, like plank, run in the same direction as the plank, not cross grain or cross plank.

  • Page 20: Thermal Overload Protection

    MK-VTS/50 FLOOR SCRAPER MAINTENTANCE THERMAL OVERLOAD PROTECTION The Thermal Overload manual reset switch is located on the bottom of the connection box of the elec- trical motor. If an extreme internal temperature is sensed, the switch will “trip” and the motor will shut off automatically.

  • Page 21: Repairs

    MK-VTS/50 FLOOR SCRAPER MAINTENTANCE REPAIRS If your tool is damaged, contact MK Diamond for a return authorization number and return the entire tool. • Shipments are not accepted without a return authorization number. • COD or freight collect shipments will not be accepted.
  • Page 22 MK-VTS/50 FLOOR SCRAPER EXPLODED VIEW MK-VTS-50 PN 167676 OPTIONAL ACCESSORY OPTIONAL ACCESSORY OPTIONAL ACCESSORY...
  • Page 23 MK-VTS/50 FLOOR SCRAPER PARTS LIST MK-VTS-50 PN 167676 ITEM NO. DESCRIPTION PART # QTY. LEG, WHEEL 06-500-25 WHEEL, REAR 8X1.75X .625 150LB 06-500-29 AXLE WELDMENT, BS-50 06-500-30 SHOCK ABSORBR 60 NATURAL RUBBE 06-505-102 BEARING, FLANGE, 2 BOLT, SBLF-206 06-5280-6 MTR, 1HP, 1P, 60HZ, BS-50...
  • Page 24 MK-VTS/50 FLOOR SCRAPER PARTS LIST MK-VTS-50 PN 167676 ITEM NO. DESCRIPTION PART # QTY. ASSY, WARNING LABELS, VTS-50 167847 ASSY, CARTON VTS-50 168043 PALLET, VTS-50 SCRAPER 168044 SCREW, SET, #10-24 X 3/16 168055 NUT, HEX, SFL, 5/16 -18 5000810 KNOB, THRD 1/2 -13 X 1.5 CP-10098 COLLAR, 1.13 ODX .625 ID .5 WIDE...
  • Page 25 MK-VTS/50 FLOOR SCRAPER EXPLODED VIEW & PARTS LIST POWER CORD FROM ITEM 8 MOTOR CORD FROM ITEM 8 ITEM NO. DESCRIPTION PART # QTY. SCREW, #6-32 X 1/2 PAN HEAD SELF TAPPING 153459 COVER, SWITCH 154301 SWITCH, TOGGLE 125V 20A...

  • Page 26: Accessories

    MK-VTS/50 FLOOR SCRAPER ACCESSORIES ACCESSORIES ITEM NUMBER DECRIPTION Vinyl Scraper blade 167619 7-3/8" x 3" Vinyl Scraper blade 167796 10" x 3" PG-10130 Tool Holder...
  • Page 27 NOTES...

  • Page 28: Ordering Information

    ORDERING & RETURN INSTRUCTIONS ORDERING INFORMATION You may order MK Diamond products through your local MK Diamond distributor or, you may order direct from MK Diamond. When ordering direct from MK Diamond, please have the following information ready before calling: •...

  • Page 29: Warranty

    © COPYRIGHT 2019, MK DIAMOND PRODUCTS, INC. ALL RIGHTS RESERVED. The MK Diamond logo is a registered trademark of MK Diamond Products, Inc. and may not be used, reproduced, or altered without written permission. All other trademarks are the property of their re- spective owners and used with permission.
  • Page 30 NOTES...
  • Page 31 NOTES...
  • Page 32 MK-VTS/50 FLOOR SCRAPER OWNER'S MANUAL, OPERATING INSTRUCTIONS & PARTS LIST MK Diamond Products, Inc. 1315 Storm Parkway Torrance, CA 90501 Toll-Free: (800) 421-5830 Phone: (310) 539-5221 Fax: (310) 539-5158 www.mkdiamond.com...
