BTT012

Plug & Play Bluetooth USB Dongle

User's manual

Brief introduction..........................1

1. About BTT012..................................1

2. System requirements..........................2

Getting started..............................2

1. Installation......................................2

2.System setting...................................3

3.Pairing Dongle with Bluetooth receive

device..............................................4

4. Music mode and remote control............8

5. Make VOIP call..............................10

Care and maintenance..................13

FAQS........................................14

Specification...............................17

Table of Contents

Need help?

Do you have a question about the BTT012 and is the answer not in the manual?

Questions and answers

Summary of Contents for K-Mate BTT012

Page 1: Table Of Contents
BTT012 Plug & Play Bluetooth USB Dongle User’s manual Brief introduction……………………..1 1. About BTT012…………………………….1 2. System requirements……………………..2 Getting started………………………...2 1. Installation………………………………..2 2.System setting……………………………..3 3.Pairing Dongle with Bluetooth receive device……………………………………….4 4. Music mode and remote control………...8 5. Make VOIP call…………………………10 Care and maintenance………………13 FAQS………………………………..14...
Page 2: Brief Introduction
BTT012. Please read this user manual carefully before use. Brief introduction 1. About BTT012 BTT012 is a Plug & Play Bluetooth USB Dongle, it supports HSP, HFP, A2DP and AVRCP profiles. It has the following features: 1) You can use VoIP software like Skype comfortably after pairing with a Bluetooth headset (or Bluetooth hands-free device) supporting HSP profile.
Page 3: System Requirements
Compliant with USB 1.1, 2.0 Getting started 1. Installation When you first use BTT012, please turn off or forbid the antivirus software. After plugging the Dongle into PC, the operating system will show “Find New Hardware” and install the devices automatically. The whole process will need a few second and if you plugging the Dongle into PC next time, it needn’t install again.
Page 4: System Setting
Before using Dongle, you should set it as default device in Windows Audio Device System.(Control desk→Voice and Audio device) Note: Depending on the actual operating system, the device name maybe is named as“K-mate Dongle”、 “USB Audion Device” or “USB Composite Device”. Following is Windows XP set up method.
Page 5: Pairing Dongle With Bluetooth Receive Device
Before using Dongle to listen wireless music or make VOLP call, you should make sure paring Dongle with Bluetooth earphone(Bluetooth receive device). 1) Inserting BTT012 into PC, then operating system will show “ Find New Hardware” and install the devices automatically.
Page 6 3) Right-button click the central of spherical symbol search equipment, the device will be searched and displayed in around. 4）Choosing BTT012 in search device list, you can see all the Bluetooth services that BTT012 support.
Page 7 5) Right-button click BTT012 and choose pairing, enter “0000” when the software indicate enter PIN number and click confirm.
Page 8 6) After confirm, paring with BTT012 succesfully. 7) Right-button click BTT012 and choose Bluetooth service which you want to connect.
Page 9: Music Mode And Remote Control
Note: Dongle can pairing with Bluetooth Audio receive devices which PIN number is “0000”, “1234”, “8888” or “1111”. Dongle can connect max two devices at the same time, one is hands-free kit HFP connect, the other is stereo music A2DP connect. But if the pairing devices which support HFP and A2DP agreement at the same time(Take most Stereo Bluetooth Headsets as sample) and the Dongle have already...
Page 10 Before playing music, in addition to system setting, you may also set Dongle as audio output devices of player. Please check the specific setting method with the use’s help of player. Take Windows Media Player as example, click “tool→ option→device→speaker”, and set Dongle as voice playback device in attribute.
Page 11 2) Headsets remote control Using Dongle, you can remote control the media player so that you can choose previous song, next song, pause or play. Remote control needed to achieve the following conditions: Pairing headsets should support A2DP or AVRCP agreement.
Page 12: Make Voip Call
you can not remote control the media player. Pairing device only support HFP agreement Although pairing device support HFP and A2DP etc. agreement, but it enter the conversation mode in currently so that it activate the HFP service. 5. Make VOIP call Dongle support VOIP service following common internet communication software: MSN, Skype, Google Talk, Yahoo Talk.
Page 13 installation.
Page 14 2）Make call with Skype Type Function Operation steps status of headsets Operat Answer Ringing Use the function of last ion of call number dailing on the headse headsets to answer the call Reject Ringing Use reject function on the call headsets to reject the call End call Conversa...
Page 15: Care And Maintenance
Care and maintenance Please read the following suggestion carefully, it will help you to fulfill any warranty obligation and enjoy this product for many years. ● Keep dry and don’t put it in the wet place, in case of effecting the interior circuit of product. ●...
Page 16: Faqs
product. ● Don’t scrap the surface with sharp things. If the product can’t work normally, please send it to the regularly asserted store, the staff will help you to solve problem warmly. FAQS 1 Q: Why can not turn on the Dongle？ A: a) Please avoid to use the USB extension cable.
Page 17 has already set to Dongle(refer to“ system setting”); b) Make sure the default audio output device of media player is Dongle; c) Make sure the player is not in mute; d) Make sure the volume of player has already adjusted to suitable position. e) Make sure the volume of receiving device has already adjusted to suitable position.
Page 18: Specification
d) Make sure media player is not in background playing status. 5 Q: Why can listen to low quality but can not switch to music mode? A: a) Make sure the VoIP calls has already ended； b) Windows may work unusual, please try to log-out system.
Page 19 (1) This device may not cause harmful interference, and(2) this device must accept any interference received, including interference that may cause undesired operation. Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
