Spectracom TPRO-cPCI User Manual

Synchronizable timecode generator with compact pci bus interface

Advertisement

Quick Links

TPRO-cPCI/TSAT-cPCI
SYNCHRONIZABLE TIMECODE
GENERATOR with
COMPACT PCI BUS INTERFACE
User Manual
95 Methodist Hill Drive
Rochester, NY 14623
Phone: US +1.585.321.5800
Fax: US +1.585.321.5219
www.spectracomcorp.com
Part Number 1152-5001-0050
Manual Revision D
12 January 2009

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPRO-cPCI and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Spectracom TPRO-cPCI

  • Page 1 TPRO-cPCI/TSAT-cPCI SYNCHRONIZABLE TIMECODE GENERATOR with COMPACT PCI BUS INTERFACE User Manual 95 Methodist Hill Drive Rochester, NY 14623 Phone: US +1.585.321.5800 Fax: US +1.585.321.5219 www.spectracomcorp.com Part Number 1152-5001-0050 Manual Revision D 12 January 2009...
  • Page 2 Copyright © 2008 Spectracom Corporation. The contents of this publication may not be reproduced in any form without the written permission of Spectracom Corporation. Printed in USA. Specifications subject to change or improvement without notice. Spectracom, NetClock, Ageless, TimeGuard, TimeBurst, TimeTap, LineTap, MultiTap, VersaTap, and Legally Traceable Time are Spectracom registered trademarks.
  • Page 3 Spectracom’s judgment the defective condition in a Spectracom Spectracom be liable for any direct, indirect, special or product is for a cause listed above for which Spectracom is not consequential damages whether the claims are grounded in responsible, Spectracom will make the repairs or replacement of contract, tort (including negligence), or strict liability.
  • Page 5: Table Of Contents

    Spectracom Corporation TPRO-cPCI/TSAT-cPCI Table of Contents OVERVIEW ....................1-1 General Information about GPS .....................1-1 Your Spectracom GPS Receiver....................1-2 Inventory ............................1-2 Inspection and Support ........................1-2 SETTINGS, CONNECTION, AND CONFIGURATION ........ 2-1 Jumper Settings ..........................2-1 Bus Connector ..........................2-2 External Connections ........................2-2 GPS Antenna Connector (TSAT-cPCI Only) ..................2-2 Timing Connector...........................2-2...
  • Page 6 TPRO-cPCI/TSAT-cPCI Spectracom Corporation 5.6.1 Examples for Setting the Heartbeat ....................5-5 Select Oscillator Output Frequency....................5-6 Set Offset Time ..........................5-6 Read Number of Satellites Tracked and Altitude................5-7 5.10 Read Longitude..........................5-8 5.11 Read Latitude..........................5-8 5.12 Enable/Disable Synchronization Flat....................5-9 5.13 Read Synchronization Enable Flag ....................5-9 5.14...
  • Page 7: Overview

    1 kHz carrier referenced to the on-board oscillator. The TPRO-cPCI is similar to the TSAT-cPCI, with the exception that it obtains time from an input time code. The time code can be in IRIG-A, IRIG-B or NASA36 format; the board automatically detects which format is being used.
  • Page 8: Your Spectracom Gps Receiver

    (housed together in a single enclosure), a breakout-cable (DB-15 to several BNC connectors), and a user manual. The TPRO-cPCI does not include those accessories specific to GPS functions. If there is a discrepancy, please contact Spectracom Customer Service at US +1.585.321.5800.
  • Page 9 Discharge (ESD). Observe all ESD precautions and safeguards when handling the timecode generator. NOTE: If equipment is returned to Spectracom, it must be shipped in its original packing material. Save all packaging material for this purpose. Synchronizable Timecode Generator User Manual...
  • Page 10 TPRO-cPCI/TSAT-cPCI Spectracom Corporation Synchronizable Timecode Generator User Manual...
  • Page 11: Settings, Connection, And Configuration

    Spectracom Corporation TPRO-cPCI/TSAT-cPCI 2 Settings, Connection, and Configuration Jumper Settings The board has three push-on configuration jumpers. Verify that these are installed as shown in Figure 2.1. (Certain custom options may call for these these jumpers to be arranged differently than shown in the example.
  • Page 12: Bus Connector

