Summary of Contents for Cisno NCC-N01
- Page 1 CISNO Espresso Machine Simplify your coffee life User Manual Model #:NCC-N01...
-
Page 2: Table Of Contents
INTRODUCTION IMPORTANT SAFEGUARDS MUST DO FOR FIRST USE PACK CONTENTS TECHNICAL SPECIFICATIONS DIAGRAM OF PARTS QUICK START GUIDE INSTRUCTIONS FOR USE CAUTION WARNING POWER SUPPLY CLEANING PROBLEMS AND SOLUTIONS WARRANTY... -
Page 3: Introduction
When this machine is used, some parts get hot and need to cool down. Proper care and maintenance will ensure the long life of the CISNO Espresso Machine and its trouble-free operation. Save these instructions and refer to them often for cleaning and care tips. -
Page 4: Must Do For First Use
7.Never touch the heating disc and steam vent of machine when and immediately after this machine is used for making an heating the coffee 8.The significant contents concerning safety must be read carefully to protect you and others from injury and damage. MUST DO FOR FIRST BREW 1.Install battery pack Battery pack is inside the battery chamber of machine. -
Page 5: Pack Contents
(hold button for 5 seconds) to internally clean the machine before making your first coffee PACK CONTENTS 1 x CISNO Portable Espresso Machine 1 x 12V Car Charger 1 x 12V 2A Power adapter 3 x Interchangeable AC plug(EU US UK) -
Page 6: Diagram Of Parts
DIAGRAM OF PARTS Air Vent Water Lid Water Cavity DC Port Battery Indicator Light Button Button Indicator Battery Chamber Light Battery Pack Main Body Battery Cap Capsule Cap Drinking Cup Battery Cap Lock AC Adaptor Car Charger UK Plug EU Plug US Plug... -
Page 7: Quick Start Guide
QUICK START GUIDE 1.Turn the machine upside down then unscrew drinking cup and capsule cap 2.Place capsule into capsule insert then press it down until flat. Note : ONLY use genuine original line Nespresso Capsules instead of Nepsresso compatible capsules(piercing needle would not puncture the foil quite enough if you use other brand's pods and it will damage the machine as well). - Page 8 3.Screw on capsule cap and drinking cup then turn it back upright 4.Unscrew water lid and pour water to max level mark,Then screw on water lid Max level line (here indicates the maximum water level) 5.When using room temperature water to boil: hold button for 2 seconds then hear 1 beep and wait 8-10 minutes.
-
Page 9: Instructions For Use
INSTRUCTIONS FOR USE 1.To make coffee boiling water. Hold the button for at least 2 seconds until the buzzer makes one sound and the battery indicator light goes on. The button indicator light shows white breathing light, and the heating disc starts heating. When the water temperature is up to the suitable temperature, the buzzer makes two sounds, and the water pump starts pumping. -
Page 10: Caution
CAUTION Never use the machine near a fire Notice the use of power plug To unplug the power plug, it is necessary to hold the power plug, not the power cable Be careful about scalding or injury Never open the air vent water lid during or immediately after heating before the water in the water cavity is pumped out Never touch the hot water, other high temperature position during or immediately after use of the machine... - Page 11 Never shake the machine body during use. General safety instructions, the machine may topple and fall(for fear of scalding) Never unplug the power plug with wet hands(risk of electric shock) Never destroy the power cable or power plug. Without permission, never machine, damage, excessively bend, forcefully pull or twist the power cable or power plug, place the power cable or power plug near a heating object or under heavy load, or squeeze the power...
-
Page 12: Power Supply
POWER SUPPLY Use of vehicle power supply(12V Car Charger) The machine can be electrified by the vehicle power supply to charge the battery pack, or to heat and pump the coffee. This can also occur without the battery in the machine. Use of adaptor Insert the DC plug of adapter into the DC 12v port on the back of the machine. -
Page 13: Problems And Solutions
CAUTION! During wiping, notice that your fingers must not touch the internal piercing knife because the knife is sharp and may result in injury. PROBLEMS AND SOLUTIONS Q: How do I charge the removable lithium battery? A: There is an AC Adaptor and 12V car charger. The battery can only be charged whilst connected inside the machine. -
Page 14: Warranty
12 month from the date of purchase. If you become aware of a defect in parts or workmanship during this time, CISNO will, at its sole discretion, provide for repair or replacement of your machine in accordance with the terms herein. - Page 15 Products Nestle S.A. or its affiliates manufacture or endorse this product in any way nor have any association with this product or the CISNO brand. Made in China. CISNO® is a trademark of USA OKEBA Industries Inc. All rights reserved c 2017 patent pending.
