Summary of Contents for Acurix X1-A-22
- Page 1 INSTALLER USER MANUAL X1-A-22...
- Page 2 Acurix Networks - User Manual X1-A-22 Table of Contents Copyright Notice ......................4 FCC Statement ......................... 4 FCC Caution: ..........................4 FCC Radiation Exposure Statement................... 5 Professional Installation ......................5 Safety Warnings......................... 5 Disclaimer; Limitation of Liability ....................6 Equipment........................7 Shipped Equipment List......................
- Page 3 Acurix Networks - User Manual X1-A-22 Copyright Notice Copyright © 2010 aCure Technology Pty, Ltd. All rights reserved. This document may not be reproduced or disclosed in whole or in part by any means without the written consent of aCure Technology Pty Ltd.
- Page 4 Acurix Networks - User Manual X1-A-22 FCC Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 105cm between the radiator & your body. The availability of some specific channels and/or operational frequency bands are country dependent and are firmware programmed at the factory to match the intended destination.
- Page 5 Acurix Networks - User Manual X1-A-22 Power Cord A power cord is not provided with this equipment. Installation This product should be installed by a qualified professional. Disclaimer; Limitation of Liability EXCEPT FOR THE WARRANTIES SPECIFICALLY DESCRIBED HEREIN, ACURE DISCLAIMS ANY AND ALL WARRANTIES AND GUARANTEES, EXPRESS,...
- Page 6 Acurix Networks - User Manual X1-A-22 Equipment Shipped Equipment List The following is normally shipped: 1 x X1-A-22 node 1 x External power supply (48v output) 1 x passive PoE injector 1 X Quick Install Instructions 1 x CD software Page 7 of 11 Confidential.
- Page 7 Both full-duplex and half-duplex mode of operation are supported. Power Connection Power to the X1-A-22 is provided via passive PoE at the Ethernet port. The voltage from the external supplies must be within the PoE range +36V to +60V, (+48V nominal) at the input to X1-A-22.
- Page 8 Software Configuration Overview The X1-A-22 will be delivered in configuration mode so that installers may make a web based connection to the unit for correct operation within their environment. The installation process below should be followed to commence configuration of the unit.
- Page 9 Acurix Networks - User Manual X1-A-22 Set the IP address to 192.168.0.2 as shown below. Select OK. Go to the Command Processor and check that that you can ping the notebook at the address 192.168.0.2. Page 10 of 11 Confidential. © Acurix Networks...
- Page 10 Communications and connecting via a notebook has been completed. Software Installation The X1-A-22 web interface utilises flash for displaying the interface. A browser based flash player must be installed prior to connecting to the unit. A suitable flash player can be downloaded from Adobe located at: http://get.adobe.com/flashplayer/...
- Page 11 Acurix Networks - User Manual X1-A-22 The login prompt will appear: The username is: admin The password is: admin Page 12 of 11 Confidential. © Acurix Networks...
