Summary of Contents for NAMCO Nam-Gear Nam-Book
-
Page 2: Table Of Contents
Model: EPC-7 Table of contents Specifications…………………………………………………………………………………2 Outlook Description…...…………………………...……………………………..…………3 Power Button Usage…..……………………………………………………………….…….4 U-disk………….…….……………………………………………………..………….……...4 Using Micro-SD Card…….…….…………………………………………….…….….…….5 Keyboard…………….………………………………………………………......5 Touchpad…………..…………………………………………………………......7 Getting Started……..………………………....………………....……….7 Charge the device….…………………………………………………….......7 Turn the device on……….…………………………………………………….….…………7 Wi-Fi Network Setup……….………………………………………………...………...…...7 Desktop……………….…………………………………………………..………………….8 Scree Lock……….……………………………………………………………..…….…..8 Applications……….…………………………………………….……......….9 Battery Management……...…………………………………………………..……………10 Important Safety Precautions………………………………...……………………………11 Caution…………………………..…………………………………………….……………13... -
Page 3: Specifications
Model: EPC-7 Specifications ●Processor: Via WM8850Cortex A9 ●Display: 7"TFT-LCD ●Resolution: 800×480 ●Internal RAM: DDR3 512MB ●Operating System: Android4.1 ●Wireless:802.11b/g ●Internal Memory: 4GBNand Flash ●External Memory: MMC/SD Card ●Support Media format:JPG,JPEG,BMP,PNG,MP2,MP3,MP4,WAV, AAC,WMA,MPEG1/2/4,MJPE,H263,H264 ●Battery: 3.7V 3000mAh Embedded Lithium Battery ●Power: DC 5V 2A Adapter ●Accessories: Adapter, Instruction Manual ●Manufacturer: TOP EIGHT IND.,(SHENZHEN)CO.,LTD. -
Page 4: Outlook Description
Model: EPC-7 Outlook Description Front view Display Power button Right view: USB interface Left view: Headphone SD card slot Microphone interface Top view: RJ45 USB interface DC Jack interface... -
Page 5: Power Button Usage
Model: EPC-7 Power Button Usage Turn On: Press the power button and hold for 2 seconds. Turn Off: Press the power button and hold for 2 seconds →tap Power off→tap OK. Restart: Press the power button and hold for 2 seconds →Tap Restart→tap OK. Airplane mode: Press the power button and hold for 2 seconds →Tap Airplane mode. -
Page 6: Using Micro-Sd Card
Model: EPC-7 the U-disk. Using Micro-SD Card Insert your card into the microSD slot until it clicks into place. It’s OK. Remove microSD Card → Close all applications or documents which have been opened on the card. Tap Settings → Storage →SD card → Unmount this storage device. When it displayed Mount this device and then press the card lightly;... - Page 7 Model: EPC-7 Sleep Num keyboard Users press to change Num mode and then they can input the corresponding number by Num key. Press it again to get back normal mode. Commonly used buttons: Esc: Back Enter: OK Arrow keys: Corresponds to the direction of (up down left right) F1: Browser F3: My Music F4: My Video...
-
Page 8: Touchpad
Model: EPC-7 F10: File Browser F11 (Fn+F1): Calendar F12 (Fn+F2): Settings PrtSc SysRq：Print screen Touchpad Touchpad is a mouse device it can be used as a regular mouse. Touch pad buttons on both sides of the left and right mouse buttons and common features with the same. Note: Do not place heavy objects on the touchpad to avoid being scratched or deformed Getting Started... -
Page 9: Desktop
Model: EPC-7 to return to the Desktop screen. If your Wi-Fi network is set as hidden, it won’t be found by the auto scan. Tap Add Wi-Fi network and follow the prompts to add your network. Desktop 1 2 3 4 6 7 8 9 10 1. -
Page 10: Applications
Model: EPC-7 Can be set to automatically lock screen or quickly press the power button to manually lock screen. The system provides four lock screen style for users. You can enter Settings → Security →Lock Screen to switch. Lock screen displays the following: Tap the unlock icon and drop it to the right and out of the circle to unlock. -
Page 11: Battery Management
Model: EPC-7 backup files to your SD card. Flash player Flash player settings. settings Search engine Google My Music Play and manage audio files. View and manage photo files. My Photo My Video Play and manage video files. News Display the news and the weather through the Internet &Weather Quick and easy access to everyone you want to People... -
Page 12: Important Safety Precautions
Model: EPC-7 The battery is not fully charged out of the box, so it is recommended that you charge the battery for at least 6 hours before you start to use the device. The rechargeable battery is designed and manufactured to be used and recharged frequently. As with all batteries, the capacity of the battery reduces each time it is charged/depleted. - Page 13 Model: EPC-7 near the surface. Do not put the device at the high-temperature, high- humidity or dusty place. not fall or crash the device, do not shock the TFT screen, it may damage the TFT screen. Adjust to suitable volume. If you feel tinnitus, please turn down or stop using. Please charge if you meet those situations as below: A、No power is displayed on the battery icon.
-
Page 14: Caution
Model: EPC-7 Caution: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: ● Reorient or relocate the receiving antenna. ● Increase the separation between the equipment and receiver. ● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. ● Consult the dealer or an experienced radio/ TV technician for help. Caution: Any changes or modifications to this device not explicitly approved by manufacturer could void your authority to operate this equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. This device and its antenna( s) must not be co‐located or operating in conjunction with any other antenna or transmitter. ...
