HS-360X Four-Slot Spare

Battery Charger

Quick Start Guide

Table of Contents

Need help?

Do you have a question about the HS-360X and is the answer not in the manual?

Questions and answers

Summary of Contents for Omron Microscan HS-360X

Page 1 HS-360X Four-Slot Spare Battery Charger Quick Start Guide...
Page 2 Omron Microscan-manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Omron Microscan. Throughout this document, trademarked names might be used. We state herein that we are using the names to the benefit of the trademark owner, with no intention of infringement.
Page 3: Related Documentation
Accessories • Two screws (for wall mounting, if applicable; user-supplied). • Power supply for desk/wall mounting configuration. 98-9000182-01 Kit, Power Supply for 4-Slot Battery Charger, HS-360X, A/C Power Cord Required 98-9000224-01 Battery, Spare, HS-360X Wireless 12-9000959-01 AC Power Cord, 2.5 M, U.S., C13 Conn.
Page 4 HS-360X Four-Slot Spare Battery Charger Quick Start Guide Charger Parts Four-Slot Spare Battery Charger Front View Battery Charging LED (four) Battery Well (four) Four Slot Spare Battery Charger Back View Wall Mount Power Cable Key-Hole Rubber Feet Groove (two) (four)
Page 5: Mounting The Charger
HS-360X Four-Slot Spare Battery Charger Quick Start Guide Mounting the Charger To mount the charger on a vertical (wall) surface: Connect the power cable to the power port and an AC power source. Insert the power cable into the cable groove.
Page 6: Led Indicators
HS-360X Four-Slot Spare Battery Charger Quick Start Guide LED Indicators Power/Charging LED Sequence Standard Use Red, amber, green, off (all four LEDs) Power up Idle Battery Indications Amber (blinking) Charging Amber (stays on) Pre-charging Green (stays on) Fully charged Amber (fast blinking)
Page 7: Regulatory Information
Declared maximum operating temperature: 50°C. Power Supply Use only an Omron Microscan-approved UL-LISTED ITE (IEC/EN 60950-1) power supply with electrical ratings: Output 12 Vdc, min 4.6A, with a maximum ambient temperature of at least 50 degrees C. Use of alternative power supply will invalidate any approvals given to this device and may be dangerous.
Page 8: Battery Safety Guidelines
Replace the battery when a significant loss of run time is detected. Standard warranty period for all Omron Microscan batteries is 30 days, regardless if the battery was purchased separately or included as part of the barcode scanner.
Page 9: Statement Of Compliance
Marking and European Economic Area (EEA) Statement of Compliance Omron Microscan hereby declares that this device is in compliance with all applicable Directives, 2014/30/EU, 2014/35/EU and 2011/65/EU. The full text of the EU Declaration of Conformity is available at the following internet address: http://www.microscan.com/support.
Page 10: Waste Electrical And Electronic Equipment (Weee)
Omron Microscan k recyklaci. Informace o způsobu vrácení produktu najdete na webové stránce: http://www.microscan.com/support. Dansk: Til kunder i EU: Alle produkter skal returneres til Omron Microscan til recirkulering, når de er udtjent. Læs oplysningerne om returnering af produkter på: http://www.microscan.com/support.
Page 11: China Rohs
Polski: Klienci z obszaru Unii Europejskiej: Produkty wycofane z eksploatacji naleźy zwrócić do firmy Omron Microscan w celu ich utylizacji. Informacje na temat zwrotu produktów znajdują się na stronie internetowej http://www.microscan.com/support.
Page 12 Omron Microscan-manufactured equipment and is not to be released, reproduced, or used for any other purpose without written permission of Omron Microscan. ©2018 Omron Microscan Systems, Inc. P/N 83-9310017-02 Rev C...
