Summary of Contents for UNIRAC Flat Flashing
- Page 1 Unirac Flat Flashing INSTALLATION MANUAL © 2011 by Unirac, Inc. All rights reserved. Pub 110525-1ii, May 2011 1411 Broadway Boulevard NE Albuquerque, NM 87102-1545 USA A HILTI GROUP COMPANY...
-
Page 2: Before You Begin
IMPORTANT! Unirac Inc. makes no warranty of any kind with regard Unirac Inc. to this material, including, but not limited to, the Marketing Department implied warranties of merchantability and fitness for a 1411 Broadway Boulevard, NE particular purpose. Albuquerque, NM 87102-1545 The information in this document is subject to change ©... - Page 3 Step 2: Center the Flat Flashing over the rafter and drill a pilot hole for the lag bolt. Step 3: Insert the Flat Flashing so the top part is under the next row of shingles and the hole lines up with the pilot hole.
- Page 4 Step 4: Insert the lag bolt through the components in the order shown in the illustration. Tighten into the rafter. 1. Lag Bolt (Installer Provided) 2. EPDM Washer 3. L-Foot (or other rail attachment piece) 4. Square Aluminum Piece (concave side down)
-
Page 5: Warranty
WARRANTY See http://www.unirac.com for current warranty documents and information. - Page 6 Unirac Flat Flashing INSTALLATION MANUAL www.unirac.com...
