Messenger Pro User Manual

Fully digital side lobe-free steerable line array
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MESSENGER PRO
User Manual
Version 1
© 2016, MESSENGER PRO, member of PAX ProAV Group

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Messenger Pro and is the answer not in the manual?

Questions and answers

Summary of Contents for Messenger Pro Messenger Pro

  • Page 1 MESSENGER PRO User Manual Version 1 © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 2 Revision History Date Version Revision 2016/01/07...

  • Page 3: Table Of Contents

    ................................. 43 Layers 5.1.4.12 ................................. 44 Birds Eye 5.1.4.13 ................................. 45 Properties 5.1.4.14 ................................. 45 Message Library 5.1.5 ................................46 Error & Warning Lobe Assembler Output ........................... 46 5.2.1 Overview ................................46 © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 4 ........................... 107 6.6.1 ................................107 6.6.2 ................................108 Batcher 6.6.3 Capturer ................................109 6.6.4 Detector ................................110 6.6.5 ................................0 Event 6.6.6 ................................111 Logic Control 6.6.7 ................................112 Logic Gate © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 5: Contents

    ................................124 Lobe Output Mixer ........................... 129 6.8.1 ................................129 Standard Mixer Selector ........................... 131 6.10 VOIP ........................... 132 6.10.1 VoIP Receive ................................132 6.11 Custom Component ........................... 136 Contact Infomation © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 6: About This Manual

    Supported Firmware Version The table list the supported firmware version that is applicable for your Messenger Pro. If you would like to know the added/modified topics in this user manual, please see [History Revision] chapter on page 2, which has details on what the listed updated functions.

  • Page 7: Notice Signs

    Notice Signs There are two types of signs can be used in this manual. The type is closely related to the effect that may be caused if it is not observed. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 8: Copyright

    All rights reserved. No part of this document may be reproduced or transmitted in any form by any means, electronic, mechanical, photocopying, or otherwise, without the prior written permission of the publisher. The content and illustrations are subject to change without prior notice. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 9: Messenger Pro Overview

    Messenger Pro - Fully digital Side Lobe-Free Steerable Line Array The Messenger Pro is equipped with two fully floating line inputs, speech and background music, and can be adapted for optimum performance separately. This results in better music and speech performance in situations where high quality music performance and superior speech intelligibility are demanded.
  • Page 10 The ADI DSP chipset and a sample rate of 48 kHz ensure a wide frequency response, up to 22kHz for crystal- clear sound quality and an impressive low frequency response. This, paired together with the patented algorithm and side lobe free suppression for speech reinforcement makes the Messenger Pro a fully versatile steerable line array.
  • Page 11 Messenger Pro Overview area required, it can be louder than in earlier array technology. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 12: Quick Start

    Power up the Messenger and the Box (non-AIO type) and make sure the Box's power LED is on. Messenger (Body): 230V. Messenger (Box): 100-240V. 3. Contact your Messenger Pro dealer to get the latest software version. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 13 Before searching the Messenger devices in the LAN, the device information area will be shown as empty. Now click the [Auto Search] button under the Devices tab, and then click the [Clear] button, the device list will appear after few seconds. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 14 7. Click the [Mapping] button on the the grid of your Messenger unit for compiling. Then click [Store] button to store/save the setting into your Messenger unit. After that, you can start to configure the further settings! © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 15 Quick Start Mapping If user would like to change the network setting of Messenger to fit your LAN, please go to Device Management < Machine Setting < Ethernet Adapter. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 16: Product Features

    3 dB over a distance of 100 m. The Messenger Pro has the unique quality that the acoustical center which can be moved over the array to match with required mounting heights. This can be achieved because each driver is separately powered and processed and therefore all variations between a symmetrical and an asymmetrical arrangement can be made by a simple push on a button.
  • Page 17 The vertical opening angle can be adjusted in steps from 45 down to 5 degrees. The Messenger Pro All-in-one-version(AIO) series contain the following products: Messenger-M 12 Loudspeakers - 1686 mm. 94 dB to 25 m.

