- Page 1 Operating instructions GPS Dashcam RF-DC-1G Item No. 1577620...
-
Page 2: Table Of Contents
Table of contents Page 1. Introduction ..........................3 2. Explanation of symbols .......................3 3. Intended use ........................4 4. Delivery contents .........................4 5. Safety instructions .......................5 a) General information ......................5 b) Rechargeable battery ....................6 6. Features and functions ......................6 7. Product overview .........................7 8. -
Page 3: Introduction
1. Introduction Dear customer, Thank you for purchasing this product. This product complies with statutory national and European regulations. To ensure that the product remains in this state and to guarantee safe operation, always follow the instructions in this manual. These operating instructions are part of this product. -
Page 4: Intended Use
Only make this product available to third parties together with its operating instructions. All company and product names are trademarks of their respective owners. All rights reserved. 4. Delivery contents • GPS Dashcam RF-DC-1G • Suction mount • Car charging cable • Operating instructions... -
Page 5: Safety Instructions
5. Safety instructions Read the operating instructions and safety information carefully. If you do not follow the safety instructions and information on proper handling in this manual, we will assume no liability for any resulting personal injury or damage to property. Such cases will invalidate the warranty/guarantee. a) General information •... -
Page 6: B) Rechargeable Battery
b) Rechargeable battery • The built-in rechargeable battery cannot be removed and can only be charged in the device. Never attempt to remove the battery and charge it with an external charger. • The battery must be charged with the vehicle charging cable provided, a USB power adapter or a USB port on your computer. -
Page 7: Product Overview
7. Product overview button MENU button MODE button button Display USB data port R/OK button 10 Card slot button 11 Microphone Status indicator 12 USB charging port Red = Battery charging 13 RESET button Blue = Switched on 14 Mounting lug Flashing blue = Video recording 15 Lens... -
Page 8: Fitting
8. Fitting Never install the product within the release range of an airbag or in an area where it may impair the driver’s vision. When installing the product, consider the risks that may arise from devices becoming dislodged in the event of an accident. Secure the product in a place where it will not present a danger to the driver and/or passengers. -
Page 9: Charging The Battery
10. Charging the battery • The camera switches on and the battery charges automatically when the camera is con- nected to a power supply. • The status indicator (6) turns red when the battery is charging. A full charge cycle takes ap- proximately one hour. -
Page 10: Operation
12. Operation Do not operate the camera when you are driving, as this may distract you and endan- ger you and other road users. a) General functions Switching on and off • Press the button (1) briefly to switch on the camera. •... - Page 11 Manual recording • Use the MODE button (2) to select the desired operating mode. • Video mode Press the R/OK button (4) to start a video recording. Press the R/OK button (4) again to stop the recording. • Photo mode Press the R/OK button (4) to take a photo.
-
Page 12: B) Menu
b) Menu Each mode has its own menu. To access a menu, enable the corresponding mode. The system menu can be accessed in any mode. Using the menu If necessary, stop the video recording or video playback. The camera must be in standby mode. - Page 13 Enables/disables GPS When GPS is enabled, GPS data is recorded and the time is set automatically. The GPS symbol appears in green when GPS reception is sufficient. Plate Number Option for entering the vehicle numberplate Photo menu Take photo auto Automatic shooting with adjustable interval between photos Image Size...
- Page 14 Playback menu Delete Delete function Protect Enables/disables write protection Files cannot be deleted when write-protection is enabled (if you wish to delete a file, disable write protection) Slide show Sets the image display duration for slide shows System menu Date /Time Sets the date and time Auto Power-Off Switch-off delay after disconnecting the power supply...
-
Page 15: Connecting The Device To A Computer
13. Connecting the device to a computer When the camera is connected to a computer, it turns on automatically and the battery starts to charge. a) Storage management • Connect a suitable USB cable to the USB data port (9). •... -
Page 16: Troubleshooting
14. Troubleshooting The camera is built using state-of-the-art technology and is safe to operate. However, problems and malfunctions may still occur. Follow the instructions below to troubleshoot possible faults: Always follow the safety information. The camera does not work after it is switched on: •... -
Page 17: Care And Cleaning
15. Care and cleaning Never use aggressive detergents, rubbing alcohol or other chemical solutions, as these could damage the casing or stop the product from functioning properly. • Always disconnect the product from the power supply before cleaning it. • Do not press too hard on the display (3) or lens (15) when cleaning the camera. 16. -
Page 18: Technical Data
18. Technical data Power supply ........12-24 V/DC (via cigarette lighter) 5 V/DC (camera via USB) Rechargeable battery .....3.7 V/200 mAh, LiPo battery Fuse ..........F2AL AL/250V (5 x 20 mm) Battery life ........approx. 20 min (video recording) Charging time .........approx. 1 hr Lens ..........152°... - Page 19 This is a publication by Conrad Electronic SE, Klaus-Conrad-Str. 1, D-92240 Hirschau (www.conrad.com). All rights including translation reserved. Reproduction by any method, e.g. photocopy, microfilming, or the capture in electronic data processing systems require the prior written approval by the editor. Reprinting, also in part, is prohibited. This publication represent the technical status at the time of printing.
