Option Audio GTM60 series User Manual

Ultra-thin 3g wwan module in lga package
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GTM601/609 Development Kit
User Guide
Ultra-thin 3G WWAN
Module in LGA package

Advertisement

Table of Contents
loading

Summary of Contents for Option Audio GTM60 series

  • Page 1 GTM601/609 Development Kit User Guide Ultra-thin 3G WWAN Module in LGA package...
  • Page 2 GTM60x Development Kit User Guide VERSION HISTORY Date Version Author Revision Approval 03/11/2010 V001int F. Arboleda P. Vandeneede 15/11/2010 V002ext F. Arboleda Review S. Han Version: v002ext Page: 2 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 3 GTM60x Development Kit User Guide OVERVIEW AND PURPOSE This document describes the GTM60x Module Development Kit hardware, software and installation instructions. This user guide is applicable for the following products: Commercial Product WCDMA EVDO WIFI 2G Bands Name Number Bands Bands 800- All models...
  • Page 4 GTM60x Development Kit User Guide CONFIDENTIALITY All data and/or information contained in or disclosed by this document is Option NV confidential and proprietary and all respective rights are hereby ® expressly reserved. By accepting this document, the recipient formally acknowledges and agrees that this data and/or information is to be held in strict confidence and is not to be used, copied, reproduced in whole or in part, nor its contents revealed in any manner to others without prior and written permission of Option...

  • Page 5: Table Of Contents

    GTM60x Development Kit User Guide CONTENTS WELCOME FEATURES GTM60x PACKAGE CONTENT HARDWARE INSTALLATION Hardware description 4.1.1 Detailed description 4.1.1.1 Controlling Switch 4.1.1.2 J14, J15 and J16 Installation DRIVER INSTALLATION Driver installation on Windows XP 5.1.1 General info: Driver set 5.1.2 Installation procedure 5.1.2.1 Automatic installation...
  • Page 6 GTM60x Development Kit User Guide HOW TO SEND AT COMMANDS GTM60x CONFIGURATION Radio ON/OFF RRC security Preferred system Access Point Name SIM control Registration SETTING UP A PACKET SWITCHED DATA CALL Using Modem interface (Dial-up) 9.1.1 On Windows XP 9.1.2 On Windows Vista 9.1.3 On Windows 7...

  • Page 7: Welcome

    GTM60x Development Kit User Guide 1 WELCOME Figure 1: The GTM60x in LGA package This GTM60x WWAN modem is the perfect solution for embedding 2G, 3G and EVDO technology in small consumer electronics devices or broadband M2M applications. The GTM60x is capable of supporting HSDPA data rates of up to 14.4 Mbps in downlink and up to 5.76 Mbps in uplink.
  • Page 8 GTM60x Development Kit User Guide For evaluation purposes the GTM60x modules are housed on an evaluation board, offering a convenient evaluation and development platform. This document describes the Module Development Kit hardware and software installation, and basic usage instructions for Windows® XP, Vista and 7. Design specific information for the modules is outside the scope of this document and can be found in the GTM60x integration package.

  • Page 9: Features

    GTM60x Development Kit User Guide 2 FEATURES Due to its ultra-thin form factor and excellent heat dissipation characteristics this is the perfect module for integration in small consumer electronics devices or broadband M2M applications. The GPS and voice capabilities give this module a unique position. The new and improved footprint facilitates soldering.

  • Page 10: Gtm60X Package Content

    GTM60x Development Kit User Guide 3 GTM60x PACKAGE CONTENT Your Module Development Kit comes with the following items:  Evaluation board containing the GTM60x module.  USB cable.  Power adaptor (5VDC / 2A @ 100-240V). The module will have the latest firmware which was available during the assembly of this development kit.