  • Page 18: Appearance

    Thanks to its embedded control panel, the All-In-One version is much easier to wire with. All cables can be wired from a hole at the bottom of the Messenger as shown in the picture below: © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 19: Control Panel

    This control panel is assembled at the bottom of the Messenger all-in-one version, open the outer case to wire. Balanced Audio Output connector: S = Shield. + = Hot audio signal. - = Cold audio signal. Balanced Audio Input connector: © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 20: Led Indicators

    Supply fault 24V (Backup). Supply fault AC(for AIO). Control IN1 Lights off when circuit Open; lights up when short circuit. Control IN2 Lights off when circuit Open; lights up when short circuit. RS232 TX © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 21: Characteristics

    Maximum output 0dBu Input Impedance Ω 1kHz@sine wave (Balanced) Output Impedance Ω 1kHz@sine wave (Balanced) Sample rate Only 1 selection Max SPL 93dB pink-noise at 25m S/N ratio Horizontal Disp degrees © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 22: Wiring

    The Messenger AIO unit connects with each other using RS485 connectors as shown in the picture below: Each AIO needs to be powered by its own AC input. One PC can search and control all the Messenger units in the LAN. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 23: System Functionality

    After every power shutdown, or software reboot, the Messenger will startup in its last saved configuration. Messenger Pro software allows the complete audio systems with a multitude of similar or different devices to be configured, supervised and controlled centrally from a single user interface. A library of control and monitoring elements, (GUI) graphical user interface, is provided and includes items such as volume control faders, various metering, 8 bands of EQ, Limiting, Mixing, quick-buttons, display elements etc.

  • Page 24: Installation

    MESSENGER PRO User Manual 5.1.3 Installation Follow the Installwizard to install Messenger Control. After the installation is finished, double click the icon to open the Messenger Pro software. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 25: Window Layout

    Show the window title of all opened windows (design, components control windows) for quick access. Dock Panel-Component Template: A dock panel on the left side of software which contains all devices and DSP components you can use to build up and design your system. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 26: File

    Opens the “Open...” dialog box which allows you to select a path and open a saved file. Recent Files: Quick access to the last opened file. Close Close the opened files. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 27: Edit

    Select all DSP components in the graphic editor. o Select All Connectors Select all wires in the graphic editor. 5.1.4.3 View Each item in the [View] menu can open a specific window to perform settings modification or management © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 28: Geometry

    Opens the window of Device Management that discovers the devices over network and maintenance. User Management Opens the window of User Management for editing the users of configuration file. 5.1.4.4 Geometry Zoom In © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 29 Ruler Unit: Specifies ruler unit of the graphic editor. There are three types of units: Inches Centimeters Pixels Show Grid Shows or hides the grid of the graphic editor. Snap to Grid © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 30 Hide a layer. All objects belonging in that layer will become invisible. o Select Layer: Selects a layer to be current. Any newly created object will belong to the current layer. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 31: Component Editing

    "Align Left" function to align several components to the left, the left will depend on the reference. o Normal In Normal mode, the reference is the place in the graphic editor. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 32 "Align Left" function, then the mouse cursor will change to a blue cross and will ask you to choose exactly where the reference is located. All the selected components will be aligned to this point. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 33 You can select several elements (by maintaining a left click and moving the mouse you will have a selection square) and then pack the elements. This function uses a reference which depends on the reference mode. Space © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 34 These functions resize the components. You can select several components and adjust them to have the same dimensions. All the selected components will have the size of the component on the top left of the window. Center © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 35 This function splits grouped components to a single component. It's the reverse of the Group function. Wiring Mode Normal Line Select Normal Line if you want to draw the wire with different angles. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 36: Operation

    Most part of those windows have short access in the Tools bar. We are going to introduce you every items. To © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 37 When Ateis Studio is online with devices, designing configuration is not allowed. Offline In the offline state, you can modify the configuration file. Audio Enable Enables audio of Ateis devices. Audio Disable Disables audio of Ateis devices. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 38: Tools

    MESSENGER PRO User Manual 5.1.4.7 Tools Language: Choose the language which runs in Messenger PRO software. Skin: By changing the skin you can modify the global style (color and appearance) of the windows. You can choose one of the skin in the list.
  • Page 39 System Functionality Mc Skin © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 40 MESSENGER PRO User Manual London Liquid Sky Communication: Select the net card in your PC which is connected to the device via Messenger PRO software. Route Table: Search and communicate the devices that are in different LAN. Search Local Version Machine: Click to search the Messenger devices with local version.