    GPS Antenna Connector (TSAT-cPCI Only) The TSAT-cPCI is equipped with a high-density, 15-pin plug connector, labeled "GPS ANTENNA", which connects to the GPS antenna via the supplied cable. Spectracom cables include shielding to meet EMI requirements. Use of other cables is not recommended.
  • Page 13: Time Code Input

    The time code can be recorded on tape in order to time-stamp data, but there are several drawbacks to this. For example, due to time-base flutter, precision boards like the TPRO-cPCI will not synchronize to a time code that is being played back from tape. Also, when recording, it is often necessary to reduce the amplitude of the signal;...
  • Page 14: Time Tag Input

    Spectracom Corporation TPRO-cPCI/TSAT-cPCI There are two methods for using the time code output to drive inputs for multiple boards. The "T" method connects the output of the master to each slave's input. The advantage of this method is that, if any board loses the incoming signal, it will report a loss of sync and will not affect the other slaves;...
  • Page 15: Indicator Lights

    TPRO-cPCI/TSAT-cPCI Spectracom Corporation small relay. It can also be used to drive TTL logic by connecting an external 4.7K pull-up resistor to +5V. Use of a Schmitt Trigger input (e.g., 74HCT14) is recommended, as the rise time is relatively slow. The external pull-up resistor and the distributed cable capacitance determine the rise time.
  • Page 16 Spectracom Corporation TPRO-cPCI/TSAT-cPCI Synchronizable Timecode Generator User Manual...
  • Page 17: Specifications

    Spectracom Corporation TPRO-cPCI/TSAT-cPCI 3 Specifications NOTE: Specifications apply to both the TPRO-cPCI and the TSAT-cPCI unless otherwise indicated. Table 3.1—General Specifications 100mm, 160 mm, 1.6mm (H, D, T) Size (board) (3.94 inch, 6.30 inch, 0.063 inch) (H, D, T) 3U x 4HP 128.7 mm, 20.32 mm (H, W) Size (front panel) (5.07 inch, 0.80 inch) (H, W)
  • Page 18 TPRO-cPCI/TSAT-cPCI Spectracom Corporation Table 3.4—External GPS Receiver/Antenna TSAT-cPCI Only Number of Satellites Tracked 12 max Acquisition Time (Warm Start) 45 seconds (typical) Acquisition Time (Cold Start) 2 minutes (typ), 15 minutes (max) Frequency 1575.42 MHz (Receive Only, L1 Band, C/A Code, SPS) Sync to UTC ±130 nS (1 sigma, stationary location)
  • Page 19 Cable Size 9 mm (0.4 inch) O.D. Connector Size (both ends) 34 mm X 16 mm (1.4 inch x 0.6 inch) Table 3.7—Time Code Input TPRO-cPCI Only Connector DB-15 TIMING, Pins 1(+) and 2(–) Format (detected automatically) IRIG-B(122) or IRIG-A(132) Amplitude (mark) IRIG-A 1.2 Vp-p (min), 8.0 Vp-p (max)
  • Page 20 Cable Length* (5 MHz) 23 m (75 ft) max Cable Length* (10 MHz) 3 m (10 ft) max Spectracom recommends a 22 AWG twisted, shielded pair cable. Connect shield to connector shell. Table 3.12—Heartbeat Output Connector DB-15 TIMING, pin 14...
  • Page 21 Spectracom Corporation TPRO-cPCI/TSAT-cPCI Table 3.13—Match Output Connector DB-15 TIMING, pin 6 Output Voltage (high) 3.8 V at 4 mA Output Voltage (low) 0.3 V at –4 mA Output Current (high or low) ±6 mA max Setability 1 uS Time base Error Same as on-board clock Table 3.14—In Sync Output...
  • Page 22 TPRO-cPCI/TSAT-cPCI Spectracom Corporation Synchronizable Timecode Generator User Manual...
  • Page 23: Register Level Description

