Parts included in with your new propeller:
Propeller (assembled)
Loctite 243
.125" diameter 1" long dowel pin
M5x35 Screw
Retaining Ring
Spring Cap
Remove your existing propeller down to the retain-
ing ring. If you have a retaining sleeve, you will
need to remove the sleeve and the collar. Install the
spring cap and retaining ring provided. (Retaining
Ring shown).
Clean shaft if needed. Install included standard
dowel pin into shaft. (Retaining ring shown)
Installing X-Propeller Manual
www.dive-xtras.com
4433 Russell Rd, STE 106
Mukilteo, WA 98275 USA
Tel: 425 296 6570
Fax: 425 493 9320
Advertisement
Table of Contents
Related Manuals for DIVEX X-Propeller
Summary of Contents for DIVEX X-Propeller
- Page 1 Installing X-Propeller Manual www.dive-xtras.com 4433 Russell Rd, STE 106 Mukilteo, WA 98275 USA Tel: 425 296 6570 Fax: 425 493 9320 Parts included in with your new propeller: Propeller (assembled) Loctite 243 .125” diameter 1” long dowel pin M5x35 Screw...
- Page 2 Mukilteo, WA 98275 USA Tel: 425 296 6570 Fax: 425 493 9320 Place the X-Propeller onto the shaft. Line up the dowel pin and the X-Propellers insert for proper installation. (The float plate should be able to move around in its pocket with your finger.