  • Page 11: Hardware Installation

    GTM60x Development Kit User Guide 4 HARDWARE INSTALLATION 4.1 Hardware description Figure 2: Evaluation board Version: v002ext Page: 11 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...
  • Page 12 GTM60x Development Kit User Guide Points of interest (See Figure 2): GTM60x Module. Power LED: Indicates that GTM60x is powered. Registration and USB activity LED: This LED indicates that the module has registered to the mobile network when it is on continuously.
  • Page 13 GTM60x Development Kit User Guide 19) J1: Jumper to enable or disable the power circuits next to the mini USB connector. By default the power circuits are enabled (no jumper cap). The power circuit should be disabled when using the battery connector to power de GTM60x by short circuiting the jumper.

  • Page 14: Detailed Description

    GTM60x Development Kit User Guide 4.1.1 Detailed description 4.1.1.1 Controlling Switch Figure 3: Controlling Switch Switches: (1) MICMUTE: Switch to mute the microphone on the audio jack. Default value: ON. (2) EARMUTE: Switch to mute the ear piece on the audio jack. Default value: (3) COMPSEL: Selection of bit format.

  • Page 15: J14, J15 And J16

    GTM60x Development Kit User Guide 4.1.1.2 J14, J15 and J16 Figure 4: J14 Specification Version: v002ext Page: 15 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...
  • Page 16 GTM60x Development Kit User Guide Figure 5: J15 Specification Version: v002ext Page: 16 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...
  • Page 17 GTM60x Development Kit User Guide Figure 6: J16 Specification. NOTE: 3v3 will be transformed into 1v8 by an on board level translator. This level translator is located on the development board and not on the GTM60x. Version: v002ext Page: 17 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...

  • Page 18: Installation

    GTM60x Development Kit User Guide 4.2 Installation Start by carefully inserting your SIM card in the SIM card holder (4). Do this by pushing the SIM card in the cardholder until it clicks into place. Figure 7: SIM card holder. Next, connect the power adaptor to the power plug (9).
  • Page 19 GTM60x Development Kit User Guide Figure 8: Power and USB connectors. Figure 9: Audio jack and Headset. Version: v002ext Page: 19 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...
  • Page 20 GTM60x Development Kit User Guide Be sure the W. Disable switch on the controlling switch (12) is on the OFF position to have the radio ON. If Jumper J2 (20) is not short circuited, press the on key (6). At this point the host PC should detect your module. Figure 10: Switch 4 (W.

  • Page 21: Driver Installation

    GTM60x Development Kit User Guide 5 DRIVER INSTALLATION 5.1 Driver installation on Windows XP We currently provide one set of drivers for Windows XP/Vista and one set for Windows 7. These driver sets contain drivers that control the module. The driver set described in this section supports, Windows XP 32/64 bit edition and Windows Vista 32/64 bit edition.

  • Page 22: Installation Procedure

    GTM60x Development Kit User Guide 5.1.2 Installation procedure Make sure you have a clean system before proceeding with the installation procedure. At this point you should copy the driver folder to a known location on your hard disk drive. NOTE: At the time of this writing the latest driver version was version 5.2.1.0. Check with your Option contact to acquire the latest driver version.

  • Page 23: Manual Installation

    GTM60x Development Kit User Guide You can verify if the device is installed by opening Device Manager. Please configure it in the menu via “View”, “Devices by connection”. Expand the tree until you see the GlobeTrotter® module as shown in Figure 12. 5.1.2.2 Manual installation (1) If you have not already done so, install and connect the cradle as described in section 4.
  • Page 24 GTM60x Development Kit User Guide Figure 14: Welcome to the Found New Hardware Wizard (2) In the first dialog (“Can Windows connect to Windows Update to search for software?”), select “No, not this time” Version: v002ext Page: 24 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 25 GTM60x Development Kit User Guide (3) In the next dialog, select “Install software automatically (Recommended)”. At this point make sure the CD-ROM with drivers is inserted in your optical drive. Figure 15: Install the software automatically (Recommended) Version: v002ext Page: 25 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 26 GTM60x Development Kit User Guide If you know where the drivers are located, you can select “Install from a list or specific location (Advanced)”. In this case ensure you select the option “Include this location in the search:” in the next screen, and enter the correct path to your drivers.
  • Page 27 GTM60x Development Kit User Guide (4) Click “Finish” in the next screen “Completing the Found New Hardware Wizard”. Figure 17: Completing the Found New Hardware Wizard Version: v002ext Page: 27 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 28 GTM60x Development Kit User Guide (5) Repeat steps 3 to 4 for all drivers. Windows will start a wizard for each interface. (6) On successful installation of all drivers, the device manager will show the following typical installed devices. Please configure the device manager by selecting “View”, “Devices by connection”...

