- Page 1 INSTRUCTION MANUAL COLOR MONITOR Model No. : EFL-1902X www.effinet.co.kr...
-
Page 2: Table Of Contents
Table of Contents IMPORTANT SAFEGUARDS ............. 3 QUICK REFERENCE TABLE OF CHARACTERISTICS..4 KEY & OSD CONTROL..............5 KEY & OSD CONTROL..............6 . STANDARD DISPLAY MODE ..........8 INSTRUCTION MANUAL EFL-1902X... -
Page 3: Important Safeguards
Never spill routine safety checks to determine that the monitor liquid of any kind on the monitor. is safe to operate. INSTRUCTION MANUAL EFL-1902X... -
Page 4: Quick Reference Table Of Characteristics
Temperature : -20 to 70ºC / Humidity : 5 to Conditions Storage White Color Temperature 9300°K : CIE x=0.281±0.015 / y=0.311±0.015 6500°K : CIE x=0.313±0.015 / y=0.329±0.015 Demonstrated MTBF More than 20,000 hours Regulation CUL(UL+CSA), CE, FCC Touch Screen Optional INSTRUCTION MANUAL EFL-1902X... -
Page 5: Key & Osd Control
1056 normal fill to aspect ratio mode color temp 6500 7300 9300 user PICTURE UTILITY english german language press <up> to reset factory power on time 10 hr information 800 x 600 / 60Hz INSTRUCTION MANUAL EFL-1902X... -
Page 6: Key & Osd Control
Red/Green/Blue Gain Adjust the Red/ Green / Blue Gain Language Select the OSD language Factory recall Recall the factory setting value. Power On time Displayed the total power on time. Information Displayed the resolution of input signal INSTRUCTION MANUAL EFL-1902X... - Page 7 Ground - Green No Connection Ground - Blue 1-2) 13pin Board-In type Connector Shape Description Description Signal - Blue Ground - Blue Vertical Sync Ground Signal- Red Horizontal Sync Ground - Red Signal - Green Ground - Green INSTRUCTION MANUAL EFL-1902X...
-
Page 8: Standard Display Mode
1024 X 768 56.49 KHz 70.1 Hz 75.000 MHz 1024 X 768 60.02 KHz 75.0 Hz 78.750 MHz 1280 X 1024 63.98 KHz 60.0 Hz 108.00 MHz SXGA 1280 X 1024 79.98 KHz 75.0 Hz 135.00 MHz INSTRUCTION MANUAL EFL-1902X... - Page 9 Do not change or modify the product without permission or authority of manufacturer. It may cause undesirable operations, permanent damages or harmful interferences ◎ Notice · Design and specification are subject to change without notice for product improvement purposes. INSTRUCTION MANUAL EFL-1902X...
