Summary of Contents for A.B.Energy ABE 300
- Page 1 ABE_300 BIOGAS CHILLER Operating Instructions Refrigerator for biogas ABE_300 Rev. 1.00...
- Page 3 Los ifractores quedan obligados a la ABE_300 indemnizaciòn por danos y perjucios. Se reservan Son marcas registradas de A.B.Energy. todos los derechos, en particular para el caso de Las otras designaciones que figuran en este concesion de Patente o de Modelo de Utilidad.
-
Page 4: Table Of Contents
Le denominazioni di altri prodotti menzionati in questa parte di terzi può violare i diritti di proprietà. documentazione possono essere marchi il cui uso da INDEX ALARM CONTACT ..........13 OPERATION OF THE FRIDGE ......12 ANALOG INPUT ..........22 ANALOG INPUT CALIBRATION ...... -
Page 5: General Warnings
Warnings to the operator Dear customer, before starting work, please read this manual! It contains warnings and important data, compliance with which will guarantee the availability of equipment, making you achieve savings on maintenance costs. Thus, the use of this equipment will be greatly facilitated and get reliable measurement results. - Page 6 Warnings to the operator Attention It means that there will be death, serious injury to persons and / or considerable damage to property, unless you take precautionary measures. Warning It means that there may be death, serious injury to persons and / or considerable damage to property, if you do not take precautionary measures.
-
Page 7: Guarantee
Warnings to the operator Warning This unit operates by electricity. The opening of the refrigerator make available certain parts of the apparatus that may be under dangerous tension. Therefore, only suitably qualified personnel may initiate actions on this unit. Qualified person If assistance is not qualified on the fridge or failure to follow instructions given in this manual, there may be serious injury to persons and / or considerable damage to property. - Page 8 The fridge ABE_300 is in line with the EC Directive 89/336/EEC "Low Voltage". According to the above mentioned EC directives to the declarations of conformity are kept available to the competent authorities at: A.B.ENERGY S.R.L. VIA AMENDOLA, 340 13836 COSSATO (BI)
-
Page 9: Safety Concerns
Installation Warnings Safety concerns Warning Certain parts of this unit are under dangerous tension. Warning The device should not work at a risk of explosion. Mixtures of explosive gases shall not be measured. If the sample gas introduced appliance may contain flammable components above the lower explosion limit (UEG) must grant the security measures required by the relevant experts. -
Page 10: Dimension
User manual ABE_300 Key Features ABE_300 fridge for biogas. The ABE_300 is used for: Cool the sample gas or biogas. Separation by lowering the temperature of the gas condenses to 2 ° C. Condensate drain through a peristaltic pump. ... - Page 11 User manual ABE_300 Biogas Chiller ABE_300...
-
Page 12: Installation
User manual ABE_300 Installation The key dimensions of the refrigerator are shown on the drawings earlier. Warning It 'necessary to maintain a free space for the ventilation of ABE_300 fridge in correspondence with the cooling fan. This area should never be less than 50 mm. Warning The installation site must be protected from weathering, the temperature must never fall below 0 °... -
Page 13: Alarm Contact
User manual ABE_300 Alarm contact The terminal block the reporting of failures is configured as follows: CONDENSA ALARM PIN 3 COMUNE PIN 8 CONTACT NO PIN 7 CONTACT NC FRIDGE ALARM PIN 6 COMUNE PIN 2 CONTACT NO PIN 1 CONTACT NC Biogas Chiller ABE_300... -
Page 14: Keyboard
User manual ABE_300 Structure and characteristics FRIDGE ABE_300 SCREEN LCD Large ¼ VGA (320 * 240 pixels). Backlit screen, high brightness, ability to vary the contrast. High level of brightness, ability to vary the contrast. Allows simultaneous viewing of all data in the fridge in numerical form and graphic (trend). ... - Page 15 User manual ABE_300 Power Connector The fridge start and red light comes on by pressing the red button on the right side. POWER CONNECTOR The system displays the startup screen of the system and starts the initialization phase that lasts about five seconds, as this stage will automatically switch to the main screen.
- Page 16 User manual ABE_300 Function keys Pressing the F1 key displays the main screen. Pressing the F2 key you can display different data in graphic format (trend). All variables are handled by the refrigerator stored in its internal memory and can support up to 4600 samples.