  • Page 29: Driver Installation On Windows Vista

    GTM60x Development Kit User Guide 5.2 Driver installation on Windows Vista We currently provide one set of drivers for Windows XP/Vista and one set for Windows 7. These driver sets contain drivers that control the module. The driver set described in this section supports, Windows XP 32/64 bit edition and Windows Vista 32/64 bit edition.

  • Page 30: Installation Procedure

    GTM60x Development Kit User Guide Figure 18: Ports occupied by the GTM60x 5.2.2 Installation procedure Make sure you have a clean system before proceeding with the installation procedure. At this point you should copy the driver folder to a known location on your hard disk drive.

  • Page 31: Automatic Installation

    GTM60x Development Kit User Guide 5.2.2.1 Automatic installation (1) Without the cradle being connected, run the driver installer “setup.exe” provided by your Option contact. The setup application runs until completion. This process can take up to two or three minutes. Starting the setup application will pop up the User Account Control security feature of Windows Vista.
  • Page 32 GTM60x Development Kit User Guide Clicking on this popup will show the progress of the installation. When all the drivers are installed, Vista will inform you that your devices are ready to use. Figure 20: The devices are ready to be used. You can verify if the device is installed by opening Device Manager.

  • Page 33: Manual Installation

    GTM60x Development Kit User Guide 5.2.2.2 Manual installation (1) If you have not already done so, install and connect the cradle as described in section 4. The unit is connected correctly only if the “Found New Hardware” screen appears. (2) Choose “Locate and install driver software (recommended)” to install the driver manually.
  • Page 34 GTM60x Development Kit User Guide (3) Next, select “I don’t have the disc. Show me other options”. Figure 22: More installation options. Version: v002ext Page: 34 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 35 GTM60x Development Kit User Guide (4) Select “Browse my computer for driver software (advanced).” Figure 23: Browse my computer for driver software (advanced) Version: v002ext Page: 35 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 36 GTM60x Development Kit User Guide (5) You can now enter the path where the driver software is located. Press “Browse” to find the appropriate driver. Figure 24: Browse for driver software on your computer (6) Windows will now start with the installation of driver software. Version: v002ext Page: 36 of 112 Option...
  • Page 37 GTM60x Development Kit User Guide (7) The wizard will notify you when the installation is successful. Figure 25: The software for this device has been successfully installed. (8) Repeat steps 2 to 7 for all drivers. Windows will start a wizard for each interface.
  • Page 38 GTM60x Development Kit User Guide (9) On successful installation of all drivers, the device manager will show the following typical installed devices. Please configure the device manager by selecting “View”, “Devices by connection”. Expand the tree to show the USB devices (See Figure 18).

  • Page 39: Driver Installation On Windows 7

    GTM60x Development Kit User Guide 5.3 Driver installation on Windows 7 We currently provide one set of drivers for Windows XP/Vista and one set for Windows 7. These driver sets contain drivers that control the module. The driver set described in this section supports, Windows 7 32/64 bit edition. The driver name should be 5.1.x.x.

  • Page 40: Installation Procedure

    GTM60x Development Kit User Guide 5.3.2 Installation procedure Make sure you have a clean system before proceeding with the installation procedure. At this point you should copy the driver folder to a known location on your hard disk drive. NOTE: At the time of this writing the latest driver version was version 5.1.38.0 (Unsigned).

