SUNITEC ENTERPRISE CO.,LTD
Bluetooth USB_Headset Combo(BTH-07C)User Manual
About Bluetooth Technology?
Bluetooth makes wireless transmission between all mobile and non-mobile facilities possible.
technique utilizes global sound & digital data 2.4G ISM transmission and makes global communication easily.
How does Bluetooth COMBO help you?
This multi-functional Bluetooth COMBO consists of Headset and Dongle – Class 2. (to be referred as
COMBO.)
(A) Headset:
When it's under Headset mode, supports all Bluetooth mobile phones and facilities with Bluetooth audio
transmission.
Powered by a built-in rechargeable battery, it can be either charged via the attached mini
AC/DC charger or via the built-in USB connector to the PC USB port.
This Bluetooth Unit
(a) It wirelessly activates phones located in anywhere within 10 meters(max.) to this unit.
(b) Voice Activation: To voice activate phone through microphone of this unit or phone itself, subject to phone
built-in with voice activation function.
(c) Press to Answer/End: To answer an incoming call or end a conversation without pressing on phones.
Simply press the multi-function key on this unit.
(d) Volume Adjustment: Simply tune the built-in volume switch to adjust volume.
(e) It makes real Hands-Free & safe driving possible.
Dongle:
(B)
When it's under USB mode, with the attached Windows driver, it support most of the common Bluetooth
profiles such as Mobile Phone, Digital Camera, P.D.A., Printer, Mouse, Fax, Bluetooth Serial Port, File
Sharing/Transmission, Network Access, Object Push, Dial-up Network, LAN Access,..., etc. It's the most
efficient tool to communicate with the latest Bluetooth-enabled devices. To use, please refer to the attached
Window Driver CD.
Working Mode:
The COMBO is a combination of Headset and Dongle. It's auto switching in between the two modes
by detecting the external connections. It'll be only switched to USB mode, when it's connected to the
USB port of PC. Under normal status, without connecting to USB port, it's always under headset mode.
www.sunitec.com
This
Advertisement
Table of Contents
Related Manuals for SUNITEC ENTERPRISE CO BTH-07C
Summary of Contents for SUNITEC ENTERPRISE CO BTH-07C
- Page 1 SUNITEC ENTERPRISE CO.,LTD www.sunitec.com Bluetooth USB_Headset Combo(BTH-07C)User Manual About Bluetooth Technology? Bluetooth makes wireless transmission between all mobile and non-mobile facilities possible. This technique utilizes global sound & digital data 2.4G ISM transmission and makes global communication easily. How does Bluetooth COMBO help you? This multi-functional Bluetooth COMBO consists of Headset and Dongle –...
-
Page 2: First Time Use
SUNITEC ENTERPRISE CO.,LTD www.sunitec.com Instruction for Headset Mode: Preparation & Start to Use: Make sure the phone is with Bluetooth function or connected to Bluetooth Adaptor. First Time Use: (A) Pairing this unit with phones - Configuration set up. (B) Locate this unit to phones within 10 meters(max.). (C) Please fully charge this unit with the attached mini AC/DC charger. - Page 3 SUNITEC ENTERPRISE CO.,LTD www.sunitec.com To voice dialing, under stand-by mode, press function key, up & down, to enter into Bluetooth connection mode - green LED blinks once every 1.5 seconds with a short beep coming out of this unit. User may talk to mic. of this unit for voice dialing.
- Page 4 SUNITEC ENTERPRISE CO.,LTD www.sunitec.com complete pairing. (Pairing procedure might be varied because of different phones. Users are recommended to refer to individual User's Manual.) Mean while, this unit is under connection mode - green LED blinks once every 4 seconds. (d) To remove pairing, constantly press function key for 4 seconds until both green &...
- Page 5 SUNITEC ENTERPRISE CO.,LTD www.sunitec.com Operation Battery Normal Battery Low Power OFF LEDs OFF LEDs OFF Stand-By Green LED blinks once every 4 seconds Red LED blinks once every 4 seconds Incoming Calls Green LED blinks twice every 1.5 seconds Red LED blinks twice every 1.5 seconds Outgoing Calls Green LED blinks once every 1.5 seconds Red LED blinks once every 1.5 seconds Charging: Under Charge...
- Page 6 SUNITEC ENTERPRISE CO.,LTD www.sunitec.com off. Meanwhile, a short beep comes up. (C) To Use headset: Once pairing is successful, this unit is under stand-by mode and ready for Bluetooth communication. Please locate this unit within 10 meters (max.) to phones. (a) To Answer a Call: When a call is in, a ringing tone will come out of headset.
- Page 7 SUNITEC ENTERPRISE CO.,LTD www.sunitec.com Instruction for USB Mode: When the COMBO is under USB mode, it works as a HCI USB device (USB dongle). Together with an external Upper layer Bluetooth Protocol Stack and relative applications, it enables PC or Laptop to communicate with other Bluetooth devices and can be charged through the USB port.
