Page 1 Instruction Manual...
Page 2: Table Of Contents
・After installation should keep carefully this instruction manual and the wiring diagram according to vehicle type. ・i-Cruise Dial is a parts for race use. Please use it according to regulations, such as the Road Traffic Law, on a public road.
Page 3: Parts List ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P2
Relay harness Although it can detach and attach, please be sure to use it, Caution attaching. i-Cruise Dial i-Cruise Dial Dial unit (one unit) Main unit (one unit) Cable blue, red, and green For a double-stick tape for dial (One sheet)
Page 4: A Function And The Feature ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P3
A function and the feature A standard and an auto-cruise function Auto-cruise will be started if a dial is left-clicked during a run. (It functions at about 30 km/h or more.) Auto cruise returned to normal drive immediately by pressing a brake pedal or pushing a dial.
Page 5 100%. Accelerator canceler function When the power supply of this product is ON, if a brake is stepped on in the state where the accelerator was stepped on, a throttle will be turned OFF (0% of valve travel) compulsorily. Even when an accelerator stops returning by a carpet and a thing being caught in an accelerator etc., vehicles can be slowed...
Page 6: For Use It Safely ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P5
For use it safely In this operation manual, the damage to the property and the body of you or other persons was prevented, and the matter I would like you to keep in order to use this product safely and effectively is written with the mark in it. Please be sure to use it, after that you often read enough understands notes about the safety shown in this operation manual.
Page 7: The Wiring Method, And Installation ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P6
When you take out and insert a connector, please work holding a connector main part. There is a possibility of disconnecting if harness is pulled and impossible power is applied.
Page 8: Installation Schematic View ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P7
6 pins 7 pins 4 pins (It is not used) Main unit The harness according to vehicle type (option) It is not used (yellow). Reverse signal (green) Accelerator Brake signal (red) Speed signal (blue) IG power (white) Ground (black) Dial unit...
Page 9 Installation schematic view and an installation procedure Work procedure (Installation preparation ) ① Please extract an ignition key, stopping vehicles at an even place and applying handbrakes ENGINE firmly. START STOP Ignition OFF Ignition OFF A key is extracted. (Push start type vehicle) ②...
Page 10 When you do not use terminal, please cut, and connect with soldering. Caution Since an electro tap has loose connection's fear, please do not use it for a IG power wire and a brake line by any means. Ground...
Page 11 Since an electro tap has loose connection's fear, please do not use it for a Caution brake line (above) and a power source wire (P9) by any means. Reverse signal <Reverse signal wire (green)> Main unit It is wiring required in order to use a back speed assist facility.
Page 12 Installation schematic view and an installation procedure Work procedure(Fixation of a dial unit) A dial unit has two kinds of fixed methods, double-stick tape and a screw. Please choose the suitable fixed method according to an attachment position etc. Important To fix with double-stick tape ①...
Page 13 Installation schematic view and an installation procedure Work procedure (Fixation of a main part) ① To Main Part Unit, please connect. harness according to Main unit vehicle type (six pin connectors) and dial unit (seven pin connectors) Relay harness ② Please collect each harness using bundles not to become the obstacle of operation.
Page 14 Operation method Name of each part If a hand is lifted from a dial, Neutral it will certainly return to this position. Left-click operation Right-click operation It turns until it is It turns until it is responsive, and lifts responsive, and lifts a hand.
Page 15: Initial Setting 1 ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P15
In addition, if it is made to learn once, even if it removes i-Cruise Dial, and it removes a battery terminal, there is no necessity for re-study as long as it uses it by the same vehicles.
Page 16 Initial-setting 1.<study (continuation of the last page) of an accelerator> ④ Where a foot is taken off an accelerator, Please take a foot please push a dial once. off an accelerator. Please push a dial once. Green blink ⑤ Blink of green LED changes to blink of changes to red LED.
Page 17 Operations check Please check operations after installation as follows. Please interrupt checking operations when some abnormalities arise, and remove a cause of troubles by following troubleshooting P31 . ENGINE START STOP ① Please turn ignition ON (state which the warning lights of meter turn on and the engine has not work), and check that A key is turned to Please push button...
Page 18 Operations check (continuation of the last page) When an engine check lamp lights up ... Study of an accelerator may not be completed normally. Please erase an engine check lamp (P30) and learn an accelerator once again (P14). ④ Please run. Please check that...
Page 19: Initial Setting 2 ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P18
If this product is used without performing this study, the functions, such as auto- cruise, will not operate normally. In addition, if it is made to learn once, even if it removes i-Cruise Dial, and it removes a battery terminal, there is no necessity for re-study as long as it uses it by the same vehicles.
