Fraco FRSM-8000 User Manual

Hydraulic elevating platform

Advertisement

Quick Links

Model
Date of issue
Bulletin n°
Information
All
2006-12-06
U-T-0003-A
Mast climbing work platform
High priority warning: Height of the first and second wall tie
Amendment to all the FRACO platforms User's Guide
Please read carefully the present letter and insert it in all your Fraco User's Guide:
Fraco is changing the anchoring procedure for all types of platforms when using ground base. The most
recent versions of our user's guide are available on our Web site (www.fraco.com). Please refer to them
for installation procedures with regards to changes below.
The two first ties must be at 10 and 20 feet or at the two first accessible structural levels on the building
(max 20').
This new procedure is to upgrade the safety of our platform during the operation of installation and
dismantling.
The platform must be secured by lifting equipment while installing or dismantling the two first ties. Once
the second tie is in place, the installation continues by the usual procedure; reduce load platform (1/2 load)
except the ACT-4 and the anchoring sequence typical for the type of platform in use as shown below:
FRSM-1500, FRSM-3000, FRSM-8000 :
20 feet
ACT-8 et FRSM-20 K :
30 feet
ACT-4 :
40 feet
For more information, contact our Technical Department:
Julie Rainville
Technical Service Director
Fraco Products
T: 800-267-0094 / 450-658-0094
F: 450-658-8905
2001© Les Produits FRACO Products ltée/Ltd.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRSM-8000 and is the answer not in the manual?

Questions and answers

Summary of Contents for Fraco FRSM-8000

  • Page 1 Please read carefully the present letter and insert it in all your Fraco User’s Guide: Fraco is changing the anchoring procedure for all types of platforms when using ground base. The most recent versions of our user’s guide are available on our Web site (www.fraco.com). Please refer to them for installation procedures with regards to changes below.
  • Page 2 User’s Guide All you need to know about the FRACO hydraulic elevating platform FRSM-8000 [English] FRSM-8000 09/2002 user’s guide All rights reserved, Any reproductions in part or in whole is stricly prohibited without the written consent of FRACO Products Ltd...
  • Page 4: Congratulation!

    The platform cannot be sold or rented without this user's guide. FRACO Products Ltd reserves the right to modify the platform or its manual without notice, and will not assume any responsibility for any damage or injury that may occur.
  • Page 5: Table Of Contents

    Standard weight distribution (double mast) • Standard weight distribution (single mast) • How to raise the platform • How to lower the platform • Dismantling the mast, anchor and platform • Moving the platform • Maintenance FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 6: Warning

    3- The operator should be familiar with the user's guide and understand all the functions of the platform. 4- Never assume anything. If you have any questions concerning the operation of the FRACO, STOP! Refer to the proper user's guide. If you are still unsure, do not continue and call FRACO immediately.
  • Page 7: General View

    General view Parts List ITEM DESCRIPTION Elevating unit Mast section Anchor Plank-end guardrail Guardrail bracket Extension Side bracket Freestanding base Stabilizer Jack Wooden jack pad Hydraulic unit Outrigger Access door Guardrail FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 8: Identification Plate

    MODELO Vitesse de déplacement vertical 0-0,05 ft/s vertical travel speed 0-0,05 pi/s velocidad de elevation 0-0,02 m/s MADE IN FABRIQUÉ AU HECHO EN Serial number XXXX Model number Platform number Year of fabrication ©FRACO Products Ltd FRSM-8000 user's guide 09/2002...
  • Page 9: Technical Data

    1 405 lbs Central bridge section 3ft 6 in x 3 ft 1 in x 20 ft / 1,07 m x 0,95 m x 6 m / 595.5 kg (Dimension / Weight) 1 310 lbs FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 10: Part Ii: Installing The Platform

    Part II Installing the platform...
  • Page 11: Distance Between 2 Masts Sections

    17.30 m (56'9'') 18,06 m (59'3") 18 m (60') bridge 19,58 m ( 64'3") 20,35 m (66'9'') 21,11 m (69'3") *The bridge arms must be extended from 5 cm (2'') to 20 cm (8''). ©FRACO Products Ltd FRSM-8000 user's guide 09/2002 II-1...
  • Page 12: Installing The Fraco Platform

    Maximum 1,63 m (64'') for 5 planks 3- Install the FRACO system (elevating unit and base) perfectly perpendicular to the wall at the appropriate ''L'' distance. 4- Make sure that the mast is perfectly vertical and that the base is level and stable.
  • Page 13: Installing The Elevating Unit Ground Base

