- Page 1 DIGIMAT Wireless Nurse Call system User Guide RANDA ELEKTRONİK SAN. TİC. LTD. ŞTİ. www.randa.com.tr...
-
Page 2: Table Of Contents
Wireless Nurse Call systems Contents 1. General Overview and functions...........2 2. System Contents…………………………………………………..5 3. System Installation and setup………..........8 3.1. Bedhead Call Unit..............8 3.2. Handset Unit...............9 3.3. WC/ Bathroom Call Unit..........10 3.4. Door Mounted Warning Lamp........11 3.5. Nurse Call Panel ..............12 4. -
Page 3: General Overview And Functions
Wireless Nurse Call systems 1. General Overview and functions Digimat Wireless Nurse Call Systems, has been designed and manufactured for the purpose of informing the personals working in hospitals, health care institutions and home cares of an a emergency situations immediately, shortening patient's waiting for intervention period and responding to patient requests quickly. - Page 4 Wireless Nurse Call systems If the nurse finds the situation needs an emergency help she could first press the green tick icon then the nurse call button on the bedhead unit. This case, the assigned room number on the display room will appear with the word "EMERGENCY"...
-
Page 5: System Contents
Wireless Nurse Call systems 2. System Contents Bedhead Call Unit It is the unit that gives a light and audio warning that allows the nurse to be called from the patient's room. It performs the call initiation and termination. Features: ... - Page 6 Wireless Nurse Call systems WC / Bathroom Call Unit It is a corded device that is used to initiate an emergency call from WC/ bathroom in patients' rooms. Features: It has a fabric cord that ends with a plastic handle which makes it easy to pull and a make an emergency call ...
- Page 7 Wireless Nurse Call systems Nurse call Panel It's the place on which the rooms that made the call, the nurse room information, the date and time and the emergency consultation information is stored and displayed. Features: It is an intelligent unit with microcontroller inside. ...
-
Page 8: System Installation And Setup
Wireless Nurse Call systems System Installation and setup 3.1. Bedhead Call Unit Bedhead call unit is wireless and works with battery. In order to start the call process the red icon shown in figure 1 must be pressed. When the call is started, it gives audio and light warning. -
Page 9: Handset Unit
Wireless Nurse Call systems 3.2. Handset Unit In order to use this device the bedhead unit should be placed and the cable connection is established. In order to send a call the button with the red nurse icon shown in figure 2 must be pressed, as the call starts it generates audio and light warning. -
Page 10: Wc/ Bathroom Call Unit
Wireless Nurse Call systems 3.3. WC/ Bathroom Call Unit This device is wireless and works with battery. Calls that comes from the WC/ Bathroom device always have a priority over the other calls. In order to start a call, the cord handle must be pulled as shown in figure 3. The room number from which the call came and the "EMERGENCY"... -
Page 11: Door Mounted Warning Lamp
Wireless Nurse Call systems In order to make the nurse finds and reaches the room that started the call easily the over door (door-mounted) warning lamp lights with red light. The nurse arrives at the room and cancels the call by pulling the cord handle in the WC / Bathroom call unit. -
Page 12: Nurse Call Panel
Wireless Nurse Call systems 3.5. Nurse Call Panel The nurse call panel shown in figure 5 works with plug-in. The settings of the system must be done as described in the following sections. ATTENTION! In order to be able to receive a call in the wireless system, you need first to register the call buttons and introduce them to the system. - Page 13 Wireless Nurse Call systems Exit: Used for exits from the menu Input: Used to enter to the first menu and its setting, at the same time used as a confirmation key. Forward: to navigate through menus. Back: Allows navigate backwards through menus. Works in reverse with the forward button.
- Page 14 Wireless Nurse Call systems Figure 7: device's standby case Menu tabs are explained as follow: TYPE: RF 5 Used for operating mode selection. mode should be selected from the menu for the system setup. To set up the device, enter the menu tab (with the number 2 button).
- Page 15 Wireless Nurse Call systems If the button is already identified by the device: To identify the call button to the system, login to the menu with the login button. A 4 line screen will appear in front of you, if you want to define a bedhead or WC/Bathroom call unit, you should first enter its type followed by the ID you want to give it.
- Page 16 Wireless Nurse Call systems ATTENTION! Do not pull the plug when the device returns to factory settings (it will count to 100 when resetting). TRN S: in order to use the optionally added pager device you need a data transmitter. This tab is used for setting the frequency value on this data transmitter.
- Page 17 Wireless Nurse Call systems In order to do that you should login to the menu with the enter button. Scroll to and enter the "PAGER" submenu with the forward and back keys. The 4 digits that appear identify the last 4 digits of the Pager's ID. The complete 7 digits Pager's ID is stored as standard 100xxxx, the digits indicated by X are the ones visible on the screen.
-
Page 18: Possible Problems And Solutions
Wireless Nurse Call systems 4. Possible problems and solutions Problems That May Possible Solutions Occur 1. Check the system power connections. There is no image comes to 2. Check the whether there is energy in the the panel cable plugged in the adapter. 3. - Page 19 Wireless Nurse Call systems 1. Make sure you performed the ID definition The panel displays the call information incorrectly. correctly. 2. If the registration was not established correctly, ensure to define the buttons again from the entr tab. 3. If the problem is not resolved, reset the system and perform the settings again.
- Page 20 Wireless Nurse Call systems coming and being deleted of the button you suspect it's causing the problem. 2. Cut off the energy of the parasitic sources that affects the system. If the problem persists, please inform our technical service. Panel is being locked. Please inform our technical service.
- Page 21 Wireless Nurse Call systems If needed, have your device serviced and repaired by an authorized service center. HUMAN AND ENVIRONMENT RELATED WARNİNGS Keep the device away from heat sources such as radiators and ovens. Do not throw the device in the garbage box that you use at home. ...
-
Page 22: Warranty Conditions
Wireless Nurse Call systems SERVICE COVERAGE SERVICE SCOPE: TS 13426 AUTHORIZED SERVICES-WIRELESS PERSONNEL CALL SYSTEMS' RULES. STANDARDS SUITABLE SERVICE TS 13426 AUTHORIZED SERVICES-WIRELESS PERSONNEL CALL SYSTEMS. TS 13401 AUTHORIZED SERVICES-CALL DEVICES. TS 13149 WORK PLACES-COMPUTER SERVICES-GENERAL RULES 5. Warranty conditions 5.1. -
Page 23: Points To Take Under Consideration
Wireless Nurse Call systems 5.4. Within the warranty period, in case of malfunction due to erroneous assembly all repairs and needed materials or modified parts will be carried out without any charges. 5.5. Despite the consumer's right to repair, if ... -
Page 24: Service Stations
Device has been dropped or damaged. 7. Service Stations Randa Elektronik Ltd. Şti. Çamlıca Mah. Anadolu Bulvarı No.20 Timko Sokak No:6 Gimat/Yenimahalle - Ankara Phone number: + 90 312 472 55 44 Fax: + 90 312 472 56 47...