  • Page 41: Manual Installation

    GTM60x Development Kit User Guide (2) Connect the GTM60x to the laptop as described in section 4. Windows Vista will recognize the device and start installing drivers. No user interaction is required. 5.3.2.2 Manual installation (1) If you have not already done so, install and connect the cradle as described in section 4.
  • Page 42 GTM60x Development Kit User Guide (3) Open the device manager by searching for it in the start menu search field and clicking on it. Figure 29: Device drivers not installed (4) Right click “Globetrotter HSUPA Modem” and choose “Update Driver Software”.
  • Page 43 GTM60x Development Kit User Guide (5) Choose “Browse my computer for driver software”. Figure 31: Browse my computer for driver software. (6) Browse to the location you copied the drivers to and click next. Version: v002ext Page: 43 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 44 GTM60x Development Kit User Guide Figure 32: Browse for driver software on your computer (7) If the drivers are not signed, Windows will request authorization to install the new drivers. At this moment click on “Install this driver software anyway”. Version: v002ext Page: 44 of 112 Option...
  • Page 45 GTM60x Development Kit User Guide Figure 33: Windows Security to install unsigned drivers. (8) The drivers will be installed. When the installation is finished, click on close. Version: v002ext Page: 45 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 46 GTM60x Development Kit User Guide Figure 34: The software for this device has been successfully installed. (9) Repeat the process starting from 4 to 8 for all other remaining unknown devices. Version: v002ext Page: 46 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 47 GTM60x Development Kit User Guide Figure 35: Remaining unknown devices (10) On successful installation of all drivers, the device manager will show the following typical installed devices. Please configure the device manager by selecting “View”, “Devices by connection”. Expand the tree to show the USB devices (See Figure 26).

  • Page 48: Firmware Upgrade

    GTM60x Development Kit User Guide 6 FIRMWARE UPGRADE NOTE: This section describes the upgrade to the latest firmware version of the GTM60x. At the time of this writing this was version 1.2.0.0. Check with your Option contact to acquire the latest firmware version. (1) Copy the latest firmware version to a known location.
  • Page 49 GTM60x Development Kit User Guide Figure 36: The Blacktip upgrader (6) Press the “Upgrade!” button. This process will take a few minutes. Do not disconnect the device during this time. Wait 10 seconds after the process is finished before disconnecting the device. Version: v002ext Page: 49 of 112 Option...
  • Page 50 GTM60x Development Kit User Guide Figure 37: Module firmware upgrade completed. Version: v002ext Page: 50 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...

  • Page 51: How To Send At Commands

    GTM60x Development Kit User Guide 7 HOW TO SEND AT COMMANDS This section briefly describes how to send AT commands using HyperTerminal to communicate with the GTM60x. HyperTerminal is included in Windows XP but not in Windows Vista or Windows 7. However, it can be downloaded free for personal use from its creator’s website: http://www.hilgraeve.com/.
  • Page 52 GTM60x Development Kit User Guide (1) First start device manager. You can do this by going to “Start” menu and selecting “Run”. Type “devmgmt.msc” in the next dialogue box as displayed below: Figure 38: Run device manager Version: v002ext Page: 52 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 53 GTM60x Development Kit User Guide (2) Check the port used by the application interface. In this example, the application port is COM6. NOTE: In Windows 7 the application interface is called the Control Interface. Figure 39: Application interface on COM6. (3) Open HyperTerminal via the “Start”...
  • Page 54 GTM60x Development Kit User Guide Figure 40: Location information. (4) Just click “OK” on the “Phone and Modem Options” screen. Version: v002ext Page: 54 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...
  • Page 55 GTM60x Development Kit User Guide Figure 41: Location information. (5) Enter a name for your HyperTerminal connection and press OK. Version: v002ext Page: 55 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...
  • Page 56 GTM60x Development Kit User Guide Figure 42: Connection Description (6) In the next window, change the “Connect using:” field to the application port you checked under (2). Click OK. Version: v002ext Page: 56 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 57 GTM60x Development Kit User Guide Figure 43: Connect To (7) Now the next window will appear. Modify the “Bits per second” field to 115200 and click OK. Version: v002ext Page: 57 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 58 GTM60x Development Kit User Guide Figure 44: Connection Properties Version: v002ext Page: 58 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...
  • Page 59 GTM60x Development Kit User Guide HyperTerminal is now configured and you are ready to issue AT commands to the module. The figure below shows a typical HyperTerminal session. If you don’t have visual feedback of what you are typing, you need to turn echo on by typing ATE, as shown in the example below.
  • Page 60 GTM60x Development Kit User Guide When you close HyperTerminal, you have the opportunity to save your HyperTerminal profile. Saved profiles can be found under HyperTerminal in the “Start” menu. Start  Programs  accessories  Communication  HyperTerminal. Version: v002ext Page: 60 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties...

