KidzTech Top Maxx Vortex 84181 Instruction Manual

CHOOSING YOUR PLAYING LOCATION
You can operate your Vortex indoors or outdoors.
rugged conditions and terrains. Do not operate your Vortex on roads or any areas where there are cars. Operating your Vortex
on roads or any areas with cars is extremely dangerous and most likely illegal! The Vortex is not water resistant. Do not operate
your Vortex in any wet conditions, mud, puddles, rain or any other form of precipitation or harsh weather. The Vortex has open
Cooling Vents in some strategic locations. If water gets into these Cooling Vents, the Vortex could sustain damage which would
not be covered under warranty. If operating your Vortex indoors, be careful to avoid contact with any objects such as furniture,
plants, electronics, and any other items which can break easily. The Vortex is capable of some relatively high speed stunts and
could easily damage some household objects. Avoid operating your Vortex around pets or people, and especially crowds. If the
Vortex is stepped on or otherwise crushed, it will sustain damage that would not be covered under warranty. Ensure that people
around you are aware that you are playing with your Vortex. Be aware of changes in your operational environment and play safe!
The radio control range of your Vortex is up to 80' (24 M), and varies depending on interference within the operational
environment. WARNING: The relatively high speed stunts of the Vortex are capable of damaging or injuring plants, furniture,
pets or people so play carefully.
Performance Tips
1. Do not drive on grass, dirt, sand, dusts, carpet or go through water.
2. Do not drive in windy or rainy weather.
3. Avoid direct impact the Vehicle with obstacles.
4. Switch OFF the power when not in use to prevent damage of Vehicle and
Transmitter due to leakage of electrolyte from batteries.
5. Remove all batteries from the Vehicle and Transmitter when not in use for
long period.
Cautions
1. Do not attempt to disassemble the Vehicle or Transmitter.
2. Do not operate the Vehicle with same frequency with other player(s)
in same location that will interfere and make the Vehicle out of control.
3. Make sure the batteries are installed with correct polarities (+/-) as
shown inside the battery compartment.
4. Remove the package and take out all accessories before giving the
Vehicle and Transmitter to child to play.
FCC label compliance statement:
This device complies with part 15 of the FCC rules. Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including interference that may cause undesired operation.
Note: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined
by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following
measures:
- Reorient or relocate the receiving antenna
- Increase the separation between the equipment and receiver
- Connect the equipment into an outlet on a circuit different from that to which the receiver is connected
- Consult the dealer or an experienced radio/TV technician for help
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user's authority to operate the
equipment.
RSS-310 Compliance Statement:
This device complies with Industry Canada Licence-exempt RSS-310. Operation is subject to the following two conditions:
(1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the
device.
Declaration of Conformity
The product is in conformity with the requirement of EU Directive 1999/5/EC
Environmental notes:
The whole product also does not belong to household waste at the end of the product life.
You can return it at collection points for the recycling of electronic and electronical instruments
The symbol on the item, instruction manual, hangtag or packing is showing this clearly.
Materials should be recycled according to their respective markings.
Recycling of old devices or other re-use of materials contained therein represents an important contribution to environmental protection.
Please ask at your local community for the correct collection point.
Disposal of batteries
Batteries should not be disposed of in the household waste. As the consumer you are legally obliged to return batteries containing harmful substances and all
other used batteries. You can hand in your old batteries at public collection points in your area or wherever batteries are sold.
You will find these chemical abbreviations along with a crossed-out refuse bin on batteries containing harmful substances:
Pb=Battery contains lead
Cd=Battery contains cadmium
Hg=Battery contains mercury
The Vortex is designed to operate in most
Voltage of batteries in Transmitter or Vehicle b) Interference from other
items that emit radio frequency signals.
8. Outdoor usage is recommended in order to get optimum control range.
9. Recommend to play the vehicle on a clean and smooth surface.
10. Clean the battery compartment to make sure it is free from dust to
prevent poor contact of batteries
The packaging and instruction manual contain important
information. Please keep them for future reference.
Warning! Choking Hazard. Not suitable for children under
the age of 3 years due to small parts.
We reserve the right to improve/amend specifications and
colors without notice.
Warning! The Antenna of vehicle is not to be inserted into
socket outlets.
Conforms to the safety requirements of ASTM F963
INSTRUCTION
MANUAL
Vortex 360° Stunt RC Vehicle
Main body
11.1V Lithium Ion
Rechargeable Battery Pack AC Charger
BATTERY REQUIREMENTS:
1. Vehicle:
9V
1 x 11.1V Lithium Ion (1100mAH)
rechargeable battery pack
(Included)
2. Transmitter:
1 x 9V battery(Included)
Charging the Rechargeable Battery Pack for the Vehicle
1. Connect the 11.1V rechargeable battery pack to the battery charger.
2. Plug the charger into the standard AC socket.
3. The charging time for a full charge is about 2 hours.
4. When charging is completed, unplug the charger from the AC socket.
5. Disconnect the rechargeable battery pack form the battery charger.
• Be Sure To Charge Battery Pack Before Using.
CAUTION
• If Battery Pack Is Hot After Use, Allow To Cool Before Recharging.
• Do Not Dispose Of Battery Pack In Fire.
• Do Not Recharge Battery Pack That Shows Leakage Or Corrosion,
or Attempt To Open Battery Pack.
- Full function radio - Full function radio
control stunt vehicle control stunt vehicle
Antenna
Radio Controller & Antenna
Rear Spoiler
Power On LED
Left Stick
- Controls Forward /
Reverse speed on
left side wheels of
Vortex
Needle
11.1V Lithium
1 X 9V Battery
1100mAh
For Transmitter
11.1V
For Vehicle
(Included)
(Included)
1100mAh
Rechargeable Rechargeable
ADAPTER Battery
(Included)
Pack
8
age
NO. 84181
Right Stick
- Controls Forward /
Reverse speed on
right side wheels of
Vortex
Twist Control
- Controls twisting
of Vortex
Rechargeable Battery Must Be
Recycled Or Disposed Of Properly.