  • Page 41: Window

    In the bottom of the window menu, you will find all the opened windows of your project. By selecting of the windows in the list, the window will comes on the first displaying level. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 42: Resource Manager

    When the path changes, this copies files from the original path to the new path. Pages of Resource File There are various types of files which can be managed by Messenger Pro, each one corresponds to a page in the resource manager. The files are listed below:...

  • Page 43: Object Tree

    Each design window can be separated into multiple layers. Every object in the design window belongs to a layer. By clicking menu [View > Layers], you can open the layers window. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 44: Birds Eye

    When the design area is huge, Bird's Eye gives an overview for the user to easily understand the graphic layout of the design. By clicking the menu [View > Bird's Eye], you can open the Bird's Eye window. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 45: Properties

    [View > Properties], you can open the properties window. 5.1.4.14 Message Library Message Library provides an easy interface to manage messages used in Messenger Pro. By clicking the menu [View > Message Library], you can open the message library window.

  • Page 46: Error & Warning

    Same color at ear level, means an even signal pattern. Using the cursor or a reference line, the signal decay versus distance can be visualized by means of figures or as graph. This is a typical lobe picture: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 47 The Messenger XL, therefore, can be positioned at various heights starting from 1.60 up to 4 meters, counting from the audience ground section. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 48: Edit Lobe

    Click the [Lobe Settings] button. The cursor movement and the parameter settings of the three lobes can be established here. Please refer to [Lobe Output component] chapter to know more about each element on lobe setting. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 49 1 to symmetrical on driver number 13 to reversed a-symmetrical on the top driver number 24. (In case of the XL). The number at the bottom of the slider indicates the driver number that corresponds with the acoustic center. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 50 Then to start to set the height, depth, height of the Messenger, frequency etc. you want to evaluate. Please refer to [Lobe Output component] chapter to know more about each element on lobe rendering. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 51 One of the unique features of the Messenger is that you can adapt the acoustic center to accommodate for the required mounting height. Depending on the mounting position of the speaker, you can change © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 52: Examples

    Placement height : 1.80 Nearfield row : at 5 mt Far field row : at 35 mt Balcony : no Relative Level of Lobe 1: 3 dB Relative Level of Lobe 2: -12 dB © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 53 Far field : at 65 mt Balcony : no Relative Level of Lobe 1: 0 dB Relative Level of Lobe 2: - 6 dB Relative Level of Lobe 3: - 6 dB © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 54 Placement Height : 3.17 Nearfield : at 10 mt Far field : at 26 mt Balcony : no Relative Level of Lobe 1: - 4 dB Relative Level of Lobe 2: - 0 dB © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 55 Placement Height : 6.27 Nearfield : at 25 mt Far field : at 53 mt Balcony : yes Relative Level of Lobe 1: - 0 dB Relative Level of Lobe 2: - 2 dB © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 56: Device Management

    Select the [Device Management] tab or open it through the menu [View > Device Management]. The Device Management window consists of four parts: Device Information: © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 57: Search And Connect

    Before searching the Messenger unit in the LAN, the device information area is empty as shown in the picture below. Click the [Auto Search] button under the Devices tab, the device list will appear after a few seconds. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 58: Health Source

    2. Select the device on the device list and click [Health Source] button on the right grid. 3. After a pop-up window appears, check the device that ticks in the box. This action can only be ticked one at a time. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 59: Machine File System

    Root directory of files display on the front window of Machine File System. Folders and files refreshing could be easily executed without any time limitation. Functionality of modify folders include add , move, rename, delete , load folders. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 60: How To