    Spectracom Corporation TPRO-cPCI/TSAT-cPCI 4 Register Level Description NOTE: In this manual, the prefix "0x" indicates that the number is in hexadecimal (Base 16) format. The descriptor “\0” denotes a single ASCII “null” character, which as a value of zero (0x00). It indicates the end of an ASCII string.
  • Page 24: Register Map

    TPRO-cPCI/TSAT-cPCI Spectracom Corporation Register Map The registers are mapped into 64 words (256 bytes) of consecutive memory space as shown below. The absolute memory address is computed as Base+Offset. "tbreg_" denotes "timing board register." For some registers, the content of the data written is irrelevant; the act of writing (any value) to the register triggers an event.
  • Page 25 Spectracom Corporation TPRO-cPCI/TSAT-cPCI 4.3.4 Interrupt Enable Register (tbreg_irq_en) The user can specify which of several possible conditions will generate an interrupt. The individual bits correspond to the IRQ Enable bits in the Status Register. 4.3.5 Clear Flag–Match Register (tbreg_clrflag_m) Writing (any value) clears Flag–Match.
  • Page 26 TPRO-cPCI/TSAT-cPCI Spectracom Corporation 4.3.9.1 Flag–Acquire This status bit is asserted when the board detects that a time code is present (before synchronization is established), or when the GPS receiver is connected, but is not tracking satellites. It is not asserted if no time code is connected to the input.
  • Page 27 These three bits indicate which input time source is being used. This is intended for diagnostic purposes only. tbstat_ssi[2:0] Input Time Source Searching for time code input (TPRO-cPCI) Acquiring GPS satellites (TSAT-cPCI) Time Code Input (IRIG-A autodetected) Time Code Input (IRIG-B autodetected)
  • Page 28 TPRO-cPCI/TSAT-cPCI Spectracom Corporation 4.3.9.17 Time Tag Event Counter This is intended for diagnostic purposes only. It counts the number of time tag events that have occurred since the time tag registers were read. If it reaches maximum count (0xf), it will remain at maximum count.
  • Page 29: Clock Time Registers

    Spectracom Corporation TPRO-cPCI/TSAT-cPCI 4.3.10 Clock Time Registers (tbreg_clk_upper, tbreg_clk_lower, and tbreg_clk_date) To read the Clock Time, first read the Status Register as described above, then read the two Clock Time registers and the Clock Date register. These registers consist of groups of four bits, each of which represents a digit in the time (i.e., it is in Binary Coded Decimal [BCD] format).
  • Page 30 TPRO-cPCI/TSAT-cPCI Spectracom Corporation Synchronizable Timecode Generator User Manual...
  • Page 31: Commands And Responses

    TPRO-cPCI/TSAT-cPCI Spectracom Corporation 5 Commands and Responses Introduction To send a command: 1. Read the Status Register, do not proceed until: Flag–Command Complete = 1. 2. Write the command to tbreg_cmd[3:0]. Important: Write to tbreg_cmd[3] last. 3. If a response is expected, read the Status Register until Flag–Command Complete = 1, then read the response from tbreg_response[3:0].
  • Page 32 TPRO-cPCI/TSAT-cPCI Spectracom Corporation For example, to set the board to year 2001, day 345, hour 12, minute 56, second 29, write the following values: tbreg_cmd[0] = 0x03451256 tbreg_cmd[1] = 0x29000000 tbreg_cmd[2] = 0x00002001 tbreg_cmd[3] = 0x00000010 The board will compute the Gregorian date (December 11) from the Julian day (345) and the year.
  • Page 33: Set Year

    TPRO-cPCI/TSAT-cPCI Spectracom Corporation Set Year 0 x 0015 Time codes (IRIG-A, IRIG-B and NASA36) do not convey the year. Use this command to set the year. This is the same as setting the year using the 0x0010 command, except that this command does not change the Julian day or time.
  • Page 34: Set Match Start Time

