Summary of Contents for Strand Lighting 63035
- Page 1 Strand Lighing RS232 Serial Interface Port � � � ..I <( Model: 63035 I...
- Page 2 La compagnie Philips Strand Lighting n'assume aucune responsibilité sur toute erreur ou ommission inscrite dans ce manuel. Pour tous commentaires ou suggestions concernant des corrections et/ou les mises à jour de ce manuel, veuillez s'll vous plait contacter le bureau de Philips Strand Lighting le plus proche.
-
Page 3: Table Of Contents
Vision.net RS232 Interface Port Installation & Operation Guide Important Safeguards When using electrical equipment, basic safety precautions should always be followed including the following: a. READ AND FOLLOW ALL SAFETY INSTRUCTIONS. b. Do not use outdoors. c. Do not mount near gas or electric heaters. d. -
Page 4: Overview
Vision.net RS232 Serial Interface Port Overview The Vision.net RS232 Serial Interface Port (Strand Part No: 63035) allows integration with the Vision.net Network using standard RS232 communication. The RS232 Interface has the abil- ity to receive and transmit data in two modes: Vision.net Protocol (binary) and Show Control Protocol (standard ASCII). -
Page 5: Installation
Vision.net RS232 Interface Port Installation & Operation Guide INSTALLATION The Vision.net Network consists of a single CAT5e cable connecting all modules in a daisy chain manner. All units connect to the network using a 9-pin plug-in connector (included). Installation Steps Step 1. -
Page 6: Operation
Vision.net RS232 Interface Port Installation & Operation Guide OPERATION Communication Modes The Vision.net RS232 Serial Interface Port operates in one of two modes: Vision.net (binary) or Show Control (ASCII). Vision.net Mode Show Control Mode 8 Bit 8 Bit 1 Stop Bit 1 Stop Bit 19200 Baud 9600 Baud... -
Page 7: Specifications
Vision.net RS232 Interface Port Installation & Operation Guide where: Room (1 - 255) qqq Coded Channel Preset (1 - 32) [0 = off] (0: Reserved Rate Index 1 - 127: Channels 1 to 127 Channel ( 1-127) 128: All Channels in room Level (0 - 255) 129 - 255: Channel in Preset: 1 - 126 Submaster Index (1 - 16) - Page 8 Part No. 2-450200-020...