  • Page 61: Gtm60X Configuration

    GTM60x Development Kit User Guide 8 GTM60x CONFIGURATION Before you set up a data connection, you should configure the module. Configuring the GTM60x is done by sending AT commands to the application interface (Windows 7: control interface). You can use HyperTerminal (explained on the previous section) or another serial communication program connected to this interface.

  • Page 62: Rrc Security

    GTM60x Development Kit User Guide 8.2 RRC security To be able to register on a real network, security should be set to “Integrity and ciphering”. This can be done by entering the following AT command: AT_OSEC=4 To register on a simulator such as an Agilent, security should be set to “Fake security”.

  • Page 63: Sim Control

    GTM60x Development Kit User Guide 8.5 SIM control The GTM60x requires a SIM to be fitted in order to access a network (if working in UMTS mode). Some people use SIMs with PIN code protection. Some operators mandate the use of PIN codes as this provides protection in the event of SIM theft.

  • Page 64: Registration

    GTM60x Development Kit User Guide 8.6 Registration SMS and data connections are only possible if the GTM60x is registered on a network. An AT command is use to return the registration state and operator name or code: AT+COPS? +COPS: 0,0,"OPERATOR",2 The “OPERATOR”...

  • Page 65: Setting Up A Packet Switched Data Call

    GTM60x Development Kit User Guide 9 SETTING UP A PACKET SWITCHED DATA CALL Make sure you have configured the module properly (refer to section 8). Before attempting the Data connection, ensure you are registered to the network. Check that the registration LED in Figure 2 is on. Also, the APN for your operator should be set correctly in the module.

