UNIVERSAL
MOUNT
Operator Manual
Model: UM-01
NOTE TO INSTALLERS
Always Read Instructions Before Use
The Operator Manual contains information relating to the
proper use of the Universal Mount and includes all product
and warranty information. This document may only be
removed by the end user. Ensure that this Operator Manual
is readily available to operators at all times.
Head Rush Technologies Universal Mount Operator Manual
P/N 00070045003
Head Rush Technologies products are covered by a number of patents, including
U.S. Patents 8,490,751; 8,851,235; 9,016,435; 8,851,235 and D654,412
& corresponding patents/applications in the USA and in other countries worldwide.
ACCESSORY OF THE
Advertisement
Table of Contents
Summary of Contents for head rush technologies UM-01
- Page 1 Head Rush Technologies Universal Mount Operator Manual P/N 00070045003 Head Rush Technologies products are covered by a number of patents, including U.S. Patents 8,490,751; 8,851,235; 9,016,435; 8,851,235 and D654,412 & corresponding patents/applications in the USA and in other countries worldwide.
-
Page 2: Table Of Contents
TABLE OF CONTENTS SAFETY INFORMATION Symbols Used in this Manual WARRANTY CONDITIONS Customer Responsibility DESCRIPTION SPECIFICATIONS UNIVERAL MOUNT PARTS UNPACKING Precautions Receipt of the Universal Mount INSTALLATION Precautions Standards Anchor Points Secondary Connectors Selecting a Location Mounting Mounting Points Strap Mounting Bolt-Hole Point Mounting OPERATION Operator Training... - Page 3 IMPORTANT SAFETY NOTICE Climbing Is a Dangerous Activity Read Before Installation & Operation Failure by the installer or operator to heed any and all instructions, warnings, and cautions for the correct installation, operation, care, and maintenance of the Universal Mount may result in serious injury and/or death. The Universal Mount and associated equipment is designed and specified for use in the recreational climbing industry as a climbing anchor.
-
Page 4: Safety Information
SAFETY INFORMATION Symbols Used in this Manual The following safety symbols are used throughout this manual to highlight po- tential dangers. One or more precautions may be associated with practices and procedures described within this manual. Failure to adhere to the precautions highlighted can result in death, serious injury, and equipment damage. -
Page 5: Warranty Conditions
Head Rush Technologies. Head Rush Technologies makes no warranties in respect to trade accessories or component parts which are not made by Head Rush Technologies. - Page 6 ƒ Wearing or additional parts such as fasteners, straps, etc. ƒ Normal deterioration due to use and exposure This warranty is subject to the following requirements of this Operator Manual, manufacturer instructions, and advice given by authorized Head Rush Technolo- gies service technicians.
-
Page 7: Description
DESCRIPTION The Universal Mount is a mounting device designed specifically for use as a climbing anchor. It is meant to be used on trees, poles, and climbing walls to pro- vide an anchor point to mount a TRUBLUE® Auto Belay or other climbing anchor. The Universal Mount is suitable for climber weights up to 150 kg (330 lbs). -
Page 8: Specifications
SPECIFICATIONS MODEL UM-01 DIMENSIONS 300 x 175 x 257 mm (11.8 x 6.9 x 10.1 in) NET WEIGHT 2.95 kg (6.5 lbs) MATERIALS Powder Coated Aluminium 6061-T6 MAX. CLIMBER WEIGHT 150 kg (330 lbs) www.headrushtech.com | +1-720-565-6885... -
Page 9: Univeral Mount Parts
UNIVERSAL MOUNT PARTS SPINE BOLT HOLES (6) MOUNTING HOLES (2) MOUNTING STRAP SLOTS (2) MFG DATE BASE www.headrushtech.com | +1-720-565-6885... -
Page 10: Unpacking
UNPACKING Precautions LEAVE THIS OPERATOR MANUAL ATTACHED TO THE UNIVER- SAL MOUNT UNTIL INSTALLATION IS COMPLETE The Operator Manual contains information relating to the proper use of the Universal Mount and warranty information. The Operator Manual may only be removed by the end user. Ensure this manual is readily available to Universal Mount users at all times. -
Page 11: Installation
INSTALLATION Precautions ALWAYS USE DESIGNATED MOUNTING POINTS AND METHODS Never install the Universal Mount using any part of the device apart from the des- ignated mounting points. Incorrect mounting can result in death or serious injury. HARD IMPACTS MAY RESULT IN STRUCTURAL DAMAGE Dropping of, or hard impacts to, the Universal Mount can result in serious damage to mounting points and the structure and may compromise safety of operation. -
Page 12: Secondary Connectors
SECONDARY CONNECTORS All secondary connectors and hardware used in the installation of the Universal Mount must be of compatible size, shape, and strength for the mounting point to which they are attached and conform to the following safety standards: ƒ EN 362 - Types of connectors for personal protection ƒ... -
Page 13: Mounting Points
MOUNTING POINTS USE ONLY THE MOUNTING METHODS AND POINTS DESIGNAT- ED IN THIS MANUAL Use only the correct mounting points designated for use with straps or bolts. Use of incorrect points can result in equipment damage. STRAP MOUNTING The Universal Mount may be mounted using straps to avoid permanent installation, damage to trees, poles, or mounting surface. -
Page 14: Bolt-Hole Point Mounting
MATERIALS DESCRIPTION PROJECT: P/N: PROPRIETARY AND CONFIDENTIAL FERENCE 6/28/16 ASSEMBLY UNIVERSAL MOUNT MODEL UM-01 THE INFORMATION CONTAINED IN THIS DRAWING IS THE SOLE TITLE: PROPERTY OF HEADRUSH www.headrushtech.com | +1-720-565-6885 TECHNOLOGIES. ANY UNIVERSAL MOUNT MOUNTING REFERENCE REPRODUCTION IN PART OR AS A WHOLE WITHOUT WRITTEN PERMISSION IS PROHIBITED. -
Page 15: Operation
OPERATION Owners and purchasers of the Universal Mount are responsible for the safety and supervision of any person using this equipment and are required by the manufac- turer to read, understand, and follow all instructions in this Operator Manual re- garding the correct installation and operation of the Universal Mount prior to use. -
Page 16: Inspection & Maintenance
The Universal Mount has been designed for use outside and in harsh environments with a wide range of temperature and weather conditions. If the mount is found to be damaged or worn during inspection, replacements are available from Head Rush Technologies and Authorized Service Centers. Weekly Inspection SAFETY PRECAUTIONS The Universal Mount must be inspected weekly for overall condition to verify against acceptable wear. -
Page 17: Manufacturer's Details
MANUFACTURER’S DETAILS Return the Universal Mount to the manufacturer at the address shown below for any replacement or unscheduled service or repairs. ADDRESS CONTACT DETAILS Head Rush Technologies +1-720-565-6885 1835 38th Street, Suite C www.headrushtech.com Boulder, CO 80301 info@headrushtech.com www.headrushtech.com | +1-720-565-6885... - Page 18 www.headrushtech.com info@headrushtech.com +1-720-565-6885 Aug 2016...
