Eastech S-100 User Manual

2.4ghz wireless optical mouse

Advertisement

Quick Links

2.4GHz WIRELESS OPTICAL MOUSE
PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING
THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause
undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant
to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause harmful interference
to radio communications. However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
-
Reorient or relocate the receiving antenna.
-
Increase the separation between the equipment and receiver.
-
Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
-
Consult the dealer or an experienced radio/TV technician for help.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
S-100
USER MANUAL
COMPLIANCE WITH FCC REGULATIONS
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S-100 and is the answer not in the manual?

Questions and answers

Summary of Contents for Eastech S-100

  • Page 1 2.4GHz WIRELESS OPTICAL MOUSE S-100 USER MANUAL PLEASE READ THIS USER MANUAL COMPLETELY BEFORE OPERATING THIS UNIT AND RETAIN THIS BOOKLET FOR FUTURE REFERENCE COMPLIANCE WITH FCC REGULATIONS This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions:...
  • Page 2 FUNCTIONS AND CONTROLS Item Description Left Button Scroll Wheel with Button (Middle Button): works in Windows based PC only Right Button Power Switch - ON: turns Mouse on. - OFF: turns Mouse off (recommended when not in use). Optical Sensor System: red light will be emitted when power is turned on Battery Compartment: hidden underneath cover and holds 2 x AAA batteries (not included) USB Receiver Storage Compartment: hidden underneath Battery Compartment Cover.
  • Page 3 WARNINGS!  Batteries must be installed or replaced by an adult.  The use of good quality alkaline batteries is recommended.  Place batteries based on the polarity shown on the battery compartment.  Only use the recommended type of batteries. ...
  • Page 4 Turn of the Mouse. Switch on the Mouse. Push the Right and Scroll Buttons at same time. When pairing is successfully established, the mouse cursor will move again. CARE AND MAINTENANCE 1. Turn off your mouse by sliding Power Switch to “OFF” when not in use to conserve battery power. 2.
  • Page 5 SPECIFICATIONS Transmitter (in Mouse unit) Specifications Sensor System Optical LED Resolution 800dpi Wireless Frequency 2.408 – 2.474GHz Modulation GFSK with 2-way “Frequency Agility Protocol” coding Working Distance About 30 feet / 9m Power Source 2 x DC1.5V ‘AAA’ (UM-4) alkaline batteries (Not included) Current Consumption About 11mA Average Battery Life...
