CAUTION: INSERT THE DRIVER CD INTO YOUR COMPUTER FIRST AND THEN
FOLLOW THE INSTRUCTIONS TO COMPLETE YOUR SETUP PROCESS.
INTRODUCTION

DRIVER INSTALLATION

Windows:
1. Insert the driver disc into your computer's CD-ROM drive. When prompted, select "Driver Setup", and press OK to
install driver.
Note: In most systems, the Setup Wizard will start automatically. If Automatic Setup does not begin, start the Setup
program manually by selecting "Start/Run", type "E:\setup", where "E:" represents the location of the CD-ROM
drive, then press "Enter".
Note: In certain cases, Windows might ask for your permission because it cannot recognize the driver you are
downloading. If this occurs, select "Continue Anyway" and continue to install.
Macintosh:
1. Insert the driver disc into your computer's CD-ROM drive.
2. Check to see if the "Genius Tablet" is shown on the screen. Double click the icon then follow the instructions.
3. Enter your administrator name and password to process the next step till it's finished.
Note: For more information, refer to the MAC user manual on the driver disc.
CAUTION: ONCE THE INSTALLATION HAS BEEN COMPLETED, REBOOT YOUR MACINTOSH BEFORE
PLUGGING THE DEVICE INTO YOUR COMPUTER.

HARDWARE INSTALLATION

CAUTION: MAKE SURE THAT YOU HAVE INSTALLED THE DRIVER SOFTWARE (SEE ABOVE) INTO
YOUR COMPUTER BEFORE INSTALLING THE HARDWARE.
1. Put the batteries into the back of tablet, insert two batteries on each side of the battery
slot first, then put the last battery in the middle.
2.
Plug the tablet dongle into your computer's USB port (located on the computer,
display, or keyboard). The tablet's LED light will indicate the operational status, and
your computer screen will display a "found new hardware" message.
Note : Do not mix or use different types of batteries at the same time such as
Li-Ion, Alkaline, etc; and remember do not put the batteries in the wrong direction.
G
ENIUS
Q U I C K I N S T A L L A T I O N G U I D E
G
T
RAPHIC
ABLET
Dongle & battery slot
1.
USB port (for charging only)
2.
LED indicator
3.
Power switch
4.
Resume button
5.
Express keys
6.
Pen clip and slot
7.
Working area
8.
Button 2
9.
Button 1
10.
Pen tip
11.
Dongle
12.
1
ENGLISH

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EasyPen M406W and is the answer not in the manual?

Questions and answers

Summary of Contents for Genius EasyPen M406W

  • Page 1 1. Insert the driver disc into your computer’s CD-ROM drive. 2. Check to see if the “Genius Tablet” is shown on the screen. Double click the icon then follow the instructions. 3. Enter your administrator name and password to process the next step till it’s finished.
  • Page 2 ENGLISH VERIFYING THE INSTALLATION To ensure that everything has been installed properly, follow the procedures below. Check the User’s manual on the CD-ROM for more information. ERIFYING ARDWARE AND RIVER UNCTIONS The LED light on the tablet is the main indicator for hardware operation. The light normally stays off, and will light up in various situations.
  • Page 3 ENGLISH NOTES ON BATTERY USAGE When you use the battery, carefully read and strictly observe the Safety Instructions and the notes described below: Different battery types and surrounding temperatures may affect the battery performance. Avoid using batteries in extremely cold environments as low temperatures can shorten the battery life and reduce wireless device performance.
