Manual for the Feathering Propeller
Installation on the shaft
Operation
Pitch adjustment LH
Pitch adjustment RH
Defining and checking adjustments
Removing from the shaft
Servicing
Torque settings prop-nut
Formular-Nr.:71 Rev.-Nr.:07 03/18
DF-160 and DF-180
( left-hand rotation propeller )
( right-hand rotation propeller)
-1-
page 2
page 4
page 5
page 6
page 7
page 8
page 9
page 10
Advertisement
Summary of Contents for VariProp DF-160
- Page 1 Manual for the Feathering Propeller DF-160 and DF-180 Installation on the shaft page 2 Operation page 4 Pitch adjustment LH ( left-hand rotation propeller ) page 5 Pitch adjustment RH ( right-hand rotation propeller) page 6 Defining and checking adjustments...
- Page 2 INSTALLATION on the shaft The VARIPROP is delivered assembled, greased and ready for installation. He may not be disassembled, otherwise the warranty claim goes out! Before fitting the VARIPROP onto the shaft, check key and keyway in the propeller hub. Take care that the key is the proper dimension and that the hub slides completely onto the shaft (see below).
- Page 3 Use LOCTITE low (pink) and observe the little washers. ENGINE DRY TEST: Please consider that a dry test of the engine MUST NOT be done while the VARIPROP is fitted onto the shaft ! The VARIPROP needs water pressure on the blades, otherwise the prop could be damaged !! Formular-Nr.:71 Rev.-Nr.:07 03/18...
-
Page 4: Operation
For large yachts, equipped with a propeller from our VARIPROP XLS range, we highly recommend to fit a shaft lock to ensure the propeller feathers and stays in sailing position. - Page 5 PITCH ADJUSTMENT „LH“ GERNAL: The pitch adjustment is very simple on the VARIPROP, and can be done in or out of the water in a matter of few minutes. It is not necessary to pull the propeller from the shaft.
- Page 6 PITCH ADJUSTMENT „RH“ GERNAL: The pitch adjustment is very simple on the VARIPROP, and can be done in or out of the water in a matter of few minutes. It is not necessary to pull the propeller from the shaft.
- Page 7 Defining and checking pitch adjustments It is quite possible to set the pitch continuously variable and independently for forward and reverse. The turning of the adjusting screws (2) & (4) at pages 5 & 6 by quarter a revolution ( 90° ) changes the pitch approx.
- Page 8 (1) The puller nut and (2) the hexagonal head bolt 1.) In order to remove the VARIPROP you must first remove the housing cap with zinc anode. 2.) Remove both lock pins (3) and the prop nut (4, see page 2) 3.) Screw the puller nut completely into the hub...
- Page 9 SERVICING The VARIPROP needs to be greased up a minimum of every 2 – 3 years, depending on the engine hours run, or whenever the boat is hauled. The VARIPROP body should always be completely filled with a high viscosity grease of a hydrophobic nature. Remove the cap screw (5) and screw in the lubricating nipple which is supplied with the tools.
- Page 10 Torque settings for the prop-nut ( page2, Fig.1, part-no.4 ) Standard – thread Fine - thread M 20 x 2,5 M 20 x 1,5 BSW 3 / 4 “ – 10 125 Nm / 95 ft/lb BSF 3 / 4 “ – 12 135 Nm / 100 ft/lb UNC 3 / 4 “...