    Move: Select the files you wish to put into on [Folders] window, then click [ ] button to open the [Select the folder] window, and choose the folder you wish the files to put into. See the Picture below, © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 61 Please make sure the software's version is correct as it will affect the file storing location. Step 2: Create a new folder To create a new folder,right clicks your mouse on the icon and types in the folder name. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 62 Add / Delete: Add or delete the folder. o Result: Result of the setting. Eg: [wait for apply] o Apply: Confirm the setting. o Cancel: Cancel the setting. Step 3: Load the file © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 63 Please note that if the selected files you have loaded from the device cannot be seen on the Machine File System, please restart the software again by using the [Run as administrator] (Right click on your mouse to open the window). Please see the picture below, © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 64 MESSENGER PRO User Manual Step 4 : Add and Save the selected file into the folder Go back to the [Save] window. Then, click [Add] button to open the [Resource Manager] window. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 65 Then, select the file you have just add in, and click [Save] button. It will automatically refresh again, then the file you have added in will be listed on the top grid of © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 66 Select the WAV format on the upper right grid, and click [...] on Parameter at the upper right grid to open the window [file name]. Parameters: o Level: To increase and decrease audio volume. Please refer to mapping table below and see the actual db with its corresponded level. Level © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 67: Machine Log

    5.3.4 Machine Log This function allows users to read the log of Messenger device. 1. Open the Device Management Window. 2. Click [Log] to open the log window. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 68: Read Version

    To know which version is loaded in the device and which version is available with the current Ateïs Studio software: 1. Open the Device Management Window. 2. Click [Read Version] to open the Version window. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 69: Machine Setting

    If the version numbers or Network ID are marked in red which means the Firmware needs to be updated or the device hasn't fully connected with Messenger Pro, please see the next chapter to perform a update. Press [Ctrl + F3] to open 4 hidden firmware grids in Read Version window: MCU / DSP / FPGA / AEC 5.3.6...
  • Page 70 [Write] button. The adjustment is required in period for the component which is associated with the time such as the scheduler. NTP: You can use the NTP server to sync the clocks on your LAN. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 71 In case of using the daylight saving time, switch to the Daylight Saving tab to set. Ethernet: Once enable the Ethernet Monitor, the fault message will show in the log list when the communication is broken. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 72: Reset Machine

    Display the information of IP, Subnet, Gateway of your device. 5.3.7 Reset Machine This function allows users to reboot the Messenger device by Messenger PRO software. 1. Open the Device Management Window. 2. Click [Machine Reset] to open the Machine Reset window.

  • Page 73: Reverse

    System Functionality 5.3.8 Reverse This function allows users to reverse designs from Messenger PRO devices. 1. Open the Device Management Window. 2. Before perform the "Reverse", the user needs to make sure the firmware version fits the current version, please perform "Read Version" and "Update" before revert to a design.

  • Page 74: Update

    1. The reverse will take a few seconds and a pop-up window will appear to ask you to save the file if a design has already existed due to that Messenger PRO software only edits one file a time. 2. Click Yes/No and the design will be loaded completely in few seconds. Now the user can edit the design.

  • Page 75: 3Rd Party Control

    3rd party devices. To activate this setting, right click the element and click on menu [3rd Party Control > Single] After the assignment is completed, you will receive a preview of the string used to control the Messenger © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 76: 3Rd Party Control List

    Element Field of Grid The name of the element listed. Channel of Grid The channel to which the component element belongs. Device Name of Grid Lists the element containing the component. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 77: Machine Set Table

    Odd / Even / Stop bit 5.4.6 3rd Party Control Commands This window shows a preview of the element that is assigned for 3rd party control. In the left part, a grid © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 78: Commands

    For example : Room1 volume, value = 3 dB 'S TX' + IR0013 + 'E XT' + 'CS ' + 'CR ' 'S TX' + IR0013 + 'E XT' + 'CR ' © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 79: Write Parameter Command

    Answer is always ACK CR or None, depend on communication protocol settings. 5.4.6.1.6 Messenger Fault Read Command Command string = F Data Section Data Section Answer is always (Reply Messenger Fault) © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 80: Reply Messenger Fault Command