  • Page 66: On Windows Xp

    GTM60x Development Kit User Guide 9.1.1 On Windows XP (1) Go to Start → Control Panel→ Network Connections and click on the icon “New Connection Wizard”. The next screen will appear: Figure 46: New connection Wizard. Version: v002ext Page: 66 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 67 GTM60x Development Kit User Guide (2) Click “Next” and following figure will appear. Select “Connect to the Internet” and click “Next” again. Figure 47: Connect to the Internet. Version: v002ext Page: 67 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 68 GTM60x Development Kit User Guide (3) Select “Set up the connection manually”, and click the “Next” button. Figure 48: Manual connection setup. Version: v002ext Page: 68 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 69 GTM60x Development Kit User Guide (4) Choose the “Connect using a dial-up modem” option, and click the “Next” button. Figure 49: Connection with dial-up modem. Version: v002ext Page: 69 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 70 GTM60x Development Kit User Guide (5) Select the correct RAS modem (Modem - GlobeTrotter MO40X modem interface), and click the “Next” button. Figure 50: Select Modem. Version: v002ext Page: 70 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 71 GTM60x Development Kit User Guide (6) Type a name for the connection that you should select the next time you need this dial-up connection, and click the “Next” button. Figure 51: Connection Name. Version: v002ext Page: 71 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 72 GTM60x Development Kit User Guide (7) Type in *99# for the telephone number to dial and click the “Next” button. Figure 52: Number to dial. Version: v002ext Page: 72 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 73 GTM60x Development Kit User Guide (8) Choose the option you like, and then click the “Next” button. Figure 53: Connection Availability. Version: v002ext Page: 73 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 74 GTM60x Development Kit User Guide (9) If your service provider requires you to enter your username and password to set up a PS data call connection, please enter them using the screen below. Figure 54: Internet Account Information. Version: v002ext Page: 74 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties...
  • Page 75 GTM60x Development Kit User Guide (10) The connection is set up and ready to use. Click the “Finish” button to close the wizard. This window also offers the possibility to add the connection into the Desktop by checking the available check box. Figure 55: Connection complete.
  • Page 76 GTM60x Development Kit User Guide (11) Then, if your module is registered on the network, you can use the configured dial-up connection to activate a PDP context and make an Internet connection. Go to Start→ Connect to→ “Module PDP” and select it. Figure 56: Connect Module PDP.
  • Page 77 GTM60x Development Kit User Guide (12) Click the dial button. After a while, a connection to the Internet is made. Figure 57: Connecting Module PDP. Figure 58: Module PDP is now connected. Version: v002ext Page: 77 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 78 GTM60x Development Kit User Guide (13) To disconnect, go to the appropriate network systray icon and select “Disconnect” from the context menu (via right mouse button). Figure 59: Disconnecting Module PDP. Version: v002ext Page: 78 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...

  • Page 79: On Windows Vista

    GTM60x Development Kit User Guide 9.1.2 On Windows Vista (1) Go to Start→ Control Panel→ Network and Internet check the option “Connect to the Internet”. Choose Dial-up connection as connection method. If there is already an existing connection, select “No, create a new connection”...
  • Page 80 GTM60x Development Kit User Guide Figure 61: Select a Dial-up connection. Version: v002ext Page: 80 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...
  • Page 81 GTM60x Development Kit User Guide (2) The next dialog will ask for the modem to be use. Select the GlobeTrotter® modem: Figure 62: Select the GlobeTrotter® modem. Version: v002ext Page: 81 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 82 GTM60x Development Kit User Guide (3) Next, Windows needs your ISP information. Enter the telephone number *99# and click “Connect”. Figure 63: Settings for Dial-up connection. Version: v002ext Page: 82 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 83 GTM60x Development Kit User Guide (4) In the following screens, you can monitor the progress as Windows sets up the connection: Figure 64: Connecting… Version: v002ext Page: 83 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 84 GTM60x Development Kit User Guide Figure 65: Testing… (This step can be skipped) Version: v002ext Page: 84 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...
  • Page 85 GTM60x Development Kit User Guide Figure 66: Connected. Figure 67: Connected. Version: v002ext Page: 85 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...
  • Page 86 GTM60x Development Kit User Guide (5) To disconnect, go to the appropriate network systray icon and select “Disconnect” from the context menu (via right mouse button). Figure 68: Disconnecting. (6) From now on, to redial using the GlobeTrotter®, go back to Start→ Control Panel.
  • Page 87 GTM60x Development Kit User Guide Figure 69: Select your connection. Version: v002ext Page: 87 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...

  • Page 88: On Windows 7

    GTM60x Development Kit User Guide 9.1.3 On Windows 7 To setup a Dial-up connection on windows 7, steps 1 to 4 from section 9.1.2 can be followed. (1) After pressing the connect button on step 3, the device will start the connection and test it once it is ready.
  • Page 89 GTM60x Development Kit User Guide (2) The connection can be also checked on the appropriate network systray icon: Figure 71: Connected on systray. Figure 72: Connected. Version: v002ext Page: 89 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 90 GTM60x Development Kit User Guide (3) To disconnect, go to the appropriate network systray icon and open the available connections (via left mouse button). Select the Dial-up connection and left click on it. Press the “Disconnect” button from menu. Figure 73: Disconnecting. Version: v002ext Page: 90 of 112 Option...
  • Page 91 GTM60x Development Kit User Guide (4) From now on, to redial using the GlobeTrotter®, go to the appropriate network systray icon and open the available connections (via left mouse button). Select the Dial-up connection and left click on it. Press the “Connect” button from menu.