    2-Install the elevating unit exceeding the base by a perfectly perpendicular to minimum of 25 mm (1"). the wall. WALL "L" Use the appropriate 1.1 m "L" distance (page II-2). (3'7") 2.2 m (7'2") ©FRACO Products Ltd FRSM-8000 user's guide 09/2002 II-3...
  • Page 14: Installing The Elevating Unit (Freestanding Base

    41 cm X 61 cm (16'' x 24'') base with anchors is 30,5 m (100'). Wall "L" "D" Use the appropriate "L" and "D" distances (see page II-2). 3,68 m (12') 1,20 m (48'') 3,80 m (12'6'') II-4 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 15 4-Install the elevating unit on the freestanding base. FIGURE 2 FIGURE 2 5-Bolt the mast couplers to join the two masts together. 6-Tighten the bolts between the mast and the freestanding base. ©FRACO Products Ltd FRSM-8000 user's guide 09/2002 II-5...
  • Page 16: Hydraulic Unit

    Installation 1-Place the hydraulic unit in the adapters on the elevating unit. 2-Lock the hydraulic unit in place with two Ø19 mm X 100 mm (Ø3/4" x 4'') pins and cotter pins. II-6 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 17: Extension

    1 m (3'4") between the extensions. -The maximum extension length is 5 m (16'8"). Ø19 mm X 64 mm (Ø3/4" X 2 1/2") 2 m (6'8") extension 15020031 DETAIL-A 3 m (10') extension 15020042 ©FRACO Products Ltd FRSM-8000 user's guide 09/2002 II-7...
  • Page 18: Bridge Assembly

    (Ø1" X 2 1/4") Ø25 mm X 230 mm (Ø1" X 9") DETAIL-A 6,10 m (20') central bridge section 15020075 6,10 m (20') bridge section 15020053 4,57 m (15') bridge section 15020064 II-8 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 19 1 m, 2 m or 3 m (3'4",6'8" or 10') extension. Before the installation of a bridge, proceed to the installation of the first anchor on both elevating units (see part IV) Extension of 3 m (10') or less Bridge ©FRACO Products Ltd FRSM-8000 user's guide 09/2002 II-9...
  • Page 20 Before the installation of a bridge, proceed to the installation of the first anchor on both elevating units (see part IV) 4 m (13'4") 0,75 m (2'6") Bridge or 5 m (16'8") bridge extension extension II-10 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 21: Outrigger

    The outriggers cannot be deployed more than 2,13 m (7'). Outrigger 19010034 Ø9 mm bolt (Ø3/8") DETAIL-A Upper adapters Lower adapters Outrigger adapter DETAIL-B Pin with washer Wall 25490088 Cotter pin 6 cm (2") 2,13 m (7') Max. DETAIL-C DETAIL-D ©FRACO Products Ltd FRSM-8000 user's guide 09/2002 II-11...
  • Page 22: Side Bracket

    18490046 DETAIL-A DETAIL-B Installation 1-Insert the side bracket in the adapter. (DETAIL-A) 2-Lock the side bracket with a Ø19 mm X 100 mm (Ø3/4" X 4") pin and a cotter pin. (DETAIL-B) II-12 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 23: Guardrail Bracket

    1-Install the guardrail bracket in the hooks at the end of the last extension section. 2-Secure the guardrail bracket and the side bracket with Ø19 m m X 150 mm (Ø3/4" X 6") pins and 2 cotter pins. ©FRACO Products Ltd FRSM-8000 user's guide 09/2002 II-13...
  • Page 24: Flooring

    4 m (13’4’’) extension 5 m (16’8’’) extension 9,14 m (30’) bridge 10,67 m (35’) bridge 12,19 m (40’) bridge 15,24 m (50’) bridge 16,76 m (55’) bridge 18,29 m (60’) bridge II-14 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 25: Guardrail

    1-Install the guardrail in the side bracket and the guardrail bracket. 2-Install the guardrails wherever there might be a risk of falling. 1 m (3'4'') guardrail 17490023 DETAIL-A 60 cm (23'') guardrail 17490012 ©FRACO Products Ltd FRSM-8000 user's guide 09/2002 II-15...
  • Page 26: Extensible Guardrail & Anti-Skid Steel Plate