    TPRO-cPCI/TSAT-cPCI Spectracom Corporation Set Match Start Time 0 x 0020 Set the Match Start time by writing the following values: Bits tbreg_cmd[0] Bits tbreg_cmd[1] 31:28 (unused) 31:28 10s of seconds 27:24 100s of days 27:24 1s of seconds 23:20 10s of days 23:20 0.1s of seconds...
  • Page 35: Set Heartbeat Divider

    TPRO-cPCI/TSAT-cPCI Spectracom Corporation Set Heartbeat Divider 0 x 0040 The Heartbeat is the output of a programmable divider. This command selects the clock frequency and the counter preset number. The counter counts from the counter preset number up to maximum count (0xffff). When maximum count is reached, one Heartbeat pulse is output, and the counter re-loads the counter preset number.
  • Page 36: Select Oscillator Output Frequency

    TPRO-cPCI/TSAT-cPCI Spectracom Corporation Other examples: Desired Pulse Rate Chosen Clock Select 1.25 MPPS 0x0 (1 * 10 0xfff8 120 PPS 0x1 (3 * 10 0x9e58 100 PPS 0x2 (1 * 10 0xd8f0 0.1 PPS 0x3 (1 * 10 0xd8f0 Notice that, although 120 PPS and 100 PPS are in the range of clock selects 0x2 and 0x3, the clock select must be chosen to divide evenly.
  • Page 37: Read Number Of Satellites Tracked And Altitude

    TPRO-cPCI/TSAT-cPCI Spectracom Corporation Compute N as follows: For negative offsets: N = offset (range 0x0000 through 0x0999) For positive offsets: N = 0x1000 + offset (range 0x1000 through 0x1999) NOTE: Be careful when writing software to increment or decrement this value. Only BCD values are acceptable.
  • Page 38: Read Longitude

    TPRO-cPCI/TSAT-cPCI Spectracom Corporation 5.10 Read Longitude 0 x 0071 (TSAT-cPCI Only) Write command 0x00000071 to tbreg_cmd[3] to read the computed longitude. Units are degrees, minutes, and fractional minutes, not degrees, minutes, and seconds. An ASCII string is returned. Bits tbreg_response[0]...
  • Page 39: Enable/Disable Synchronization Flat

    The Factory Test Messages provide a means of diagnosing problems. There are 16 different possible messages, each of which is 128 bits (4 words) long. Spectracom recommends that the user include the ability to read these messages. Specifically, the user's software should include a function (subroutine) to read and display them (or log them to the disk).
  • Page 40: Read Version

    It is not possible to determine what options are present, or which version is more recent, from this number. It is is for diagnostic purposes only. Spectracom suggests that the user's software include a means of reading and displaying these numbers.
  • Page 41: Options And Accessories

    TPRO-cPCI/TSAT-cPCI Spectracom Corporation 6 Options and Accessories The following options and accessories are available: Accessories 6.1.1 TRIM-CAB-D-D-100 (TSAT-cPCI Only) This cable acts as an extension cord for a board that is using the Trimble GPS Receiver. It consists of a 100’ cable with DB-15 connectors (one male, one female) on the ends. It connects to a board on one end, and to the standard TRIM-CAB-STD cable on the other end.
  • Page 42 TPRO-cPCI/TSAT-cPCI Spectracom Corporation Synchronizable Timecode Generator User Manual...
  • Page 43: Driver Support

    Spectracom Corporation 7 Driver Support Please contact your sales representative for information about Spectracom’s bus-level timing board driver support for Windows, Linux, VxWorks, and a variety of other platforms. You may also visit our website at www.spectracomcorp.com to download datasheets and manuals.
  • Page 44 TPRO-cPCI/TSAT-cPCI Spectracom Corporation Synchronizable Timecode Generator User Manual...
  • Page 45 REVISION HISTORY Revision Level Number Description First conversion of legacy KSI documentation to Spectracom — documentation. Corrected errors in Phase Noise values. Removed reference to 2022 Option 05. Made minor style and format changes. 2218 Changed lower limit of IRIG-B input voltage range to 3.6V.
  • Page 46 Spectracom Corporation 95 Methodist Hill Drive Rochester, NY 14623 www.spectracomcorp.com Phone: US +1.585.321.5800 Fax: US +1.585.321.5219...
