Summary of Contents for Pegatron WL-227N_ABAND
- Page 1 WL-227N_ABAND Mini PCI WiFi (802.11 a/n) Card Hardware and Driver Reference...
- Page 2 CONTENTS CONTENTS..................2 INTRODUCTION................3 SCOPE ..................... 3 ACRONYMS AND DEFINITIONS ............. 3 GENERAL FEATURES ..............3 DRIvER.INSTallaTION.............4 SaFETY.INFORMaTION.............6 NOTE:.Information.in.this.document.is.subject.to.change.after.this.document.is. made.available. WL-227N_ABAND Hardware & Driver Reference...
- Page 3 Two Tx transmits from transceiver through an external PA to the Mechanism antenna. Three Rx act as MIMO coming from the antennas. Antenna Connectors Hirose U.FL-R-SMT-1(10) compatible Driver Support OS Linux Application This module will be used in a 12 inch or greater laptop. WL-227N_ABAND Hardware & Driver Reference...
-
Page 4: Driver Installation
DRIvER INSTALLATION Driver installation for Linux 1. Insert USB flash disk & WL-227N_ABAND NIC before booting 2. Boot Linux system and login 3. Create path [Wireless]: mkdir /etc/Wireless 4. Mount USB Hard Disk: mount /dev/sda1 /mnt 5. Copy tar file to Linux from USB Hard Disk: cp /mnt/2008_0812_RT2880_iNIC_v1.1.8.0.tar.bz2 /etc/Wireless/... - Page 5 DRIvER INSTALLATION 9. Setup and bootstrap WL-227N_ABAND NIC: a. Setup WL-227N_ABAND NIC: insmod /etc/Wireless/RT2880/module/rt2880_iNIC.ko mode=sta • If it shows “ra0:Ralink iNIC at 0xe0cc0000(hardware address), 00:43:0c:00:00:00 (MAC address), IRQ169 (IRQ address)”, the NIC is boot strap successfully. b. Bootstrap NIC parameters: •...
-
Page 6: Safety Information
Under such configuration, the FCC radiation exposure limits set forth for an population/uncontrolled environment can be satisfied. WL-227N_ABAND Hardware & Driver Reference... - Page 7 Any changes or modifications not expressly approved by the manufacturer could void the user's authority to operate this equipment. USERS MANUAL OF THE END PRODUCT: In the users manual of the end product, the end user has to be informed to keep at least 20cm separation with the antenna while this end product is installed and operated.
