Product Summary
The SimplyHome Motion Sensor (SH003B) should be installed in any indoor location where motion detection is needed.
The enclosed unit is a passive infrared sensor that detects movement within a specific area by sensing the infrared energy
emitted from a body as it moves through the sensor's field of view. When operating, the system will operate as a part of
a wireless mesh network. This network allows the sensor to transmit signals to other sensors within the network or to a
system base unit. Additionally, the main unit contains a temperature sensor for readings wherever the sensor is
mounted, and it also contains a tamper switch for alerting when the sensor has been opened.
Passive Infrared
Sensor
Status LED Light
Battery
(screw holes
located behind)
Powering On the Device
To power on the SimplyHome Motion Sensor (SH003B) take the following steps:
Remove the cover on the main unit. To do so, gently pry the top and bottom housing apart at the line around
•
the unit.
Locate the battery holding area (as seen in the picture above).
•
Insert the enclosed battery per the directions noted on the plastic enclosure (positive terminal should be closest
•
to the green LED Light above). After inserting the battery properly a green LED Light should turn on momentarily
above the battery.
Put the two plastic covers back together and be sure that they snap completely closed.
•
SimplyHome Motion Sensor SH003B
Motion Sensor – SH003B
User Manual and Installation Instructions
Tamper Switch
Page | 1
Advertisement
Table of Contents
Summary of Contents for SimplyHome SH003B
- Page 1 User Manual and Installation Instructions Product Summary The SimplyHome Motion Sensor (SH003B) should be installed in any indoor location where motion detection is needed. The enclosed unit is a passive infrared sensor that detects movement within a specific area by sensing the infrared energy emitted from a body as it moves through the sensor’s field of view.
- Page 2 Programming the Sensor into your SimplyHome System Once the sensor is powered on it will start communicating with the other sensors and the base system for your SimplyHome System. Refer to the SimplyHome Base Unit user guide for more information on sensor programming. Mounting the Sensor To begin the sensor installation, start by locating where the sensor should be mounted.