    DSP_COMM_ERROR Bit 010 DSP_CODE_ERROR Bit 011 FPGA_COMM_ERROR Bit 012 INPUT1_20K_ERROR Bit 013 INPUT2_20K_ERROR Bit 014 POWER_24V_ERROR Bit 015 POWER_LOW12V_ERROR Bit 016 POWER_12V_ERROR Bit 017 POWER_48V_ERROR Bit 018 POWER_DC24V_ERROR Bit 019 POWER_AC_ERROR © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 81 AMP2_SCLK_ERROR Bit 072 AMP3_SCLK_ERROR Bit 073 AMP4_SCLK_ERROR Bit 074 AMP1_PLL_LOCK_ERROR Bit 075 AMP2_PLL_LOCK_ERROR Bit 076 AMP3_PLL_LOCK_ERROR Bit 077 AMP4_PLL_LOCK_ERROR Bit 078 AMP1_OVER_TEMPER Bit 079 AMP2_OVER_TEMPER Bit 080 AMP3_OVER_TEMPER Bit 081 AMP4_OVER_TEMPER © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 82 MATLAB_2XL35_CORRUPTION Bit 149 MATLAB_2XL45_CORRUPTION Bit 150 MATLAB_L25_CORRUPTION Bit 151 MATLAB_L35_CORRUPTION Bit 152 MATLAB_L45_CORRUPTION Bit 153 MATLAB_M25_CORRUPTION Bit 154 MATLAB_M35_CORRUPTION Bit 155 MATLAB_M45_CORRUPTION Bit 156 MATLAB_XL25_CORRUPTION Bit 157 MATLAB_XL35_CORRUPTION Bit 158 MATLAB_XL45_CORRUPTION © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 83: Components

    Object Tree(Devices Page) List the devices which are ready for drag and drop to a device design window. Some of the objects correspond to physical devices and some are only symbols. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 84: Delay (Basic)

    The first is by adjusting element Delay time, the second is by adjusting the Element Temp and Distance to compute the delay time. Element Type can be switched between two modes. Control Window: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 85 *3: The maximum value of Distance depends on the type of Delay (Basic) Type Maximum 1.62 m 50ms 16.25 m 100ms 32.5 m 200ms 65 m 500ms 162.5 m 1000ms 325 m © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 86: Dynamic

    Dynamic 6.2.1 DNM ER Component Template: Component Appearance: Description: DNM component is basically the same as the A.N.G. component but it uses the DNM microphone as the S.M input of A.N.G. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 87 Paging Activity Decrease Zone Dead Zone Increase Zone Fast Increase Zone Sensing Mic -100.0 -100 Hz-dB Level C/Sensing Mic -100.0 -100 Level Output Level -100.0 -100 Differential Level -100.0 -100 Element Description: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 88 Lights up when the paging is active while the P.M. is above the mode threshold. Decrease Zone: Indicates that the AGC gain is decreasing. Dead Zone: Indicates that the AGC is not changing. Increase Zone: Indicates that the AGC gain is increasing. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 89: Ducker

    The Ducker is a type of "sophisticated switch" which allows you to attenuate or switch off the signal arriving in input A automatically when the chosen level (in dB) is perceived in input S. Control Window: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 90 Set enough "Hold time" to avoid the unexpected background level during the speeches breaks. Release Time: Adjusts the fade-out time of the (A) signal when the Ducker is no longer working. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 91 Set as 700(ms) which is enough to avoid the music increasing during the speech breaks. Audio Depth: Set as -20dB for constantly hearing the music during the speech but in a very low level (depending on the context). © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 92: Gate Mono

    MESSENGER PRO User Manual 6.2.3 Gate Mono Component Template Component Appearance: Description: The Gate allows you to cut off the signal below the chosen threshold. Control Window: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 93 Adjusts the time between the end level's detection and the end of the Gate operation. Release Time: Adjusts the fade-out time of the signal when the Gate is no longer working. Depth: Attenuates the level when the Gate is active. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 94: Limiter

    This component limits the output level (dB) within the threshold parameter. Control Window: Element Properties: Name Initial Minimum Maximum Precision Unit Hard Clipping Limiting Threshold (dB) -60.0 Release time (1ms) 5000 Gain reduction (dB) -45.0 Hard Clipping: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 95 Reflects the current amount of gain reduction. Graphical Control Window: Axis o X: Input signal level(dB) o Y: Output signal level(dB) Control Points o Blue: Adjusts Threshold. o Red: Adjusts Threshold Range. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 96: Ethernet Igmp Audio Stream