Page 20 Initial-setting 2.<study (continuation of the last page) of speed> ④ Please maintain speed 60 km/h and push a dial in the state. (60km/h) Please push dial once. ⑤ A setup is completion when blue LED disappears, after lighting up for about 1 Blue LED lighting second.
Page 21 Operation list -20-...
Page 22: Notes About Auto-Cruise ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P21
Operation method of auto-cruise Notes about auto-cruise The auto-cruise function of this product is a function for reducing the burden to which the automatic control of the accelerator is carried out on a high-speed way etc., a vehicle speed is kept constant, and a driver adjusts speed. There is no function which detects road situations, such as irregular bound of traffic situations, such as confusion condition of a road and the distance between two cars, a person, running out of vehicles, etc., a curve of a road, and a falling object, and others.
Page 23: For Starting Auto-Cruise ・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・・ P22
Operation method of auto-cruise For starting auto-cruise For start auto-cruise, please push a dial Push a dial one time once and make it into ready state. A button blinks blue. ① For carring out Auto-cruise in a present speed. Please lift a hand in the place which turned the dial to the left until it is responsive.
Page 24 Operation method of auto-cruise For canceling auto-cruise In order to stop an auto-cruise run and to return to the usual run, there are the following two kinds of methods. ① Step on brakes Auto-cruise is immediately canceled by stepping on a brake during auto-cruise. ②...
Page 25 Operation method of auto-cruise About the acceleration and deceleration under auto-cruise By the following and the method of the following page, a change of auto-cruise speed can be made to acceleration and deceleration also in auto-cruise. ① Acceleration and deceleration in a dial click Speed (* target speed) goes up 2 km/h at a time by lifting a hand in the place which turned the dial to the right until it is...
Page 26 Operation method of auto-cruise ③ When it turns pushing a dial, it is acceleration and deceleration. During auto-cruise, if it turns to the right exceeding a clicking point, pushing a dial, it will accelerate. The thing of the largest valve angle at three, auto-cruise control, dial acceleration, and pedal acceleration, is reflected in actual acceleration.
Page 27 Operation method of auto-cruise For adjusting a degree of comfort under auto-cruise During auto-cruise, when speed becomes unstable or a repetition of acceleration and a slowdown is worrisome, please change a level by the following methods. It is set in level adjustment mode. ①...
Page 28 Operation method of throttle control Mode change of throttle control Normal (power supply OFF) Left-click Right-click Left-click Right-click Eco-auto Power auto The light is The light is switched on green. switched on in red. Click: please turn it till you can feel response;...
Page 29 It is image of throttle-open range The effect of manual throttle control Power (1) power (2) becomes the run which was further brisk rather than power auto. Moreover, regardless of a running speed, it becomes an accelerator response as shown in the following figure.
Page 30 About the EcoNavi function According to accelerator valve angle, the lighting color of LED of a dial always changes gradually under a run and regardless of auto-cruise. Blink earliness: It is early. Accelerator valve angle 100％ 100％ ∼ ∼ Blink (red) 91％...
Page 31 How to turn off a check lamp ① Please stop engine and turn off ignition switch. ② Please neglect it about 5 minutes then and remove the cause by which it seems that the check lamp lit up. ③ Please check that waiting and an engine check lamp do not light up for 1 minute after starting engine.
Page 32 When all LED of a dial has gone out, it is in a power supply OFF ！ state, and it is the same as the state where the product is not attached.
Page 33 When LED of a dial does not light up, please check all wiring (P9). ！ Please reconfirm whether there is any mistake in the connector (seven pins) which connects a main part unit with a power source wire (white), a ground (black), the harness according to vehicle type, and a lever especially.
Page 34 Troubleshooting Because of safety, when speed is about 30 km/h or less, auto- ！ cruise cannot be started. Moreover, when it becomes about 30 km/h or less during auto- cruise, auto-cruise is canceled automatically. Since there is possibility of the loose connection of a speed signal ！...
Page 36 ・ Failure and breakage by earthquake, a thunderbolt, flood damage and other natural disasters, an accident, or abnormal voltage. 4. Since I do not recurrence-line-do, please keep this guarantee carefully. Power Enterprise Co., Ltd. 43 Aoshima-cho,Fuji-shi,Shizuoka 417-0047 TEL. 0545-52-0123 F AX. 0545-52-0103 http://www.power-enterprise.co.jp/...