    Safety pin 4-Secure them with screws or nails on one side only, to allow movement of the bridge arms. DETAIL-A Anti-skid steel plate 70 cm (28'') : 20490319 100 cm (40'') : 20490320 II-16 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 27: Plank Tie & Plank-End Guardrail

    2-Secure them with screws or nails 3-Place plank-end guardrails wherever there might be a risk of falling Warning Never place any load on the planks at any time Plank ties ©FRACO Products Ltd FRSM-8000 user's guide 09/2002 II-17...
  • Page 28: Extension Turnbuckle

    3-Join the long and short part of the extension turnbuckle with a Ø16 mm X 75 mm (5/8" X 3") pin and a cotter pin. (DETAIL-D) 4-Tighten the extension turnbuckle. Extension turnbuckle long part 23050044 Cotter pin Extension turnbuckle short part 23050033 See DETAILS on page II-19 II-18 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 29: Extension Turnbuckle (Details

    DETAIL-A DETAIL-B Cotter pin Extension turnbuckle long part Ø16 mm X 75 mm Ø19 mm X 140 mm ( Ø5/8" X 3") pin ( Ø3/4" X 5 1/2") bolt DETAIL-C DETAIL-D ©FRACO Products Ltd FRSM-8000 user's guide 09/2002 II-19...
  • Page 30 Part III Options/Miscellanous...
  • Page 31: Outrigger Guardrail Iii-1

    3-Insert 50 mm X 100 mm (2" X 4") planks in the outrigger guardrails and secure them with screws or nails. Cotter pin Outrigger guardrail DETAIL-A 17490067 ©FRACO Products Ltd FRSM-8000 user's guide 09/2002 III-1...
  • Page 32: Outrigger Tie Iii-2

    Never place any load on the Ø19 mm X 100 mm planks at any time. (Ø3/4" X 4'') pin Installation only permitted for 1 m to 4m (3'4'' to 13'4'') extensions Outrigger tie DETAIL-A 20490038 III-2 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 33: Single Mast Locking System Iii-3

    4-Adjust the distance between the wheel and the wall to 3 cm (1 "1/4). 5-Tighten the bolt on the outrigger lock. (DETAIL-B) Pin with washer Outrigger lock 204900072 Wheel 20490263 DETAIL-B Cotter pin DETAIL-A ©FRACO Products Ltd FRSM-8000 user's guide 09/2002 III-3...
  • Page 34: Self-Erecting System Iii-4

    When using a self-erecting system, the total permissible load is 1 818 kg (4 000 lbs) uniformly distributed and including workers. Self-erecting boom 20490162 Self-erecting tubes 20490331 20490342 20490027 12mmØ x 250mm (1/2"Ø x 10") DETAIL-A III-4 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 36: Part Iv: Mast And Anchor Installation

    Part IV Mast and anchor installation...
  • Page 37: Erection Of A Mast

    FRACO system. The maximum freestanding height is 11,58 m (38'). 2-Use a fork lift, a boom truck or a FRACO self erecting system to install the masts. 3-Check to make sure that the holes for the anchors are on...
  • Page 38: Anchor Positions

    *-TO INSTALL THE ANCHORS ONLY, it is permited to exceed the last anchor by 6 m (20') with a load less than 1 364 kg (3 000 lbs), two men and tools when the first anchor is installed. IV-2 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 39: Anchor Assembly

    Maximum deployment limit Ø12mm X 100mm (Ø1/2" X 4") pin Turnbuckle extention 23040021 -The length of the central tube may vary depending on the needs. -The turnbuckle may be extended with turnbuckle extention. ©FRACO Products Ltd FRSM-8000 user`s guide 09/2002 IV-3...
  • Page 40 3,53 m (11'7") 2,11 m (6'11") 2,03 m (6'8'') 1,98 m (6'6") 1,88 m (6'2") 3,25 m (10'8") 1,83 m (6') 2,39 m (7'10") 4,14 m (13'7") 2,41 m (7'11") 30° to 45° IV-4 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 41 C-Shorten the right turnbuckle and extend the left one. D-Shorten the left turnbuckle and extend the right one. E-Extend both turnbuckles and the central tube. F-Shorten both turnbuckles and the central tube. ©FRACO Products Ltd FRSM-8000 user`s guide 09/2002 IV-5...
  • Page 42: Anchor Bolted To A Angle Iron

    4-Drill a hole in the angle iron for the central tube. (adjustment TYPE #1) 5-Make sure all the pins are in place and are secured by cotter pins. 6-Lock the anchor in putting the turnbuckles in tension and the central tube in compression. IV-6 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 43: Anchor Bolted To A Structural H-Beam