    This component is an Internet steam player which locates and plays the audio stream users save on sever. The Internet audio stream which you save on sever can simply compose into the certain format (RTP) and play the audio stream via this component. Application: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 97 Click to open the window of channel setting. Application: There are several types as the server of Ethernet audio stream: Terra Server, Terracom device or computer software such as VLC Media Player. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 98: Audio Matrix

    Audio Matrix provides a clear interface to manage all audio in/output, here you can: Audio routing with priority. Audio routing with RAC-5/8. Volume control depends on audio source. Announcement has different volume with music. Send network stream. Play network streams. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 99 Always set the SIP's priority as "1", or the call will be left aside. The SIP includes Call, Paging Group and Pre-define Message. Select inputs by RAC allows the user to switch the source manually, and the priority will be locked: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 100 Check the checkbox to enable the audio output channels. The current audio outputs will show at the upper-right of the page. For example, it shows SIP during a SIP call. Stream Out: Sends network streams. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 101 48k sampling. SHOUTcast/Icecast URL: Type the URL of the Shoutcast or Icecast. Stream Multicast (LAN Only): Receive RTP (Real-time Transport Protocol) packet from IGMP. Type the Multicast Address and its port. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 102: Equalizer

    ("Q") can be widened or narrowed. EQs are capable of making much more precise adjustments to sound than other equalizers and are commonly used in sound recording and live sound reinforcement. Control Window: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 103 *1: The initial value of Frequency depends on how many bands of a PEQ. These initial values are average distribution in range from 10 to 22000 Hz. Element Description: Bypass all: Bypasses the EQ (all the frequency bands). Bypass: Bypasses only the selected frequency band. Q(Bandwidth): © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 104 Some speaker systems don't use separate woofers and tweeters to cover the bass and treble frequencies but rather include full-range drivers. However, this speaker system © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 105: Input

    This component controls the input signal's parameters and monitors it. The analog input modules represent the physical analog inputs which are accessible of your device. Analog input and output modules are added automatically to the fixed configuration of DSP window. Control Window: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 106 Sensitivity Phantom Power Overload Volume -50.0 -50.0 20.0 Signal Level -60.0 20.0 Overload Thd. -20.0 20.0 Element Description: Bypass: Bypasses audio of the channel. Mute: Mutes the audio of the channel. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 107: Logic

    Indicates if an audio signal presents above -30 dB from the chosen 'Sensitivity'. Level: The Signal output level of the channel. Overload Thd.: A threshold value to determine the signal of a channel is overloaded or not. Logic 6.6.1 Component Template: Component Appearance: © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 108: Batcher

    NC pin (No Change): NC pin indicates when the input ''remains the same'', the NC will give the pulse to let the next component which is mapped with the Batcher component to identify the © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 109: Capturer

    R pin (Reset): R pin indicates the ''trigger'' which allows to capture the updates changes of input to output, which is based on the [Ready] Mode. CR pin: CR pin indicates to compulsively lock down, which is based on the [Disable] mode. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 110: Detector

    The Detector component can be used when the output is based on the range of input you select. Please note that the setting of input range is according to the binary code. Control Window of Detector Setting: © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 111: Logic Control

    In additions, the default number of blank mapping pin will be 0. 6.6.6 Logic Control Component Template: Component Appearance: Description: © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 112: Logic Gate

    Control Window: Elements: On/Off: Outputs logic signal 0 or 1. 6.6.7 Logic Gate Component Template: Component Appearance: Description: This component allows to delay the output time. Control Window: © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 113: Logic Meter

    Falling Response Time (100ms): The time of output delay when a falling signal is triggered. The unit of time is 100ms, therefore, the actually value is N x 100 ms. 6.6.8 Logic Meter Component Template: Component Appearance: Description: © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 114: Paulse Control

    Component Appearance: Description: The Pulse Control component allows to have a duration of 1 second for pulse output when the status of Input Pin has been changed. Please see the picture below, © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 115: Status Control

    When the input is triggered, the output will result in a duration of 1 second of pulse. 6.6.10 Status Control Component Template: Component Appearance: Description: The Status Control component allows the status output to get locked and remains at the last status when © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 116: Not

