Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
General . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Manufacturer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
European Representative . . . . . . . . . . . . . . . . . . . . . . . .2
Name and Model . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
Machine Description . . . . . . . . . . . . . . . . . . . . . . . . . . . .2
EC Declaration of Conformity . . . . . . . . . . . . . . . . . . . . .3
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Stage Load Specifications . . . . . . . . . . . . . . . . . . . . . . .5
Floor Level Specifications . . . . . . . . . . . . . . . . . . . . . . . .5
Required Working Environment . . . . . . . . . . . . . . . . . . .5
Main Electrical Power Supply . . . . . . . . . . . . . . . . . . . . .5
Ground Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
Note: Please read and understand these User Instructions before working with or using the
Diva
Note: If you need additional information about the Diva Air Transporter, contact the
Wenger Corporation using the information below.
©Wenger Corporation 2011
Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448
Air Transporter.
®
Questions? Call..... 001-507-455-4100 • www.wengercorp.com
Diva
Operation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Ambient Light Levels . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Control Devices . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
Tower Set Up . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Power Failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Abnormal Uses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .11
Replacement Parts . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Training . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Printed in USA 02/11
User Instructions
Air Transporter
®
Part #185A462-01
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Wenger Diva 185A455
Summary of Contents for Wenger Diva 185A455
-
Page 1: Table Of Contents
Note: If you need additional information about the Diva Air Transporter, contact the Wenger Corporation using the information below. ©Wenger Corporation 2011 Printed in USA 02/11 Part #185A462-01 Wenger Corporation, 555 Park Drive, P.O. Box 448, Owatonna, Minnesota 55060-0448 Questions? Call..001-507-455-4100 • www.wengercorp.com... -
Page 2: Introduction
Wenger Corporation. Wenger Corporation does not assume any responsibility for any errors that may appear in this manual. In no event will Wenger Corporation be liable for technical or editorial omissions made herein, nor for direct, indirect, special, incidental, or consequential damages resulting from the use or defect of this manual. -
Page 3: Ec Declaration Of Conformity
D eClArATioN oNforMiTy Manufacturers Name: Wenger Corporation Manufacturers’ Address: 555 Park Drive Owatonna, MN 55060 USA Declare that the machinery described below complies with applicable health and safety requirements of Part 1 of Annex 1 of the Machinery Directive 98/37/EC taking full account of the additional requirements of Machinery Directive 2006/42/EC and the EMC Directive. -
Page 4: Installation
If a product return is necessary, your representative will issue a return authorization. This is your sole remedy for breach of this warranty. Should you have a question or problem with any Wenger product, don’t hesitate to call, even if the product is past warranty. It’s important to us that all our customers be satisfied. -
Page 5: Stage Load Specifications
9.7 m (384 inches) high, 3 m (120 inches) to 3.6 m (144 inches) wide and length 1.4 m (56 inches) deep weighing up to 885 Kg (1950 lbs). The machine is only intended to lift and transport Wenger Diva Acoustic Towers. -
Page 6: Operation
peRation MbieNT iGhT evels A Diva Air Transporter is only intended for use inside buildings where there will be artificial lighting. Ambient lighting must be sufficient for operators to see inside and around all parts of the machine. There is no need to provide additional internal lighting under the hood. Maintenance personnel can see all internal parts when access covers have been removed and there is no need to provide additional internal lighting. -
Page 7: Tower Set Up
peRation oWer In normal operation, a Diva Air Transporter can be maneuvered manually with ease once the air cushion has been inflated. There is little risk of fatigue by the operator. The force needed to push the assembly is 13.6 Kg (30 lbs) and this is not excessive. Acoustic towers weigh up to 885 Kg (1950 lbs) and are positioned manually, with minimal physical effort. - Page 8 peRation continued oWer CoNTiNueD 2. Lift the release lever on the handle to extend the release lever air pads to the floor. handle 3. Place the Diva Air Transporter under the acoustic tower with the lifting hooks under the lifting brackets. caution caution Two or more people must...
- Page 9 peRation continued oWer CoNTiNueD 4. Turn on the Diva Air Transporter air blower by pushing in the power switch. Note: Make sure that both lift hooks engage the lifting brackets. power switch 5. Slowly pull the Diva Air Transporter to move the acoustic tower approximately 1.5 m (5 feet) out from the others.
- Page 10 peRation continued oWer CoNTiNueD 7. With one person pushing the Diva Air Transporter and a second person ensuring that the way is clear, slowly move (no faster than 50 cm per second) the acoustic tower to the performance location. Be careful to not push the acoustic tower into any obstructions on the stage floor or above the stage floor (such as ceiling panels, etc).
-
Page 11: Power Failure
Examples of abnormal uses to which a Diva Air Transporter should not be put. Wenger takes no responsibility for the safety of machines if they are used for any purpose other than the intended purpose as specified in these instructions. -
Page 12: Replacement Parts
Should there be a need for replacement parts, contact Wenger at 001-507-455-4100. Raining Training is provided at the time of installation.
