Jun Shade JSR-4300 Manual

RF REMOTE CONTROLLER
SPECIFICATION
Operationg Voltage
Operationg Distance
Operationg Frequency 447.775 MHz or

HOW TO SET-UP

1. Set installed curtain motor or receiver to Set-Up mode
Curtain motor : Put 1st terminal of DIP switch to "ON".
Receiver : If you release PROG button after pressing it for 2 seconds, the Red LED blinks.
2. Select desired any channel by
3. Press PROG Button on the back of Controller for 2 seconds.
4. If Remote Controller complete Set-Up correctly, the buzzer sound once.
Curtain Motor : Buzzer sounds once
RF Receiver : Red LED Light comes 'ON'
5. Turn the 1st terminal of the DIP switch to "OFF". Then, if the LED of the curtain motor lights 'ON'.
The Remote controller Set-Up is finished.
6. Set the rest of the channels in the same way.
RF Remote Controller retains the last selected channel.
Each Set-Up channel is memorized for collective control without additional Set-Up Procedure.

HOW TO ERASE SET-UP CHANNEL

Curtain Motor
1. Turn NO.1 dip S/W to 'on', right side, LED in motor blinks.
2. After selecting the applied channel, press PROG button for 2 seconds. If erasing completes correctly,
the buzzer sounds two times from motor and controller.
RF Receiver
1. Red LED Light comes off when you press PROG button for 2 seconds and take off.
2. Press PROG button for 2 seconds after selecting the applied channel.
If erasing completes correctly, the buzzer sounds two times from Romote controller & Red LED L ight comes off.
( Caution : If there are remained Set-Up channel in Remote Controller, Red LED Light keeps 'ON')
Radio Wave type
3V
Wireless Standard
Within 1km
Communication System
433.92 MHz
button. The number of the desired channel is indicated by LED Light comes 'ON'
0
F10
Wireless device for wireless
minimal output
1 Way RF
0
The LED of the curtain motor blinks when you do this.
Model . JSR - 4300