    The Input Pin N and Output Pin N are mutually corresponded, they will not be affected by other Pin. 6.6.11 NOT Component Template: Component Appearance: Description: This component performs logical NOT operation. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 117 Components 6.6.12 OR Component Template: Component Appearance: Description: This component performs logical OR operation. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 118: Output

    MESSENGER PRO User Manual 6.6.13 Output Component Template: Component Appearance: Description: This component is corresponding to the contact outputs. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 119: Scheduler

    The pins on the top side enables(signal = 1) or disables(signal = 0) the scheduler belongings to the channel. The pins at the button generate the pulse signal depending on the settings of the component. Control Window: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 120 The right part of the window shows the settings of the scheduler which will be switched to the corresponding scheduler. General Settings: Name: The name of the scheduler. Start Time: The start time of the scheduler. Stop Condition: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 121 The triggering mode defines the rule of triggering a pulse to output. Periodic: The interval is the time between two triggers. Cyclic: The Occurrence parameter determines the cycle type of triggering. There are five types © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 122 "Exception Duration" allows the user to edit a list for the exceptions of the triggering. Each exception consists of a start time and a stop time. During the exception time all triggering will be masked. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 123: Serial Signal Buffer

    F Pin: F Pin will output the binary codes or binary combinations which are converted from decimal codes or combinations after the F Pin is triggered. The binary combinations can be user-defined depending on the applications. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 124: Output

    Description: The lobe output modules represent the physical analog outputs accessible of your device. Analog input and output modules are added automatically to the fixed configuration of DSP window. Control Window: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 125 Mutes or unmutes the output channel, the LED lights in red while the channel is muted. Signal: Indicates if a channel is activated or not. Level: The signal output level of the module. Overload thd.: Sets the threshold of the overload indicator. Lobe Settings: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 126 MESSENGER PRO User Manual Element Properties: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 127 Focal point: If you do not know the steering angle, you can also fill out the data required for the focal point that will exactly bring the lobes acoustic center through your measuring point. Aiming Height: Set the aiming height when rendering the measurement of focal point. Relative Level: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 128 20dbB less than Lobe 2. Aiming Distance: Set the aiming distance when rendering the measurement of focal point. Placement Height: Set up the exact height between Messenger PRO and ground. Placement Degree: Set up the exact directing angle of Messenger PRO. Lobe Render: Simulation: o Frequency: The lobe results at the given frequency.

  • Page 129: Mixer

    The matrix module is similar to the standard mixer. The main difference is that there is no ability to make independent mixes for each output channel. So, the module primarily used for simple routing purposes. Control Window: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 130 Sets the input level of the channel. Output Mute: Mutes or unmutes the channel output. Output Level: Sets the master output level of the channel. Routing Turns on/off the input on the particular output channel. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 131: Selector

    A simple selector allowing the user to select which input is routed to the single output. Control Window: Element Properties: Name Initial Minimum Maximum Precision Unit Input Select Element Description: Input Select: Open the drop-down list to select the input. © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 132: Voip

    The VoIP component allows the device such as PPM-IT5, IP phone, SIP server, Terra-K etc. to call via LAN/ WAN. G.711, G.722, L16 and MP3 format can be supported by MESSENGER PRO. The communication protocol via SIP protocol or Voxnet format.
  • Page 133 Precision Unit Mute Level Mute: Mute or unmute the channel input. Level: The level of the channel. Setting Element of [Setting] Window: Server: o IP: The connected IP of SIP server. © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 134 Call button. Application: The picture below shows using the VoIP component to paging to Messenger PRO on Terra Server: 1. Select the Input---IN1, IN2, IN3 2. Select the Controller( the connected input type)---Logic, RAC 5, RAC 8, RAC Analog, Edge Trigger Button, Push to Talk 3.
  • Page 135 Components © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 136: Custom Component

    Initial Component. Control Window: © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 137 Custom Component list. Right click on the component and click [Export] function. After the configuration has been exported, the configuration will be listed on the list of Custom Component. See the picture below, © 2016, MESSENGER PRO, member of PAX ProAV Group...
  • Page 138 MESSENGER PRO User Manual © 2016, MESSENGER PRO, member of PAX ProAV Group...

  • Page 139: Contact Infomation
