WVM User Manual
User Manual
Model: WVM-1101
Page 1 of 1
** Company Confidential **
Rev 1.00
Advertisement
Table of Contents
Summary of Contents for ADIMOS Systems WVM-1101
- Page 1 No disclosure thereof shall be made to third parties without the express written permission of ADIMOS Systems Ltd. ADIMOS Systems Ltd. reserves the right to alter the equipment specifications and descriptions in this publication without prior notice. No part of this publication shall be deemed to be part of any contract or warranty unless specifically incorporated by reference into such contract or warranty.
-
Page 2: Table Of Contents
ADIMOS Systems Ltd. ** Company Confidential ** Table of Contents Introduction ..........................3 Purpose and Scope ........................3 Terms and Abbreviations ......................3 References .............................3 Configuration and Status Registers ....................3 General Description.........................3 Register Details........................3 3.2.1 Introduction ........................3 3.2.2 Register Summary......................4 3.2.3 System Version ........................5 3.2.4... -
Page 3: Introduction
Introduction Purpose and Scope The Wireless Video Module product (WVM-1101) delivers video over wireless channel. It enables a wireless connection between a video source (DVD, VCR, PVR, STB, BS or PC) and a video display (standard TV, flat screen TV or video monitor). -
Page 4: Register Summary
ADIMOS Systems Ltd. ** Company Confidential ** 3.2.2 Register Summary Sub-address Name Side Read/ Size Function Write [bytes] 0x00 System Version Tx, Rx System version ID 0x01 Set video standard Set NTSC/PAL/SECAM/Auto. 0x02 Video standard status Tx, Rx Actual status of video standard... -
Page 5: System Version
ADIMOS Systems Ltd. ** Company Confidential ** 3.2.3 System Version Sub- Name Size Value Default addr [bytes] 0x00 System Version Byte0: V1 Byte1: V2 Byte2: V3 Byte3: V4 Byte values are 0-0xFF The System version is presented as: V1.V2.V3.V4. V1 – Product type V2 –... -
Page 6: Video Input Port
ADIMOS Systems Ltd. ** Company Confidential ** 3.2.5 Video input port Sub- Name Size Value Default addr [bytes] 0x03 Select video Byte0 = 1: Composite video input port Byte0 = 2: S -Video (Composite (Tx only) video) Byte0 = 3: YPbPr-interlaced video... -
Page 7: Country Code
ADIMOS Systems Ltd. ** Company Confidential ** The video transmission rate can be set to 4, 8 or 14 Mbps, or can be set to Limited Automatic or Fully Automatic. When set to Limited Automatic, the system will select automatically the highest possible video rate, up to the value set in Byte0 of register 0x09. -
Page 8: Operation Mode - Local Unit
ADIMOS Systems Ltd. ** Company Confidential ** Channel Table Channel Channel Channel Channel Channel Channel Number Frequency Number Frequency Number Frequency (Hex) (GHz) (Hex) (GHz) (Hex) (GHz) 5.170 5.500 5.745 5.180 5.520 5.765 5.190 5.540 5.785 5.200 5.560 5.805 5.210 5.580... -
Page 9: Timeout And Status Of The Wireless I2C
ADIMOS Systems Ltd. ** Company Confidential ** Notes: • Enter Sleep mode request is applicable only when the remote unit is in Idle or Work mode. Entering Sleep mode stops any video and audio transfer. • Exit Sleep mode request is applicable only when the remote unit is in Sleep mode. The unit will switch to Idle mode. -
Page 10: Discrete Inputs Status
ADIMOS Systems Ltd. ** Company Confidential ** 3.2.13 Discrete Inputs Status Sub- Name Size Value Default addr [bytes] 0x19 Discrete Inputs Byte0 = 0-7: Status of Discrete Status Input 1, 2, 3 at the Tx unit. (Rx only) Bit 0 is 1 when Discrete Input 1 is low;... -
Page 11: Do Installation Process
ADIMOS Systems Ltd. ** Company Confidential ** • When the unit is not connected, waiting for a peer unit to connect, PER status register is 200. • When the unit is in sleep mode and connected to a peer unit, PER status register is 0. - Page 12 ADIMOS Systems Ltd. ** Company Confidential ** Antenna: Brand - NTK Model - MAP5200AEA01 Detail specification – See attached "Antenna with Brand and Model Name 10-01-04.pdf" Regulatory Information Integrator must follow below instructions: The Adimos WVM -1101 Wireless Video Module must be installed and used in strict accordance with the manufacturer’s instructions as described in the user documentation that comes with the product.
- Page 13 EN301 893, EN301 489-17, EN60950 NOTE: Due to frequency restrictions, it is necessary to select your country before using this radio device. Refer to your Adimos WVM-1101 online help for details. Europe - Declaration of Conformity in Languages of the European Community English Hereby, Adimos Incorporation Company, declares that this Radio LAN device is in compliance with the essential requirements and other relevant provisions of Directive 1999/5/EC.
- Page 14 ADIMOS Systems Ltd. ** Company Confidential ** French Par la présente Adimos IncorporationNetwork Company déclare que l'appareil Radio LAN device est conforme aux exigences essentielles et aux autres dispositions pertinentes de la directive 1999/5/CE Par la présente, Adimos Incorporation Company déclare que ce Radio LAN device est conforme...
- Page 15 ADIMOS Systems Ltd. ** Company Confidential ** Europe - Copy of Original Declaration of Conformity Decleration of Conformity (will be provided soon) WVM User Manual Page 15 of 15 Rev 1.00...
- Page 16 ADIMOS Systems Ltd. ** Company Confidential ** Europe – Restrictions for Use of 5GHz Frequencies in European Community Countries European Community Countries 5150-5250 MHz 5250-5350 MHz Channels: 36, 40, 44, 48 Channels: 52, 56, 60, 64) Indoor Only Indoor Only Austria ×...
- Page 17 Module WVM-1101 and antenna it tested with must be integrated in the end product in such a way that the end user cannot access the either the module, cables or antennas.
- Page 18 ADIMOS Systems Ltd. ** Company Confidential ** FCC 15.407 Requirements Frequency Stability (15.407 (g)) FCC 15.407(g) states: “Manufacturers of U-NII devices are responsible for ensuring frequency stability such that an emission is maintained within the band of operation under all conditions of normal operation as specified in the users manual.”...
