Media Vision MV-ALS-STFM-D Professional Installation Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
MV-ALS-STFM-D
Professional Installation Guide

Advertisement

loading
Need help?

Need help?

Do you have a question about the MV-ALS-STFM-D and is the answer not in the manual?

Questions and answers

Summary of Contents for Media Vision MV-ALS-STFM-D

  • Page 1 MV-ALS-STFM-D Professional Installation Guide...

  • Page 2: Table Of Contents

    1 - 2 Introduction Product Highlights Product Package General Information 3 RF Power Single MV-ALS-STFM-D Rack Kit Installation 4 - 6 Double MV-ALS-STFM-D Rack Kit Installation 6 – 12 12 – 13 Helical Antenna 14 – 17 Remote Dipole Antenna...

  • Page 3: Overview

    20 mW, Nominal The MV-ALS-STFM-D Base Unit works in conjunction with the MV-ALS-PRFM. Please see the Media Vision Assistive Listening User Manual for general information on overall system implementation, connecting to the Dante Network and software configuration. Federal Communication Commission Interference Statement This device complies with Part 15 of FCC Rules and Regulations.

  • Page 4: Introduction

    Installation only by Professional Installers: The Media Vision Dante Enabled Stationary Base Transmitter requires professional installation. A professional installer is required to install the MV-ALS-STFM-D. You must follow Part 15 of the FCC rules, and specifically Part 15.203 pertaining to antenna requirements of an intentional radiator.

  • Page 5: General Information

    The MV-ALS-STFM-D Stationary Base Transmitter comes with the Dante Enabled Stationary Base Transmitter, Rack Kit, Power Adapter Cord, and programming Cable. Required to make the MV-ALS-STFM-D function properly are one of the two FCC approved Antenna: A. MV-ALS-AT01 (Helical Antenna).
  • Page 6 Note: For installation of (2) MV-ALS-STFM-D into Rack System please skip to section 8. Step 1. The feet on the MV-ALS-STFM-D are secured and locked in by a pressure fit plug. Utilizing a flathead screwdriver or comparable tool, remove the (4) feet from the MV- ALS-STFM-D by inserting it into the foot and gently lift the screw until you are able to remove it.
  • Page 7 (Screw Removed from the MV-ALS-STFM-D Foot.) (MV-ALS-STFM-D with feet removed.)
  • Page 8 Step 2: Rack Ears A. Attach the short rack ear to the left or right side of the MV-ALS-STFM-D with the four rack ear screws. B. Attach the long rack ear to the right or left side of the MV-ALS-STFM-D with four rack ear screws.
  • Page 9 (MV-ALS-STFM-D with Rack Kit installed in Rack System) 8. Installation of two MV-ALS-STFM-D - Rack Kit Step 1. The feet on the MV-ALS-STFM-D are secured and locked in by a pressure fit plug. Utilizing a flathead screwdriver or comparable tool, remove the (8) feet from the (2) MV-ALS-STFM-D by inserting it into the foot and gently lift the pressure fit plug until you are able to remove it.
  • Page 10 (Removing Foot from MV-ALS-STFM-D) (Pressure fit plug removed from the MV-ALS-STFM-D foot.) (MV-ALS-STFM-D with feet removed.)
  • Page 11 Step 2: Linking bars A. Place the MV-ALS-STFM-D side by side. The indent on the top of the MV-ALS- STFM-D should meet to form a complete linking bar indent. B. Line the linking bar up with the indent between the two MV-ALS-STFM-D. Then...
  • Page 12 C. Flip the two MV-ALS-STFM-D upside down and align the linking bar with the 4 screw holes in the middle.
  • Page 13 E. Flip the two MV-ALS-STFM-D over gently and attach the short rack ear to the left side of the MV-ALS-STFM-D with four linking bar screws. F. Attach the short rack ear to the right side of the MV-ALS-STFM-D with four rack ear screws.
  • Page 14 (Rack Kit Installed on two MV-ALS-STFM-D) F. Place the two MV-ALS-STFM-D into the Rack System and utilize rack ear screws to secure both ends...

  • Page 15: Helical Antenna

    9. Helical Antenna Installation Included: (1) Helical Antenna Step 1. Align the Helical Antenna with the BNC Antenna connector.
  • Page 16 Step 2. Connect the Antenna and the BNC antenna connector. Secure and lock it into place.

  • Page 17: Remote Dipole Antenna

    9. Remote Dipole Antenna Installation Includes: (1) Bracket with Mounted Antenna (1) 25” Coaxial Cable (6) Stoppers (6) Screws. Step 1. Choose the location where you’d like to install the Antenna Bracket. When selecting the location of your Antenna avoid any metal obstructions or steel beams between the Antenna and the receiver.
  • Page 18 Step 3. Position the two openings on each end of the bracket onto the screws and slide the bracket down until it can move no further.
  • Page 19 Step 4. Using the cable clips, secure the coaxial cable onto a flat surface. Make sure that cable clips are at least 4 inches apart. Step 5. Attach the coaxial cable to the BNC antenna connector on the back of the transmitter.

  • Page 20: Installation Technical Information

    8. Installation - Technical Information 8a. MV-ALS-STFM-D Channels 57 (6 Simultaneous) Transmission Range Up to 1,500 ft. 80 dB Frequency 70Hz-12Khz Response Distortion <2% Display OLED Input 1 XLR - TRS Combo Jack - Line, Mic, Mic+PH Input 2 Stereo RCA Audio Out Stereo RCA.
  • Page 21 8.46” X 8.26” X 1.96” Size Weight 3.7 lbs. Warranty Lifetime Approvals / FCC, RoHS Certifications 8b. MV-ALS-AT01 8.89” Height; 1.14” Distance from MV-ALS-STFM-D Dimensions Weight 2 oz. Frequency Range 72-76 MHz 50 Ω Nominal Impedance VSWR 2:1 or Better...
  • Page 22 Dimensions (41 mm) High, Collapsed; (970 mm) Extended; (180 mm) Distance from Wall Weight 245g Frequency Range 72-76 MHz 50 Ω Nominal Impedance VSWR 3:1 or Better Power Handling Capability 20mW, Nominal Warranty 90 Days...
