Farpointe Data WRT-4 Installation Manual

Ranger Long-Range Wireless Radio Transmitter
These Operating Instructions are a basic guide in the proper use and care of the Ranger Transmitters. Addi-
tional information may be downloaded from the Farpointe Data website found at www.farpointedata.com;
under Products > Ranger™ Long Range Transmitters and Receivers.
The Ranger Long-Range Wireless Radio Transmitter is compliant with the following organizations:
FCC compliance Statement: This device complies with part 15 of the FCC rules. Operation is subject to the
following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired oper-
ation.
Product can be used without license conditions or restrictions in all European Union countries, including
Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece,
Hungary, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Poland, Portugal, Romania,
Slovakia, Spain, Sweden, United Kingdom, as well as other non-EU countries, including Iceland, Norway, and
Switzerland.
1.0 Description
Wireless Radio Transmitters (commonly known as "clickers") and Long Range Receivers with integrated
antenna form Farpointe Data's ultra-high frequency, long-range identification solution known as Ranger.
Intended for security access control applications, Ranger's wireless communications are based upon a
secure, digital, anti-playback routine
Ranger Transmitters feature one or four-buttons, each corresponding to its own Wiegand output on the
Ranger Receiver. Each Transmitter includes an integrated red LED, used to indicate positive button press as
well as battery strength. They are also equipped standard with a proximity module for use with
Pyramid Series
Farpointe's
2
imity access credential .
2.0 Transmitter Layout
1. Eliminates the risk of code sniffing and unauthorized duplication. As such, the Transmitter must be clicked twice to be
learned by the Receiver upon initial Receiver power up.
2. Formatting of the proximity module matches that of the Transmitter.
1
.
Proximity™ readers. This allows the Transmitter to be used as a close-range prox-
Red Led
1
2
3
4
Buttons 1 to 4
Key Ring Holder
Front
2177 Leghorn Street
Mountain View, CA 94043-1605
Tel: +1-650-964-2615
Web: www.farpointedata.com
Legend
ID Label
Back
Fax: +1-650-988-6687
01602-001 - Rev. 1.2
USA
E-mail: info@farpointedata.com
1 of 2
