BRAVER UPS
(Uninterruptible Power System)
User's Manual

Advertisement

Table of Contents
loading

Related Manuals for HELIOR BRAVER

Summary of Contents for HELIOR BRAVER

  • Page 1 BRAVER UPS (Uninterruptible Power System) User’s Manual...

  • Page 2: Safety Caution

    Safety – CAUTION!  This UPS utilizes voltages that may be hazardous. Do not attempt to disassemble the unit. The unit contains no user replaceable parts. Only authorized service personnel may perform repairs.  Internal battery voltage is 12V DC. Sealed, lead-acid, 6 cells battery. ...
  • Page 3  Servicing of batteries should be performed or supervised by personnel knowledgeable of batteries and the required precautions should be taken. Keep unauthorized personnel away from batteries.  When replacing batteries, replace with the same number of the sealed lead-acid batteries. ...

  • Page 4: System Description

    System Description Front Panel – 1. Power Switch & LED Indicator 2. LED Indicators -- AC Mode: Green Lighting Battery Mode: Yellow Flashing Fault Mode: Red Lighting 1. Power switch 2. LCD display...

  • Page 5: Back Panel

    Back Panel – 1. Output receptacles 2. AC Input with AC fuse 3. Modem/Phoneline Surge Protection 4. Communication Port...
  • Page 6 Installation and Operation Installing the UPS is as easy as following the steps shown. Be aware of the Power Switch must be kept in the “ON” position, otherwise, the UPS will be disabled and your equipment will not be protected during a power failure. 1.
  • Page 7 4. Computer Connection Connect one computer-related device into each of the power receptacles supplied on the back of the UPS (maximum of three devices). 5. Modem / Phone line Connection Plug incoming internet line into the “In” socket at the back of the UPS. Use one more Internet line cable and plug one end of the Internet line cable to the “Out”...
  • Page 8 Just simply press the power switch to turn on the UPS. 9. Green Power Function Braver UPS is equipped with Green Power Function. For saving power and protecting battery, the method of deep discharging...
  • Page 9 Software Installation – WinPower-XP WinPower-XP is a UPS monitoring software, which provides user-friendly interface to monitor and control your UPS.

  • Page 10: Troubleshooting

    Trouble Shooting Symptom Possible Cause Remedy No LED display 1. Battery weak. 1. Re-charge battery up to 8 hours. on the front 2. Battery defect. 2. Replace with the same type of panel. battery. 3. Power switch is not 3. Press the power switch again. pressed.

  • Page 11: Specifications

    Specifications MODEL Braver UPS CAPACITY 400VA 600VA 800VA Voltage Range 170-280V AC Frequency 40Hz above Voltage 230V AC Voltage Regulation + / - 10% (Battery Mode) Frequency 50Hz or 60Hz OUTPUT Frequency Regulation + / - 1 Hz (Battery Mode)