- Page 17 User manual ABE_300 Main screen MAIN SCREEN The main screen which are displayed in numerical form, all the variables read by the system. (1) The first line in the upper right displays the date and time. The internal clock works even when the fridge is switched off, constantly updating the date. (2) The reference value of temperature (in degrees Celsius).
-
Page 18: Trend
User manual ABE_300 Trend Pressing the F2 key you can display different data in graphic format (trend). TREND All variables are handled by the refrigerator stored in its internal memory and can support up to 4600 samples. Pressing the keys under the symbol up or down you change the variable to display (temperature gas output, percentage of control, ambient temperature, radiator temperature). -
Page 19: Password
User manual ABE_300 Screen password Pressing the F3 key will display the following screen PASSWORD Password: 123456 Inserting the right code is passed immediately in the first configuration page. There are pages of configuration depending on the version. Once inside the configuration you can move from page to page using keys F1 F2 F4. To exit setup and return to the display pages just press the ESC key. -
Page 20: Configuration
User manual ABE_300 Configuration From the main screen by pressing F3 you access the password page, enter the password and press F1 to bring up the following screen. SYSTEM SETUP • Address: If you have multiple devices on the network can be assigned an identification number to the device (option is not used for ABE_300). - Page 21 User manual ABE_300 • Hours operation: Indicates the operating hours of the fridge. • Fan operating hours: Indicates the hours of operation of the cooling fan. • Ore function peristaltica: Select from the hours of operation of peristaltic pump. • Date: The date and time set, selecting the DATA you can reset the date and time correct by the new data in the format (ddMMyyhhmmss).
-
Page 22: Analog Input
User manual ABE_300 Analog input The card has 8 analog converter operated by a high-resolution (24 bit) and programmable gain between 1 and 64. The first 2 channels have an input buffer amplifier made with a high-isolation and gain, the six channels feature a next input buffer gain one negative in common with inputs connected to the earth. - Page 23 User manual ABE_300 How to calibrate analog input For the calibration of each channel to proceed with the following steps: 1. Connect the analogue input signal to zero take on zero value of the channel to write the value of zero. 2.
-
Page 24: Configuration Pid Temperature
User manual ABE_300 Configuration PID temperature From the main screen by pressing F3 you access the password page, introduce the password (123456) and press F4, the following screen appears. SCREEN PID TEMPERATURE • Reference: value of temperature that you want to have on the bottom plate. •... -
Page 25: Screen Errors
User manual ABE_300 Errors screen If the mini detects an alarm immediately displays the error window with the list of all active alarms at the moment. The window of errors can be displayed even with the pressure of the F4 key from the main screen. Pressing the "DEL"... -
Page 26: Power
User manual ABE_300 Power POWER The fridge ABE_300 is powered at 230 volts, power cord included. The protection of the local electric refrigerator ABE_300 is charged to the customer. For protection of the refrigerator, next to the power outlet is a fuse 6 A. The length of the power line for the electrical protection must not exceed 3 meters. -
Page 27: Maintenance
User manual ABE_300 Specification Operational temperature 0 °C / 50 °C Operational pressure -500 / +500 mBar Weight 8,5 Kg Maintenance Attention Working with toxic gases must be ensured that the workplace can not rise to a harmful concentration on health. In case of improper connection of the gas may rise to the danger of accidents due to toxic gases, combustible or explosive. -
Page 28: Reshipment
Fax: +39 015 9233243 info@abenergy.it Repairs For rapid identification and elimination of the causes of incidents Please send the equipment to the following address. A.B.ENERGY S.R.L. VIA AMENDOLA 340 13836 COSSATO (BI) ITALY Tel.: +39 015 9842253 Fax: +39 015 9233243... - Page 29 Appendix EC DECLARATION OF CONFORMITY A.B.Energy S.r.L. Via Amendola, 340 13836 COSSATO (BI) Italia AS MANIFACTURER DECLARE UNDER OUR SOLE RESPONSABILITY THAT EQUIPMENT OF SERIES ABE-1000 AND RELATED ACCESSORIES, TO WHICH THIS DECLARATION RELATES, APPLIED UNDER CONDITION SUPPLIED IN THE USER’S MANUAL,...