    4-Drill a hole in the structural H-beam for the central tube. (adjustment TYPE #1) 5-Make sure that all the pins are in place and are secured by cotter pins. 6-Lock the anchor in putting the turnbuckles in tension and the central tube in compression. ©FRACO Products Ltd FRSM-8000 user`s guide 09/2002 IV-7...
  • Page 44: Anchor For A Concrete Structure Or Beam

    6-Lock the anchor in putting the turnbuckles in tension and the central tube in compression. The concrete must have a resistance of 35 MPa minimum Ø16 mm x 127 mm (Ø5/8" x 5'') Wedge bolt or approved equivalent IV-8 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 45: Horizontal Anchor For Concrete Structure

    5-Make sure that all the pins are in place and are secured by cotter pins. 6-Lock the anchor in putting the turnbuckles in tension and the central tube in compression. The concrete must have a resistance of 35 MPa minimum Horizontal concrete anchor 24010030 ©FRACO Products Ltd FRSM-8000 user`s guide 09/2002 IV-9...
  • Page 46: Anchor Welded To A Angle Iron

    4-Weld the plate for the central tube on the angle iron. (adjustment TYPE #1) 5-Make sure that all the pins are in place and are secured by cotter pins. 6-Lock the anchor in putting the turnbuckles in tension and the central tube in compression. IV-10 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 47: Anchor Welded To A Structural H-Beam

    4-Weld the plate on the structural H-beam for the central tube. (adjustment TYPE #1) 5-Make sure that all the pins are in place and are secured by cotter pins. 6-Lock the anchor in putting the turnbuckles in tension and the central tube in compression. ©FRACO Products Ltd FRSM-8000 user`s guide 09/2002 IV-11...
  • Page 48: Anchoring Box For Concrete Floor

    6-Lock the anchor in putting the turnbuckles in tension and the central tube in compression. *-You do not have to use the inner Quick bolt on each plate. Ø 16 mm X 127 mm (Ø 5/8" X 5") Wedge bolt or approved equivalent IV-12 FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 49: Adjustable Anchor For H-Beam

    4-Install the adjustable anchor for the central tube. (adjustment TYPE #1) 5-Make sure that all the pins are in place and are secured by cotter pins. 6-Lock the anchor in putting the turnbuckles in tension and the central tube in compression. ©FRACO Products Ltd FRSM-8000 user`s guide 09/2002 IV-13...
  • Page 50: Part V: Operating The Platform

    Part V Operating the platform...
  • Page 51: Standard Weight Distribution (Double Mast

    The load must be uniformly distributed on the platform. The loading zone is located with in 2 m (7') on both sides of the elevating unit. IMPORTANT Never place any load on the work zone or the traveling zone ©FRACO Products Ltd FRSM-8000 user`s guide 09/2002...
  • Page 52: Standard Weight Distribution (Single Mast

    Standard weight distribution Double mast configuration FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 53: How To Raise The Platform

    At the end of the raising operation make sure that the safety assembly rests on a mast cross bar. The height of the platform (floor of platform) must never exceed the last anchor. ©FRACO Products Ltd FRSM-8000 user`s guide 09/2002...
  • Page 54: How To Lower The Platform

    9-Keep pushing lever "A" until the safety assembly stops on a mast cross bar. 10-Repeat steps 1 to 9 until you reach the desired height. At the end of the lowering operation make sure that the safety assembly rests on a mast cross bar FRSM-8000 user's guide 09/2002 ©FRACO Products Ltd...
  • Page 55: Dismantling The Mast, Anchor And Platform

    8- Take off the last remaining anchor, the last mast section and the elevating unit. IMPORTANT: These instructions concern the dismantling of a regular FRACO FRSM-6000 platform using a crane, boom truck or forklift. If you still have any questions, please contact your FRACO representative. ©FRACO Products Ltd...
  • Page 56: Moving The Platform

    These instructions concern the moving of a platform on the ground. Moving the platform when it is not on the ground is a special operation that requires the approval of FRACO or other competent personnel. If you still have any questions, please contact your FRACO representative.
  • Page 57: Maintenance

    ! Check the condition of the different springs Monthly Preventive maintenance sheet ! Verify hydraulic oil level (SAE 32 or HVI 36) Annual ! General painting ! Retouch places exposed to rust. ©FRACO Products Ltd FRSM-8000 user's guide 09/2002...
