Marvair GeoScholar Series Manual

Geoscholar heat pump 2, 2.5, 3, 3.5, 4 & 5 tons
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
MODEL NO.: ______________________ SERIAL NO.: _________________
DATE OF START-UP.: _______________
MODELS VWIA, VWISA and VWCA, VWCSA
2, 2.5, 3, 3.5, 4 & 5 Tons
P.O. Box 400 • Cordele, GA 31010
156 Seedling Drive • Cordele, GA 31015
(229) 273-3636 • Fax: (229) 273-5154
Email: marvair@airxcel.com
Internet: www.marvair.com
GeoScholar
Heat Pump
(CSI 15740)
INSTALLATION AND
START-UP
WARNING
SAFETY REQUIREMENTS
• If the information in these instructions are not
followed exactly, a fire may result causing property
damage, personal injury or loss of life.
• Read all instructions carefully prior to beginning the
installation. Do not begin installation if you do not
understand any of the instructions.
• Improper installation, adjustment, alteration, service
or maintenance can cause property damage,
personal injury or loss of life.
• Installation and service must be performed by a
qualified installer or service agency in accordance
with these instructions and in compliance with
all codes and requirements of authorities having
jurisdiction.
• Follow all safety codes.
Part # 01516
GeoScholar IS Manual 03/2019
Rev. 2
