ASCO POWER TECHNOLOGIES SIGMA Hand-held Quick Start Manual

SIGMA Hand-held Quickstart Guide
The Sigma Hand-held provides full three-phase instrumentation
on any ASCO Sigma equipped load banks. This quickstart
guide will help you get the best out of the Sigma Hand-held.
1. Set the Supply on Test
Press F4
to confirm.
i
Press F1 to
scroll through
common Preset
electrical
parameters.
Read the load bank manual before
use and take special note of all the
safety warnings. Please view the
manual for load bank / hand-held
connection instructions, error codes
and solutions.
Press F1 to see
total load bank/s
capacity.
Press F2 to set supply
voltage, frequency and
phases automatically
(when supply on test is
connected).
Press F3 to manually
edit supply details.
Use the + and - keys
to set the size of the
supply.
There are numerous
languages available.
Press F2 to find
new load banks
and reset errors.
Options are saved so
you only need to set
them once.
2. Options
Press F1 to see
total load bank/s
capacity.
Press F3 to
view Options.
i
Press F1 to
scroll through
Options pages.
Ramp down
on reject takes
load off slowly
Press F4 to to prevent
confirm Options. damage to
supply on test.
i
ASCO Power Technologies - Froment Load Banks
Cliffe Road, Easton-on-the-Hill, PE9 3NP , United Kingdom
Tel: +44 1780 480033 Email: froment.sales@ascopower.com
© January, 2018. Publication 5069 V2.2
Press F3 to
select the option
and + to edit.
i i
Cyclic auto test
repeats the
auto test until
it is stopped
manually.