  • Page 92: Using Ndis Interface

    GTM60x Development Kit User Guide 9.2 Using NDIS interface 9.2.1 On Windows XP/Vista (Applet) (1) Locate the executable file: Your Option contact has provided you with a “.cpl” file. This is the dashboard applet. (2) Double click on the file appropriate for your operating system. If you have a 32 bit OS choose the filename ending with 32, if you have a 64 bit OS choose the filename ending with 64.
  • Page 93 GTM60x Development Kit User Guide (3) In the Wireless WAN configuration window press on the “Reconnect” button. When a connection is made the status text field will display “Connected”. Figure 76: Connected. (4) To disconnect, simply press on the “Disconnect” button. When the device is disconnected the status text field will display “Disconnected”.

  • Page 94: On Windows 7 (Mobile Broadband)

    GTM60x Development Kit User Guide 9.2.2 On Windows 7 (Mobile Broadband) (1) Go to the appropriate network systray icon and open the available connections (via left mouse button). Select the correct Mobile Broadband Connection (Service Provider name) and left click on it. Press the “Connect” button from menu.
  • Page 95 GTM60x Development Kit User Guide (2) The first time, Mobile Broadband will request the Subscription details to be use for the new connection. Type your subscription settings here and press “Continue”. Figure 78: Subscription settings. (3) Select an option for the “Autoconnect settings”. Figure 79: Autoconnect settings.
  • Page 96 GTM60x Development Kit User Guide (4) The Internet connection should be active now. The connection status should be connected. Figure 80: Active Mobile Broadband connection. Version: v002ext Page: 96 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ®...
  • Page 97 GTM60x Development Kit User Guide (5) To disconnect, go to the appropriate network systray icon and open the available connections (via left mouse button). Select the Mobile Broadband connection and left click on it. Press the “Disconnect” button from menu. Figure 81: Disconnecting.

  • Page 98: Set Up A Gsm/Umts Voice Call

    GTM60x Development Kit User Guide 10 SET UP A GSM/UMTS VOICE CALL To be able to make a call, a minimum configuration is needed on the module. For this, a Terminal connection to the application port is needed. Please, refer to section 7 for this matter. (1) First of all, be sure that the device is configured as explained in section 8.
  • Page 99 GTM60x Development Kit User Guide AT_ODO=0 The response to this AT command should be: (4) By default, the voice part of the firmware is disabled. This setting needs to be enabled in order to have voice capabilities. This setting is stored in non-volatile memory of the module.
  • Page 100 GTM60x Development Kit User Guide (6) To set up a call, you must use the ATD command followed by a telephone number. ATD<phone number>; NOTE: Do not forget the semicolon (;) at the end of the AT command! The response to this AT command should be: Attention! You need to plug in the headset in the specified 2,5”...
  • Page 101 GTM60x Development Kit User Guide Figure 83: Voice call example. Version: v002ext Page: 101 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...

  • Page 102: Gps Features

    GTM60x Development Kit User Guide 11 GPS FEATURES 11.1 General The GTM60x module has built-in support for A-GPS (Assisted GPS) and S- GPS (Standalone GPS) signal processing. In mobile-assisted GPS (A-GPS) mode, when a request for position location is issued, available network information is provided to the location server (e.g., cell-ID) and assistance is requested from the location server.
  • Page 103 GTM60x Development Kit User Guide  A high-sensitivity solution that works in all terrains: indoor, outdoor, urban and rural.  High availability that is enabled by using both satellite and network information. These two GPS solutions on the module provide optimal time to fix, accuracy, sensitivity, availability and reduced network utilization in both these environments, depending on the conditions.

