Citizen 8217 Instruction Manual

INSTRUCTION MANUAL FOR MIYOTA WATCH MOVEMENT

CALIBRE NO. 8217

AUTOMATIC MOVEMENT

A) DISPLAYS AND BUTTONS
B) WINDING THE MAINSPRING
C) SETTING THE TIME
D) SETTING THE DATE
A) DISPLAYS AND BUTTONS
Hour Hand
24Hour Hand
Second Hand
B) WINDING THE MAINSPRING
Automatic winding watch can also be hand winded by turning the crown clockwise in Normal position.
Wind several times clockwise. It will start to move naturally.
C) SETTING THE TIME
1. Pull the crown out to the 2nd Click Position.
2. Turn the crown to set hour and minute hands.
3. After the time has been set, push the crown back to the Normal position.
*24Hour hand moves linked with the center Hour and Minute hand.
D) SETTING THE DATE
1. Pull the crown out to the 1st Click Position.
2. Turn the crown counter-clockwise to set the date.
* If the date is set between the hours of around 9:00 PM and 1:00 AM, the date may not change on
the following day.
3. After the date has been set, push the crown back to the normal position.
UNIVERSAL MASTERPIECE BORN IN JAPAN
MADE IN JAPAN
METAL MOVEMENT
These specifications might be changed without prior notice.
Minutes Hand
Normal Position
2nd Click Position
1st Click Position