  • Page 104: Set Up A Gps Connection

    GTM60x Development Kit User Guide 11.2 Set up a GPS connection The data of the GPS positioning can be monitored from the GPS data interface. Open the Device Manager and check the Interfaces on the module. Figure 84: Interfaces on GTM60x Take note of the GPS data Interface COM port.

  • Page 105: Enabling Gps Positioning

    GTM60x Development Kit User Guide 11.2.1 Enabling GPS positioning By default, GPS positioning is disabled. To enable, connect to the application port via HyperTerminal and use the command below. The response to this AT command should be OK. AT_OGPS=2 The next step is connecting to the GPS Data Interface using HyperTerminal. Use the COM port you made note on 11.2.

  • Page 106: Using The Gps In Google Earth

    GTM60x Development Kit User Guide 11.2.2 Using the GPS in Google Earth You can test the GPS by displaying your current position in Google Earth. To use the GPS in Google Earth the following steps can be used. (1) Open Google Earth. (2) Click the Tools dropdown in the menu bar and choose...
  • Page 107 GTM60x Development Kit User Guide (3) Click Start . Google Earth will now be able to find your location via “ ＂ GPS. If you want to stop using the GPS, you can click Stop on the “ ＂ Realtime tab. Figure 87: Realtime GPS location found NOTES: Google Earth will need an active internet connection to find the maps.
  • Page 108 GTM60x Development Kit User Guide REFERENCES Document GTM60x Integration Package Version: v002ext Page: 108 of 112 Option Copyright: This document may not be duplicated, nor distributed to third parties ® without prior and written permission of Option ®...

  • Page 109: Appendix A: Limited Warranty

    GTM60x Development Kit User Guide APPENDIX A: LIMITED WARRANTY HARDWARE: Option warrants its products to be free from defects in ® workmanship and materials, under normal use and service, for one year. If a product does not operate as warranted during the applicable warranty period, Option shall, at its option and expense, repair the defective ®...
  • Page 110 GTM60x Development Kit User Guide no warranty that its products will work in combination with any hardware or applications software products provided by third parties, that the operation of the software products will be uninterrupted or error-free, or that all defects in the products will be corrected. For any third-party products listed in the Option software product documentation or ®...
  • Page 111 GTM60x Development Kit User Guide WARRANTIES EXCLUSIVE: If an Option product does not operate as ® warranted above, customer’s sole remedy shall be repair or replacement, at Option ’s option. The foregoing warranties and remedies are exclusive ® and are in lieu of all other warranties, express or implied, either in fact or by operation of law, statutory or otherwise, including warranties of merchantability and fitness for a particular purpose, Option neither...
  • Page 112 GTM60x Development Kit User Guide Option NV – Gaston Geenslaan 14 – 3001 Leuven Belgium T +32 16 317 411 – F +32 16 207 164 www.option.com Copyright ©2010 OPTION. All rights reserved. Option, GlobeTrotter and the Option logo are registered trademarks of OPTION. All third-party trademarks are the property of their respective owners.
  • Page 113 GTM609W FCC-ID: NCMOMO6092 IC: 2734A-MO6092 Certification Leaflet AGENCY REQUIREMENTS Licensed by QUALCOMM Incorporated under one or more of the following United States Patents and/or their counterparts in other nations: 4,901,307; 5,490,165; 5,056,109; 5,504,773; 5,101,501; 5,506,865; 5,109,390; 5,511,073; 5,228,054; 5,535,239; 5,267,261; 5,544,196; 5,267,262; 5,568,483; 5,337,338; 5,600,754; 5,414,796; 5,657,420; 5,416,797; 5,659,569;...
  • Page 114 Device marking The integrated device must carry the CE mark and Notified body number of the Notified Body used in the Annex IV conformity assessment of the module on the manufacturing label as described in the R&TTE directive 1999/5/EC Annex VII.
